Please, help, I’m a little bit desperate.
I’m not exactly new to Linux, or Manjaro, but I never needed solve problem with sound before and my knowledge or talent with computers are very limited, unfortunatly. I’m with a new computer, and it’s been difficult to get used to it, and since I bought it I installed my linux in it, and t is showing some problems recognizing audio, like, there is the HDMI port of the monitor and the profile was all the time changing it to the HDMI profile, but my monitor don’t have speakers or audio port, so i was using the headphone in the front of the PC with the profile “digital stereo out” (in my system it is in portuguese, I’m translating here as I can) as “headphones”, but every game that I started playing it changed automaticaly to the HDMI profile, I was getting really frustrated, and then I connected to the rear phone entrance of the pc, and connected in the profile “digital stereo out” as “line out”, and it worked for some hours, I could play two games without problems, BUT when I turned off the computer, hours later I turned on again it was not working anymore, and it doesn’t matter if I connect in front or rear, even if the profile doesn’t change, it always says “disconected” in every profile I choose, even with my headphone plugged into it. I don’t know what is happening. I was so happy when I bought the computer, now it’s been a headache.
!!################################
!!ALSA Information Script v 0.5.1
!!################################
!!Script ran on: Mon Aug 29 02:01:39 UTC 2022
!!Linux Distribution
!!------------------
ID_LIKE=arch
!!DMI Information
!!---------------
Manufacturer: To be filled by O.E.M.
Product Name: To be filled by O.E.M.
Product Version: To be filled by O.E.M.
Firmware Version: 4.6.5
System SKU: To be filled by O.E.M.
Board Vendor:
Board Name:
!!ACPI Device Status Information
!!---------------
/sys/bus/acpi/devices/INT3F0D:00/status 15
/sys/bus/acpi/devices/PNP0103:00/status 15
/sys/bus/acpi/devices/PNP0C01:01/status 15
/sys/bus/acpi/devices/PNP0C0C:00/status 15
/sys/bus/acpi/devices/PNP0C0F:00/status 9
/sys/bus/acpi/devices/PNP0C0F:01/status 9
/sys/bus/acpi/devices/PNP0C0F:02/status 9
/sys/bus/acpi/devices/PNP0C0F:03/status 9
/sys/bus/acpi/devices/PNP0C0F:04/status 9
/sys/bus/acpi/devices/PNP0C0F:05/status 9
/sys/bus/acpi/devices/PNP0C0F:06/status 9
/sys/bus/acpi/devices/PNP0C0F:07/status 9
!!Kernel Information
!!------------------
Kernel release: 5.15.60-1-MANJARO
Operating System: GNU/Linux
Architecture: x86_64
Processor: unknown
SMP Enabled: Yes
!!ALSA Version
!!------------
Driver version: k5.15.60-1-MANJARO
Library version: 1.2.7.2
Utilities version: 1.2.7
!!Loaded ALSA modules
!!-------------------
snd_hda_intel (card 0)
!!Sound Servers on this system
!!----------------------------
PipeWire:
Installed - Yes (/usr/bin/pipewire)
Running - Yes
Pulseaudio:
Installed - Yes (/usr/bin/pulseaudio)
Running - Yes
Jack:
Installed - Yes (/usr/bin/jackd)
Running - No
!!Soundcards recognised by ALSA
!!-----------------------------
0 [PCH ]: HDA-Intel - HDA Intel PCH
HDA Intel PCH at 0xf7d00000 irq 30
!!PCI Soundcards installed in the system
!!--------------------------------------
00:1b.0 Audio device [0403]: Intel Corporation 6 Series/C200 Series Chipset Family High Definition Audio Controller [8086:1c20] (rev 05)
Subsystem: Intel Corporation 6 Series/C200 Series Chipset Family High Definition Audio Controller [8086:1c20]
!!Loaded sound module options
!!---------------------------
!!Module: snd_hda_intel
align_buffer_size : -1
bdl_pos_adj : -1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1
beep_mode : N,N,N,N,N,N,N,N,N,N,N,N,N,N,N,N,N,N,N,N,N,N,N,N,N,N,N,N,N,N,N,N
dmic_detect : Y
enable : Y,Y,Y,Y,Y,Y,Y,Y,Y,Y,Y,Y,Y,Y,Y,Y,Y,Y,Y,Y,Y,Y,Y,Y,Y,Y,Y,Y,Y,Y,Y,Y
enable_msi : -1
id : (null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null)
index : -1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1
jackpoll_ms : 0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0
model : (null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null)
patch : (null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null),(null)
pm_blacklist : Y
position_fix : -1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1
power_save : 1
power_save_controller : Y
probe_mask : -1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1,-1
probe_only : 0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0
single_cmd : -1
snoop : -1
!!Sysfs card info
!!---------------
!!Card: /sys/class/sound/card0
Driver: /sys/bus/pci/drivers/snd_hda_intel
Tree:
!!HDA-Intel Codec information
!!---------------------------
--startcollapse--
Codec: Realtek ALC883
Address: 0
AFG Function Id: 0x1 (unsol 0)
Vendor Id: 0x10ec0883
Subsystem Id: 0x10ec0883
Revision Id: 0x100002
No Modem Function Group found
Default PCM:
rates [0x560]: 44100 48000 96000 192000
bits [0xe]: 16 20 24
formats [0x1]: PCM
Default Amp-In caps: N/A
Default Amp-Out caps: N/A
State of AFG node 0x01:
Power states: D0 D1 D2 D3
Power: setting=D0, actual=D0
GPIO: io=2, o=0, i=0, unsolicited=1, wake=0
IO[0]: enable=0, dir=0, wake=0, sticky=0, data=0, unsol=0
IO[1]: enable=0, dir=0, wake=0, sticky=0, data=0, unsol=0
Node 0x02 [Audio Output] wcaps 0x11: Stereo
Device: name="ALC883 Analog", type="Audio", device=0
Converter: stream=0, channel=0
PCM:
rates [0x560]: 44100 48000 96000 192000
bits [0xe]: 16 20 24
formats [0x1]: PCM
Node 0x03 [Audio Output] wcaps 0x11: Stereo
Converter: stream=0, channel=0
PCM:
rates [0x560]: 44100 48000 96000 192000
bits [0xe]: 16 20 24
formats [0x1]: PCM
Node 0x04 [Audio Output] wcaps 0x11: Stereo
Converter: stream=0, channel=0
PCM:
rates [0x560]: 44100 48000 96000 192000
bits [0xe]: 16 20 24
formats [0x1]: PCM
Node 0x05 [Audio Output] wcaps 0x11: Stereo
Converter: stream=0, channel=0
PCM:
rates [0x560]: 44100 48000 96000 192000
bits [0xe]: 16 20 24
formats [0x1]: PCM
Node 0x06 [Audio Output] wcaps 0x211: Stereo Digital
Control: name="IEC958 Playback Con Mask", index=16, device=0
Control: name="IEC958 Playback Pro Mask", index=16, device=0
Control: name="IEC958 Playback Default", index=16, device=0
Control: name="IEC958 Playback Switch", index=16, device=0
Control: name="IEC958 Default PCM Playback Switch", index=0, device=0
Device: name="ALC883 Digital", type="SPDIF", device=1
Converter: stream=0, channel=0
Digital: Enabled
Digital category: 0x0
IEC Coding Type: 0x0
PCM:
rates [0x560]: 44100 48000 96000 192000
bits [0x1e]: 16 20 24 32
formats [0x1]: PCM
Node 0x07 [Vendor Defined Widget] wcaps 0xf00000: Mono
Node 0x08 [Audio Input] wcaps 0x10011b: Stereo Amp-In
Control: name="Capture Volume", index=0, device=0
ControlAmp: chs=3, dir=In, idx=0, ofs=0
Control: name="Capture Switch", index=0, device=0
ControlAmp: chs=3, dir=In, idx=0, ofs=0
Device: name="ALC883 Analog", type="Audio", device=0
Amp-In caps: ofs=0x08, nsteps=0x1f, stepsize=0x05, mute=1
Amp-In vals: [0x10 0x10]
Converter: stream=0, channel=0
SDI-Select: 0
PCM:
rates [0x160]: 44100 48000 96000
bits [0x6]: 16 20
formats [0x1]: PCM
Connection: 1
0x23
Node 0x09 [Audio Input] wcaps 0x10011b: Stereo Amp-In
Control: name="Capture Volume", index=1, device=0
ControlAmp: chs=3, dir=In, idx=0, ofs=0
Control: name="Capture Switch", index=1, device=0
ControlAmp: chs=3, dir=In, idx=0, ofs=0
Device: name="ALC883 Alt Analog", type="Audio", device=2
Amp-In caps: ofs=0x08, nsteps=0x1f, stepsize=0x05, mute=1
Amp-In vals: [0x80 0x80]
Converter: stream=0, channel=0
SDI-Select: 0
PCM:
rates [0x160]: 44100 48000 96000
bits [0x6]: 16 20
formats [0x1]: PCM
Connection: 1
0x22
Node 0x0a [Audio Input] wcaps 0x100391: Stereo Digital
Control: name="IEC958 Capture Switch", index=0, device=0
Control: name="IEC958 Capture Default", index=0, device=0
Device: name="ALC883 Digital", type="SPDIF", device=1
Converter: stream=0, channel=0
SDI-Select: 0
Digital:
Digital category: 0x0
IEC Coding Type: 0x0
PCM:
rates [0x560]: 44100 48000 96000 192000
bits [0x1e]: 16 20 24 32
formats [0x1]: PCM
Unsolicited: tag=00, enabled=0
Connection: 1
0x1f
Node 0x0b [Audio Mixer] wcaps 0x20010b: Stereo Amp-In
Control: name="Rear Mic Playback Volume", index=0, device=0
ControlAmp: chs=3, dir=In, idx=0, ofs=0
Control: name="Rear Mic Playback Switch", index=0, device=0
ControlAmp: chs=3, dir=In, idx=0, ofs=0
Control: name="Front Mic Playback Volume", index=0, device=0
ControlAmp: chs=3, dir=In, idx=1, ofs=0
Control: name="Front Mic Playback Switch", index=0, device=0
ControlAmp: chs=3, dir=In, idx=1, ofs=0
Control: name="Line Playback Volume", index=0, device=0
ControlAmp: chs=3, dir=In, idx=2, ofs=0
Control: name="Line Playback Switch", index=0, device=0
ControlAmp: chs=3, dir=In, idx=2, ofs=0
Control: name="CD Playback Volume", index=0, device=0
ControlAmp: chs=3, dir=In, idx=4, ofs=0
Control: name="CD Playback Switch", index=0, device=0
ControlAmp: chs=3, dir=In, idx=4, ofs=0
Control: name="Beep Playback Volume", index=0, device=0
ControlAmp: chs=3, dir=In, idx=5, ofs=0
Control: name="Beep Playback Switch", index=0, device=0
ControlAmp: chs=3, dir=In, idx=5, ofs=0
Amp-In caps: ofs=0x17, nsteps=0x1f, stepsize=0x05, mute=1
Amp-In vals: [0x80 0x80] [0x80 0x80] [0x80 0x80] [0x80 0x80] [0x80 0x80] [0x80 0x80] [0x80 0x80] [0x80 0x80] [0x80 0x80] [0x80 0x80]
Connection: 10
0x18 0x19 0x1a 0x1b 0x1c 0x1d 0x14 0x15 0x16 0x17
Node 0x0c [Audio Mixer] wcaps 0x20010f: Stereo Amp-In Amp-Out
Control: name="Front Playback Volume", index=0, device=0
ControlAmp: chs=3, dir=Out, idx=0, ofs=0
Amp-In caps: ofs=0x00, nsteps=0x00, stepsize=0x00, mute=1
Amp-In vals: [0x00 0x00] [0x80 0x80]
Amp-Out caps: ofs=0x1f, nsteps=0x1f, stepsize=0x05, mute=0
Amp-Out vals: [0x19 0x19]
Connection: 2
0x02 0x0b
Node 0x0d [Audio Mixer] wcaps 0x20010f: Stereo Amp-In Amp-Out
Control: name="Surround Playback Volume", index=0, device=0
ControlAmp: chs=3, dir=Out, idx=0, ofs=0
Amp-In caps: ofs=0x00, nsteps=0x00, stepsize=0x00, mute=1
Amp-In vals: [0x00 0x00] [0x80 0x80]
Amp-Out caps: ofs=0x1f, nsteps=0x1f, stepsize=0x05, mute=0
Amp-Out vals: [0x19 0x19]
Connection: 2
0x03 0x0b
Node 0x0e [Audio Mixer] wcaps 0x20010f: Stereo Amp-In Amp-Out
Control: name="Center Playback Volume", index=0, device=0
ControlAmp: chs=1, dir=Out, idx=0, ofs=0
Control: name="LFE Playback Volume", index=0, device=0
ControlAmp: chs=2, dir=Out, idx=0, ofs=0
Amp-In caps: ofs=0x00, nsteps=0x00, stepsize=0x00, mute=1
Amp-In vals: [0x00 0x00] [0x80 0x80]
Amp-Out caps: ofs=0x1f, nsteps=0x1f, stepsize=0x05, mute=0
Amp-Out vals: [0x19 0x19]
Connection: 2
0x04 0x0b
Node 0x0f [Audio Mixer] wcaps 0x20010f: Stereo Amp-In Amp-Out
Control: name="Side Playback Volume", index=0, device=0
ControlAmp: chs=3, dir=Out, idx=0, ofs=0
Amp-In caps: ofs=0x00, nsteps=0x00, stepsize=0x00, mute=1
Amp-In vals: [0x00 0x00] [0x80 0x80]
Amp-Out caps: ofs=0x1f, nsteps=0x1f, stepsize=0x05, mute=0
Amp-Out vals: [0x19 0x19]
Connection: 2
0x05 0x0b
Node 0x10 [Vendor Defined Widget] wcaps 0xf00000: Mono
Node 0x11 [Vendor Defined Widget] wcaps 0xf00000: Mono
Node 0x12 [Vendor Defined Widget] wcaps 0xf00000: Mono
Node 0x13 [Vendor Defined Widget] wcaps 0xf00000: Mono
Node 0x14 [Pin Complex] wcaps 0x40018f: Stereo Amp-In Amp-Out
Control: name="Front Playback Switch", index=0, device=0
ControlAmp: chs=3, dir=Out, idx=0, ofs=0
Amp-In caps: ofs=0x00, nsteps=0x03, stepsize=0x27, mute=0
Amp-In vals: [0x00 0x00]
Amp-Out caps: ofs=0x00, nsteps=0x00, stepsize=0x00, mute=1
Amp-Out vals: [0x00 0x00]
Pincap 0x0000003e: IN OUT HP Detect Trigger
Pin Default 0x01014030: [Jack] Line Out at Ext Rear
Conn = 1/8, Color = Green
DefAssociation = 0x3, Sequence = 0x0
Pin-ctls: 0x40: OUT
Unsolicited: tag=06, enabled=1
Connection: 5
0x0c* 0x0d 0x0e 0x0f 0x26
Node 0x15 [Pin Complex] wcaps 0x40018f: Stereo Amp-In Amp-Out
Control: name="Center Playback Switch", index=0, device=0
ControlAmp: chs=1, dir=Out, idx=0, ofs=0
Control: name="LFE Playback Switch", index=0, device=0
ControlAmp: chs=2, dir=Out, idx=0, ofs=0
Amp-In caps: ofs=0x00, nsteps=0x03, stepsize=0x27, mute=0
Amp-In vals: [0x00 0x00]
Amp-Out caps: ofs=0x00, nsteps=0x00, stepsize=0x00, mute=1
Amp-Out vals: [0x00 0x00]
Pincap 0x0000003e: IN OUT HP Detect Trigger
Pin Default 0x01011031: [Jack] Line Out at Ext Rear
Conn = 1/8, Color = Black
DefAssociation = 0x3, Sequence = 0x1
Pin-ctls: 0x40: OUT
Unsolicited: tag=08, enabled=1
Connection: 5
0x0c 0x0d 0x0e* 0x0f 0x26
Node 0x16 [Pin Complex] wcaps 0x40018f: Stereo Amp-In Amp-Out
Control: name="Surround Playback Switch", index=0, device=0
ControlAmp: chs=3, dir=Out, idx=0, ofs=0
Amp-In caps: ofs=0x00, nsteps=0x03, stepsize=0x27, mute=0
Amp-In vals: [0x00 0x00]
Amp-Out caps: ofs=0x00, nsteps=0x00, stepsize=0x00, mute=1
Amp-Out vals: [0x00 0x00]
Pincap 0x0000003e: IN OUT HP Detect Trigger
Pin Default 0x01016032: [Jack] Line Out at Ext Rear
Conn = 1/8, Color = Orange
DefAssociation = 0x3, Sequence = 0x2
Pin-ctls: 0x40: OUT
Unsolicited: tag=07, enabled=1
Connection: 5
0x0c 0x0d* 0x0e 0x0f 0x26
Node 0x17 [Pin Complex] wcaps 0x40018f: Stereo Amp-In Amp-Out
Control: name="Side Playback Switch", index=0, device=0
ControlAmp: chs=3, dir=Out, idx=0, ofs=0
Amp-In caps: ofs=0x00, nsteps=0x03, stepsize=0x27, mute=0
Amp-In vals: [0x00 0x00]
Amp-Out caps: ofs=0x00, nsteps=0x00, stepsize=0x00, mute=1
Amp-Out vals: [0x00 0x00]
Pincap 0x0000003e: IN OUT HP Detect Trigger
Pin Default 0x01012033: [Jack] Line Out at Ext Rear
Conn = 1/8, Color = Grey
DefAssociation = 0x3, Sequence = 0x3
Pin-ctls: 0x40: OUT
Unsolicited: tag=09, enabled=1
Connection: 5
0x0c 0x0d 0x0e 0x0f* 0x26
Node 0x18 [Pin Complex] wcaps 0x40018f: Stereo Amp-In Amp-Out
Control: name="Rear Mic Boost Volume", index=0, device=0
ControlAmp: chs=3, dir=In, idx=0, ofs=0
Amp-In caps: ofs=0x00, nsteps=0x03, stepsize=0x27, mute=0
Amp-In vals: [0x00 0x00]
Amp-Out caps: ofs=0x00, nsteps=0x00, stepsize=0x00, mute=1
Amp-Out vals: [0x80 0x80]
Pincap 0x0000173e: IN OUT HP Detect Trigger
Vref caps: HIZ 50 GRD 80
Pin Default 0x01a19850: [Jack] Mic at Ext Rear
Conn = 1/8, Color = Pink
DefAssociation = 0x5, Sequence = 0x0
Pin-ctls: 0x21: IN VREF_50
Unsolicited: tag=02, enabled=1
Connection: 5
0x0c* 0x0d 0x0e 0x0f 0x26
Node 0x19 [Pin Complex] wcaps 0x40018f: Stereo Amp-In Amp-Out
Control: name="Front Mic Boost Volume", index=0, device=0
ControlAmp: chs=3, dir=In, idx=0, ofs=0
Amp-In caps: ofs=0x00, nsteps=0x03, stepsize=0x27, mute=0
Amp-In vals: [0x00 0x00]
Amp-Out caps: ofs=0x00, nsteps=0x00, stepsize=0x00, mute=1
Amp-Out vals: [0x80 0x80]
Pincap 0x0000173e: IN OUT HP Detect Trigger
Vref caps: HIZ 50 GRD 80
Pin Default 0x02a19c80: [Jack] Mic at Ext Front
Conn = 1/8, Color = Pink
DefAssociation = 0x8, Sequence = 0x0
Pin-ctls: 0x24: IN VREF_80
Unsolicited: tag=03, enabled=1
Connection: 5
0x0c* 0x0d 0x0e 0x0f 0x26
Node 0x1a [Pin Complex] wcaps 0x40018f: Stereo Amp-In Amp-Out
Control: name="Line Boost Volume", index=0, device=0
ControlAmp: chs=3, dir=In, idx=0, ofs=0
Amp-In caps: ofs=0x00, nsteps=0x03, stepsize=0x27, mute=0
Amp-In vals: [0x00 0x00]
Amp-Out caps: ofs=0x00, nsteps=0x00, stepsize=0x00, mute=1
Amp-Out vals: [0x80 0x80]
Pincap 0x0000173e: IN OUT HP Detect Trigger
Vref caps: HIZ 50 GRD 80
Pin Default 0x01813050: [Jack] Line In at Ext Rear
Conn = 1/8, Color = Blue
DefAssociation = 0x5, Sequence = 0x0
Pin-ctls: 0x20: IN VREF_HIZ
Unsolicited: tag=04, enabled=1
Connection: 5
0x0c* 0x0d 0x0e 0x0f 0x26
Node 0x1b [Pin Complex] wcaps 0x40018f: Stereo Amp-In Amp-Out
Control: name="Headphone Playback Switch", index=0, device=0
ControlAmp: chs=3, dir=Out, idx=0, ofs=0
Amp-In caps: ofs=0x00, nsteps=0x03, stepsize=0x27, mute=0
Amp-In vals: [0x00 0x00]
Amp-Out caps: ofs=0x00, nsteps=0x00, stepsize=0x00, mute=1
Amp-Out vals: [0x80 0x80]
Pincap 0x0000173e: IN OUT HP Detect Trigger
Vref caps: HIZ 50 GRD 80
Pin Default 0x02214c40: [Jack] HP Out at Ext Front
Conn = 1/8, Color = Green
DefAssociation = 0x4, Sequence = 0x0
Pin-ctls: 0xc0: OUT HP VREF_HIZ
Unsolicited: tag=01, enabled=1
Connection: 5
0x0c 0x0d 0x0e 0x0f 0x26*
Node 0x1c [Pin Complex] wcaps 0x400001: Stereo
Pincap 0x00000020: IN
Pin Default 0x99331150: [Fixed] CD at Int ATAPI
Conn = ATAPI, Color = Black
DefAssociation = 0x5, Sequence = 0x0
Misc = NO_PRESENCE
Pin-ctls: 0x00:
Node 0x1d [Pin Complex] wcaps 0x400000: Mono
Pincap 0x00000020: IN
Pin Default 0x00000100: [Jack] Line Out at Ext N/A
Conn = Unknown, Color = Unknown
DefAssociation = 0x0, Sequence = 0x0
Misc = NO_PRESENCE
Pin-ctls: 0x00:
Node 0x1e [Pin Complex] wcaps 0x400300: Mono Digital
Pincap 0x00000010: OUT
Pin Default 0x01441170: [Jack] SPDIF Out at Ext Rear
Conn = RCA, Color = Black
DefAssociation = 0x7, Sequence = 0x0
Misc = NO_PRESENCE
Pin-ctls: 0x00:
Connection: 1
0x06
Node 0x1f [Pin Complex] wcaps 0x400200: Mono Digital
Pincap 0x00000020: IN
Pin Default 0x01c46160: [Jack] SPDIF In at Ext Rear
Conn = RCA, Color = Orange
DefAssociation = 0x6, Sequence = 0x0
Misc = NO_PRESENCE
Pin-ctls: 0x00:
Node 0x20 [Vendor Defined Widget] wcaps 0xf00040: Mono
Processing caps: benign=0, ncoeff=17
Node 0x21 [Vendor Defined Widget] wcaps 0xf00000: Mono
Node 0x22 [Audio Mixer] wcaps 0x20010f: Stereo Amp-In Amp-Out
Amp-In caps: ofs=0x00, nsteps=0x00, stepsize=0x00, mute=1
Amp-In vals: [0x00 0x00] [0x80 0x80] [0x80 0x80] [0x80 0x80] [0x80 0x80] [0x80 0x80] [0x80 0x80] [0x80 0x80] [0x80 0x80] [0x80 0x80] [0x80 0x80]
Amp-Out caps: N/A
Amp-Out vals: [0x00 0x00]
Connection: 11
0x18 0x19 0x1a 0x1b 0x1c 0x1d 0x14 0x15 0x16 0x17 0x0b
Node 0x23 [Audio Mixer] wcaps 0x20010f: Stereo Amp-In Amp-Out
Amp-In caps: ofs=0x00, nsteps=0x00, stepsize=0x00, mute=1
Amp-In vals: [0x00 0x00] [0x80 0x80] [0x80 0x80] [0x80 0x80] [0x80 0x80] [0x80 0x80] [0x80 0x80] [0x80 0x80] [0x80 0x80] [0x80 0x80] [0x80 0x80]
Amp-Out caps: N/A
Amp-Out vals: [0x00 0x00]
Connection: 11
0x18 0x19 0x1a 0x1b 0x1c 0x1d 0x14 0x15 0x16 0x17 0x0b
Node 0x24 [Vendor Defined Widget] wcaps 0xf00000: Mono
Node 0x25 [Audio Output] wcaps 0x11: Stereo
Converter: stream=0, channel=0
PCM:
rates [0x560]: 44100 48000 96000 192000
bits [0xe]: 16 20 24
formats [0x1]: PCM
Node 0x26 [Audio Mixer] wcaps 0x20010f: Stereo Amp-In Amp-Out
Control: name="Headphone Playback Volume", index=0, device=0
ControlAmp: chs=3, dir=Out, idx=0, ofs=0
Amp-In caps: ofs=0x00, nsteps=0x00, stepsize=0x00, mute=1
Amp-In vals: [0x00 0x00] [0x80 0x80]
Amp-Out caps: ofs=0x1f, nsteps=0x1f, stepsize=0x05, mute=0
Amp-Out vals: [0x00 0x00]
Connection: 2
0x25 0x0b
Codec: Intel CougarPoint HDMI
Address: 3
AFG Function Id: 0x1 (unsol 0)
Vendor Id: 0x80862805
Subsystem Id: 0x80860101
Revision Id: 0x100000
No Modem Function Group found
Default PCM:
rates [0x0]:
bits [0x0]:
formats [0x0]:
Default Amp-In caps: N/A
Default Amp-Out caps: N/A
State of AFG node 0x01:
Power states: D0 D3 CLKSTOP EPSS
Power: setting=D0, actual=D0, Clock-stop-OK
GPIO: io=0, o=0, i=0, unsolicited=0, wake=0
Node 0x02 [Audio Output] wcaps 0x6611: 8-Channels Digital
Converter: stream=0, channel=0
Digital: Enabled
Digital category: 0x0
IEC Coding Type: 0x0
PCM:
rates [0x7f0]: 32000 44100 48000 88200 96000 176400 192000
bits [0x1e]: 16 20 24 32
formats [0x5]: PCM AC3
Power states: D0 D3 EPSS
Power: setting=D0, actual=D0
Node 0x03 [Audio Output] wcaps 0x6611: 8-Channels Digital
Converter: stream=0, channel=0
Digital: Enabled GenLevel
Digital category: 0x2
IEC Coding Type: 0x0
PCM:
rates [0x7f0]: 32000 44100 48000 88200 96000 176400 192000
bits [0x1e]: 16 20 24 32
formats [0x5]: PCM AC3
Power states: D0 D3 EPSS
Power: setting=D0, actual=D0
Node 0x04 [Audio Output] wcaps 0x6611: 8-Channels Digital
Converter: stream=0, channel=0
Digital: Enabled
Digital category: 0x0
IEC Coding Type: 0x0
PCM:
rates [0x7f0]: 32000 44100 48000 88200 96000 176400 192000
bits [0x1e]: 16 20 24 32
formats [0x5]: PCM AC3
Power states: D0 D3 EPSS
Power: setting=D0, actual=D0
Node 0x05 [Pin Complex] wcaps 0x40778d: 8-Channels Digital Amp-Out CP
Control: name="IEC958 Playback Con Mask", index=0, device=0
Control: name="IEC958 Playback Pro Mask", index=0, device=0
Control: name="IEC958 Playback Default", index=0, device=0
Control: name="IEC958 Playback Switch", index=0, device=0
Amp-Out caps: ofs=0x00, nsteps=0x00, stepsize=0x00, mute=1
Amp-Out vals: [0x00 0x00]
Pincap 0x09000094: OUT Detect HBR HDMI DP
Pin Default 0x18560010: [Jack] Digital Out at Int HDMI
Conn = Digital, Color = Unknown
DefAssociation = 0x1, Sequence = 0x0
Pin-ctls: 0x40: OUT
Unsolicited: tag=00, enabled=0
Power states: D0 D3 EPSS
Power: setting=D0, actual=D0
Connection: 1
0x02
Node 0x06 [Pin Complex] wcaps 0x40778d: 8-Channels Digital Amp-Out CP
Control: name="IEC958 Playback Con Mask", index=1, device=0
Control: name="IEC958 Playback Pro Mask", index=1, device=0
Control: name="IEC958 Playback Default", index=1, device=0
Control: name="IEC958 Playback Switch", index=1, device=0
Amp-Out caps: ofs=0x00, nsteps=0x00, stepsize=0x00, mute=1
Amp-Out vals: [0x00 0x00]
Pincap 0x09000094: OUT Detect HBR HDMI DP
Pin Default 0x18560010: [Jack] Digital Out at Int HDMI
Conn = Digital, Color = Unknown
DefAssociation = 0x1, Sequence = 0x0
Pin-ctls: 0x40: OUT
Unsolicited: tag=00, enabled=0
Power states: D0 D3 EPSS
Power: setting=D0, actual=D0
Connection: 1
0x03
Node 0x07 [Pin Complex] wcaps 0x40778d: 8-Channels Digital Amp-Out CP
Control: name="IEC958 Playback Con Mask", index=2, device=0
Control: name="IEC958 Playback Pro Mask", index=2, device=0
Control: name="IEC958 Playback Default", index=2, device=0
Control: name="IEC958 Playback Switch", index=2, device=0
Amp-Out caps: ofs=0x00, nsteps=0x00, stepsize=0x00, mute=1
Amp-Out vals: [0x00 0x00]
Pincap 0x09000094: OUT Detect HBR HDMI DP
Pin Default 0x18560010: [Jack] Digital Out at Int HDMI
Conn = Digital, Color = Unknown
DefAssociation = 0x1, Sequence = 0x0
Pin-ctls: 0x40: OUT
Unsolicited: tag=00, enabled=0
Power states: D0 D3 EPSS
Power: setting=D0, actual=D0
Connection: 1
0x04
Node 0x08 [Vendor Defined Widget] wcaps 0xf00000: Mono
--endcollapse--
!!ALSA Device nodes
!!-----------------
crw-rw---- 1 root audio 116, 12 Aug 28 22:59 /dev/snd/controlC0
crw-rw---- 1 root audio 116, 10 Aug 28 22:59 /dev/snd/hwC0D0
crw-rw---- 1 root audio 116, 11 Aug 28 22:59 /dev/snd/hwC0D3
crw-rw---- 1 root audio 116, 3 Aug 28 22:59 /dev/snd/pcmC0D0c
crw-rw---- 1 root audio 116, 2 Aug 28 23:00 /dev/snd/pcmC0D0p
crw-rw---- 1 root audio 116, 5 Aug 28 23:00 /dev/snd/pcmC0D1c
crw-rw---- 1 root audio 116, 4 Aug 28 22:59 /dev/snd/pcmC0D1p
crw-rw---- 1 root audio 116, 6 Aug 28 22:59 /dev/snd/pcmC0D2c
crw-rw---- 1 root audio 116, 7 Aug 28 22:59 /dev/snd/pcmC0D3p
crw-rw---- 1 root audio 116, 8 Aug 28 22:59 /dev/snd/pcmC0D7p
crw-rw---- 1 root audio 116, 9 Aug 28 22:59 /dev/snd/pcmC0D8p
crw-rw---- 1 root audio 116, 1 Aug 28 22:59 /dev/snd/seq
crw-rw---- 1 root audio 116, 33 Aug 28 22:59 /dev/snd/timer
/dev/snd/by-path:
total 0
drwxr-xr-x 2 root root 60 Aug 28 22:59 .
drwxr-xr-x 3 root root 320 Aug 28 22:59 ..
lrwxrwxrwx 1 root root 12 Aug 28 22:59 pci-0000:00:1b.0 -> ../controlC0
!!Aplay/Arecord output
!!--------------------
APLAY
**** List of PLAYBACK Hardware Devices ****
card 0: PCH [HDA Intel PCH], device 0: ALC883 Analog [ALC883 Analog]
Subdevices: 1/1
Subdevice #0: subdevice #0
card 0: PCH [HDA Intel PCH], device 1: ALC883 Digital [ALC883 Digital]
Subdevices: 1/1
Subdevice #0: subdevice #0
card 0: PCH [HDA Intel PCH], device 3: HDMI 0 [HDMI 0]
Subdevices: 1/1
Subdevice #0: subdevice #0
card 0: PCH [HDA Intel PCH], device 7: HDMI 1 [PG_HDMI]
Subdevices: 1/1
Subdevice #0: subdevice #0
card 0: PCH [HDA Intel PCH], device 8: HDMI 2 [HDMI 2]
Subdevices: 1/1
Subdevice #0: subdevice #0
ARECORD
**** List of CAPTURE Hardware Devices ****
card 0: PCH [HDA Intel PCH], device 0: ALC883 Analog [ALC883 Analog]
Subdevices: 1/1
Subdevice #0: subdevice #0
card 0: PCH [HDA Intel PCH], device 1: ALC883 Digital [ALC883 Digital]
Subdevices: 1/1
Subdevice #0: subdevice #0
card 0: PCH [HDA Intel PCH], device 2: ALC883 Alt Analog [ALC883 Alt Analog]
Subdevices: 1/1
Subdevice #0: subdevice #0
!!Amixer output
!!-------------
!!-------Mixer controls for card PCH
Card sysdefault:0 'PCH'/'HDA Intel PCH at 0xf7d00000 irq 30'
Mixer name : 'Realtek ALC883'
Components : 'HDA:10ec0883,10ec0883,00100002 HDA:80862805,80860101,00100000'
Controls : 80
Simple ctrls : 27
Simple mixer control 'Master',0
Capabilities: pvolume pvolume-joined pswitch pswitch-joined
Playback channels: Mono
Limits: Playback 0 - 31
Mono: Playback 25 [81%] [-9.00dB] [on]
Simple mixer control 'Headphone',0
Capabilities: pvolume pswitch
Playback channels: Front Left - Front Right
Limits: Playback 0 - 31
Mono:
Front Left: Playback 0 [0%] [-46.50dB] [off]
Front Right: Playback 0 [0%] [-46.50dB] [off]
Simple mixer control 'PCM',0
Capabilities: pvolume
Playback channels: Front Left - Front Right
Limits: Playback 0 - 255
Mono:
Front Left: Playback 254 [100%] [-0.20dB]
Front Right: Playback 254 [100%] [-0.20dB]
Simple mixer control 'Front',0
Capabilities: pvolume pswitch
Playback channels: Front Left - Front Right
Limits: Playback 0 - 31
Mono:
Front Left: Playback 31 [100%] [0.00dB] [on]
Front Right: Playback 31 [100%] [0.00dB] [on]
Simple mixer control 'Front Mic',0
Capabilities: pvolume pswitch
Playback channels: Front Left - Front Right
Limits: Playback 0 - 31
Mono:
Front Left: Playback 0 [0%] [-34.50dB] [off]
Front Right: Playback 0 [0%] [-34.50dB] [off]
Simple mixer control 'Front Mic Boost',0
Capabilities: volume
Playback channels: Front Left - Front Right
Capture channels: Front Left - Front Right
Limits: 0 - 3
Front Left: 0 [0%] [0.00dB]
Front Right: 0 [0%] [0.00dB]
Simple mixer control 'Surround',0
Capabilities: pvolume pswitch
Playback channels: Front Left - Front Right
Limits: Playback 0 - 31
Mono:
Front Left: Playback 31 [100%] [0.00dB] [on]
Front Right: Playback 31 [100%] [0.00dB] [on]
Simple mixer control 'Center',0
Capabilities: pvolume pvolume-joined pswitch pswitch-joined
Playback channels: Mono
Limits: Playback 0 - 31
Mono: Playback 31 [100%] [0.00dB] [on]
Simple mixer control 'LFE',0
Capabilities: pvolume pvolume-joined pswitch pswitch-joined
Playback channels: Mono
Limits: Playback 0 - 31
Mono: Playback 31 [100%] [0.00dB] [on]
Simple mixer control 'Side',0
Capabilities: pvolume pswitch
Playback channels: Front Left - Front Right
Limits: Playback 0 - 31
Mono:
Front Left: Playback 31 [100%] [0.00dB] [on]
Front Right: Playback 31 [100%] [0.00dB] [on]
Simple mixer control 'Line',0
Capabilities: pvolume pswitch
Playback channels: Front Left - Front Right
Limits: Playback 0 - 31
Mono:
Front Left: Playback 0 [0%] [-34.50dB] [off]
Front Right: Playback 0 [0%] [-34.50dB] [off]
Simple mixer control 'Line Boost',0
Capabilities: volume
Playback channels: Front Left - Front Right
Capture channels: Front Left - Front Right
Limits: 0 - 3
Front Left: 0 [0%] [0.00dB]
Front Right: 0 [0%] [0.00dB]
Simple mixer control 'CD',0
Capabilities: pvolume pswitch
Playback channels: Front Left - Front Right
Limits: Playback 0 - 31
Mono:
Front Left: Playback 0 [0%] [-34.50dB] [off]
Front Right: Playback 0 [0%] [-34.50dB] [off]
Simple mixer control 'IEC958',0
Capabilities: pswitch pswitch-joined cswitch cswitch-joined
Playback channels: Mono
Capture channels: Mono
Mono: Playback [off] Capture [off]
Simple mixer control 'IEC958 Default PCM',0
Capabilities: pswitch pswitch-joined
Playback channels: Mono
Mono: Playback [on]
Simple mixer control 'IEC958',1
Capabilities: pswitch pswitch-joined
Playback channels: Mono
Mono: Playback [on]
Simple mixer control 'IEC958',2
Capabilities: pswitch pswitch-joined
Playback channels: Mono
Mono: Playback [on]
Simple mixer control 'IEC958',16
Capabilities: pswitch pswitch-joined
Playback channels: Mono
Mono: Playback [on]
Simple mixer control 'Beep',0
Capabilities: pvolume pswitch
Playback channels: Front Left - Front Right
Limits: Playback 0 - 31
Mono:
Front Left: Playback 0 [0%] [-34.50dB] [off]
Front Right: Playback 0 [0%] [-34.50dB] [off]
Simple mixer control 'Capture',0
Capabilities: cvolume cswitch
Capture channels: Front Left - Front Right
Limits: Capture 0 - 31
Front Left: Capture 16 [52%] [12.00dB] [on]
Front Right: Capture 16 [52%] [12.00dB] [on]
Simple mixer control 'Capture',1
Capabilities: cvolume cswitch
Capture channels: Front Left - Front Right
Limits: Capture 0 - 31
Front Left: Capture 0 [0%] [-12.00dB] [off]
Front Right: Capture 0 [0%] [-12.00dB] [off]
Simple mixer control 'Auto-Mute Mode',0
Capabilities: enum
Items: 'Disabled' 'Enabled'
Item0: 'Enabled'
Simple mixer control 'Input Source',0
Capabilities: cenum
Items: 'Rear Mic' 'Front Mic' 'Line' 'CD'
Item0: 'Rear Mic'
Simple mixer control 'Input Source',1
Capabilities: cenum
Items: 'Rear Mic' 'Front Mic' 'Line' 'CD'
Item0: 'Rear Mic'
Simple mixer control 'Loopback Mixing',0
Capabilities: enum
Items: 'Disabled' 'Enabled'
Item0: 'Disabled'
Simple mixer control 'Rear Mic',0
Capabilities: pvolume pswitch
Playback channels: Front Left - Front Right
Limits: Playback 0 - 31
Mono:
Front Left: Playback 0 [0%] [-34.50dB] [off]
Front Right: Playback 0 [0%] [-34.50dB] [off]
Simple mixer control 'Rear Mic Boost',0
Capabilities: volume
Playback channels: Front Left - Front Right
Capture channels: Front Left - Front Right
Limits: 0 - 3
Front Left: 0 [0%] [0.00dB]
Front Right: 0 [0%] [0.00dB]
!!Alsactl output
!!--------------
--startcollapse--
state.PCH {
control.1 {
iface MIXER
name 'Front Playback Volume'
value.0 31
value.1 31
comment {
access 'read write'
type INTEGER
count 2
range '0 - 31'
dbmin -4650
dbmax 0
dbvalue.0 0
dbvalue.1 0
}
}
control.2 {
iface MIXER
name 'Front Playback Switch'
value.0 true
value.1 true
comment {
access 'read write'
type BOOLEAN
count 2
}
}
control.3 {
iface MIXER
name 'Surround Playback Volume'
value.0 31
value.1 31
comment {
access 'read write'
type INTEGER
count 2
range '0 - 31'
dbmin -4650
dbmax 0
dbvalue.0 0
dbvalue.1 0
}
}
control.4 {
iface MIXER
name 'Surround Playback Switch'
value.0 true
value.1 true
comment {
access 'read write'
type BOOLEAN
count 2
}
}
control.5 {
iface MIXER
name 'Center Playback Volume'
value 31
comment {
access 'read write'
type INTEGER
count 1
range '0 - 31'
dbmin -4650
dbmax 0
dbvalue.0 0
}
}
control.6 {
iface MIXER
name 'LFE Playback Volume'
value 31
comment {
access 'read write'
type INTEGER
count 1
range '0 - 31'
dbmin -4650
dbmax 0
dbvalue.0 0
}
}
control.7 {
iface MIXER
name 'Center Playback Switch'
value true
comment {
access 'read write'
type BOOLEAN
count 1
}
}
control.8 {
iface MIXER
name 'LFE Playback Switch'
value true
comment {
access 'read write'
type BOOLEAN
count 1
}
}
control.9 {
iface MIXER
name 'Side Playback Volume'
value.0 31
value.1 31
comment {
access 'read write'
type INTEGER
count 2
range '0 - 31'
dbmin -4650
dbmax 0
dbvalue.0 0
dbvalue.1 0
}
}
control.10 {
iface MIXER
name 'Side Playback Switch'
value.0 true
value.1 true
comment {
access 'read write'
type BOOLEAN
count 2
}
}
control.11 {
iface MIXER
name 'Headphone Playback Volume'
value.0 0
value.1 0
comment {
access 'read write'
type INTEGER
count 2
range '0 - 31'
dbmin -4650
dbmax 0
dbvalue.0 -4650
dbvalue.1 -4650
}
}
control.12 {
iface MIXER
name 'Headphone Playback Switch'
value.0 false
value.1 false
comment {
access 'read write'
type BOOLEAN
count 2
}
}
control.13 {
iface MIXER
name 'Loopback Mixing'
value Disabled
comment {
access 'read write'
type ENUMERATED
count 1
item.0 Disabled
item.1 Enabled
}
}
control.14 {
iface MIXER
name 'Rear Mic Playback Volume'
value.0 0
value.1 0
comment {
access 'read write'
type INTEGER
count 2
range '0 - 31'
dbmin -3450
dbmax 1200
dbvalue.0 -3450
dbvalue.1 -3450
}
}
control.15 {
iface MIXER
name 'Rear Mic Playback Switch'
value.0 false
value.1 false
comment {
access 'read write'
type BOOLEAN
count 2
}
}
control.16 {
iface MIXER
name 'Front Mic Playback Volume'
value.0 0
value.1 0
comment {
access 'read write'
type INTEGER
count 2
range '0 - 31'
dbmin -3450
dbmax 1200
dbvalue.0 -3450
dbvalue.1 -3450
}
}
control.17 {
iface MIXER
name 'Front Mic Playback Switch'
value.0 false
value.1 false
comment {
access 'read write'
type BOOLEAN
count 2
}
}
control.18 {
iface MIXER
name 'Line Playback Volume'
value.0 0
value.1 0
comment {
access 'read write'
type INTEGER
count 2
range '0 - 31'
dbmin -3450
dbmax 1200
dbvalue.0 -3450
dbvalue.1 -3450
}
}
control.19 {
iface MIXER
name 'Line Playback Switch'
value.0 false
value.1 false
comment {
access 'read write'
type BOOLEAN
count 2
}
}
control.20 {
iface MIXER
name 'CD Playback Volume'
value.0 0
value.1 0
comment {
access 'read write'
type INTEGER
count 2
range '0 - 31'
dbmin -3450
dbmax 1200
dbvalue.0 -3450
dbvalue.1 -3450
}
}
control.21 {
iface MIXER
name 'CD Playback Switch'
value.0 false
value.1 false
comment {
access 'read write'
type BOOLEAN
count 2
}
}
control.22 {
iface MIXER
name 'Auto-Mute Mode'
value Enabled
comment {
access 'read write'
type ENUMERATED
count 1
item.0 Disabled
item.1 Enabled
}
}
control.23 {
iface MIXER
name 'Input Source'
value 'Rear Mic'
comment {
access 'read write'
type ENUMERATED
count 1
item.0 'Rear Mic'
item.1 'Front Mic'
item.2 Line
item.3 CD
}
}
control.24 {
iface MIXER
name 'Input Source'
index 1
value 'Rear Mic'
comment {
access 'read write'
type ENUMERATED
count 1
item.0 'Rear Mic'
item.1 'Front Mic'
item.2 Line
item.3 CD
}
}
control.25 {
iface MIXER
name 'Capture Volume'
value.0 16
value.1 16
comment {
access 'read write'
type INTEGER
count 2
range '0 - 31'
dbmin -1200
dbmax 3450
dbvalue.0 1200
dbvalue.1 1200
}
}
control.26 {
iface MIXER
name 'Capture Switch'
value.0 true
value.1 true
comment {
access 'read write'
type BOOLEAN
count 2
}
}
control.27 {
iface MIXER
name 'Capture Volume'
index 1
value.0 0
value.1 0
comment {
access 'read write'
type INTEGER
count 2
range '0 - 31'
dbmin -1200
dbmax 3450
dbvalue.0 -1200
dbvalue.1 -1200
}
}
control.28 {
iface MIXER
name 'Capture Switch'
index 1
value.0 false
value.1 false
comment {
access 'read write'
type BOOLEAN
count 2
}
}
control.29 {
iface MIXER
name 'Rear Mic Boost Volume'
value.0 0
value.1 0
comment {
access 'read write'
type INTEGER
count 2
range '0 - 3'
dbmin 0
dbmax 3000
dbvalue.0 0
dbvalue.1 0
}
}
control.30 {
iface MIXER
name 'Front Mic Boost Volume'
value.0 0
value.1 0
comment {
access 'read write'
type INTEGER
count 2
range '0 - 3'
dbmin 0
dbmax 3000
dbvalue.0 0
dbvalue.1 0
}
}
control.31 {
iface MIXER
name 'Line Boost Volume'
value.0 0
value.1 0
comment {
access 'read write'
type INTEGER
count 2
range '0 - 3'
dbmin 0
dbmax 3000
dbvalue.0 0
dbvalue.1 0
}
}
control.32 {
iface MIXER
name 'Beep Playback Volume'
value.0 0
value.1 0
comment {
access 'read write'
type INTEGER
count 2
range '0 - 31'
dbmin -3450
dbmax 1200
dbvalue.0 -3450
dbvalue.1 -3450
}
}
control.33 {
iface MIXER
name 'Beep Playback Switch'
value.0 false
value.1 false
comment {
access 'read write'
type BOOLEAN
count 2
}
}
control.34 {
iface MIXER
name 'IEC958 Playback Con Mask'
index 16
value '0fff000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000'
comment {
access read
type IEC958
count 1
}
}
control.35 {
iface MIXER
name 'IEC958 Playback Pro Mask'
index 16
value '0f00000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000'
comment {
access read
type IEC958
count 1
}
}
control.36 {
iface MIXER
name 'IEC958 Playback Default'
index 16
value '0400000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000'
comment {
access 'read write'
type IEC958
count 1
}
}
control.37 {
iface MIXER
name 'IEC958 Playback Switch'
index 16
value true
comment {
access 'read write'
type BOOLEAN
count 1
}
}
control.38 {
iface MIXER
name 'IEC958 Default PCM Playback Switch'
value true
comment {
access 'read write'
type BOOLEAN
count 1
}
}
control.39 {
iface MIXER
name 'IEC958 Capture Switch'
value false
comment {
access 'read write'
type BOOLEAN
count 1
}
}
control.40 {
iface MIXER
name 'IEC958 Capture Default'
value '0400000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000'
comment {
access read
type IEC958
count 1
}
}
control.41 {
iface MIXER
name 'Master Playback Volume'
value 25
comment {
access 'read write'
type INTEGER
count 1
range '0 - 31'
dbmin -4650
dbmax 0
dbvalue.0 -900
}
}
control.42 {
iface MIXER
name 'Master Playback Switch'
value true
comment {
access 'read write'
type BOOLEAN
count 1
}
}
control.43 {
iface CARD
name 'Rear Mic Jack'
value false
comment {
access read
type BOOLEAN
count 1
}
}
control.44 {
iface CARD
name 'Front Mic Jack'
value false
comment {
access read
type BOOLEAN
count 1
}
}
control.45 {
iface CARD
name 'Line Jack'
value false
comment {
access read
type BOOLEAN
count 1
}
}
control.46 {
iface CARD
name 'CD Phantom Jack'
value true
comment {
access read
type BOOLEAN
count 1
}
}
control.47 {
iface CARD
name 'Line Out Front Jack'
value false
comment {
access read
type BOOLEAN
count 1
}
}
control.48 {
iface CARD
name 'Line Out Surround Jack'
value false
comment {
access read
type BOOLEAN
count 1
}
}
control.49 {
iface CARD
name 'Line Out CLFE Jack'
value false
comment {
access read
type BOOLEAN
count 1
}
}
control.50 {
iface CARD
name 'Line Out Side Jack'
value false
comment {
access read
type BOOLEAN
count 1
}
}
control.51 {
iface CARD
name 'Front Headphone Jack'
value false
comment {
access read
type BOOLEAN
count 1
}
}
control.52 {
iface CARD
name 'SPDIF Phantom Jack'
value true
comment {
access read
type BOOLEAN
count 1
}
}
control.53 {
iface CARD
name 'SPDIF In Phantom Jack'
value true
comment {
access read
type BOOLEAN
count 1
}
}
control.54 {
iface PCM
name 'Playback Channel Map'
value.0 0
value.1 0
value.2 0
value.3 0
value.4 0
value.5 0
value.6 0
value.7 0
comment {
access read
type INTEGER
count 8
range '0 - 36'
}
}
control.55 {
iface PCM
name 'Capture Channel Map'
value.0 0
value.1 0
comment {
access read
type INTEGER
count 2
range '0 - 36'
}
}
control.56 {
iface PCM
device 1
name 'Playback Channel Map'
value.0 0
value.1 0
comment {
access read
type INTEGER
count 2
range '0 - 36'
}
}
control.57 {
iface PCM
device 1
name 'Capture Channel Map'
value.0 0
value.1 0
comment {
access read
type INTEGER
count 2
range '0 - 36'
}
}
control.58 {
iface PCM
device 2
name 'Capture Channel Map'
value.0 0
value.1 0
comment {
access read
type INTEGER
count 2
range '0 - 36'
}
}
control.59 {
iface CARD
name 'HDMI/DP,pcm=3 Jack'
value false
comment {
access read
type BOOLEAN
count 1
}
}
control.60 {
iface MIXER
name 'IEC958 Playback Con Mask'
value '0fff000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000'
comment {
access read
type IEC958
count 1
}
}
control.61 {
iface MIXER
name 'IEC958 Playback Pro Mask'
value '0f00000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000'
comment {
access read
type IEC958
count 1
}
}
control.62 {
iface MIXER
name 'IEC958 Playback Default'
value '0400000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000'
comment {
access 'read write'
type IEC958
count 1
}
}
control.63 {
iface MIXER
name 'IEC958 Playback Switch'
value false
comment {
access 'read write'
type BOOLEAN
count 1
}
}
control.64 {
iface PCM
device 3
name ELD
value ''
comment {
access 'read volatile'
type BYTES
count 0
}
}
control.65 {
iface CARD
name 'HDMI/DP,pcm=7 Jack'
value true
comment {
access read
type BOOLEAN
count 1
}
}
control.66 {
iface MIXER
name 'IEC958 Playback Con Mask'
index 1
value '0fff000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000'
comment {
access read
type IEC958
count 1
}
}
control.67 {
iface MIXER
name 'IEC958 Playback Pro Mask'
index 1
value '0f00000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000'
comment {
access read
type IEC958
count 1
}
}
control.68 {
iface MIXER
name 'IEC958 Playback Default'
index 1
value '0482000200000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000'
comment {
access 'read write'
type IEC958
count 1
}
}
control.69 {
iface MIXER
name 'IEC958 Playback Switch'
index 1
value true
comment {
access 'read write'
type BOOLEAN
count 1
}
}
control.70 {
iface PCM
device 7
name ELD
value '100007006710000100000000000000006b5af6ff50475f48444d490907070000'
comment {
access 'read volatile'
type BYTES
count 32
}
}
control.71 {
iface CARD
name 'HDMI/DP,pcm=8 Jack'
value false
comment {
access read
type BOOLEAN
count 1
}
}
control.72 {
iface MIXER
name 'IEC958 Playback Con Mask'
index 2
value '0fff000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000'
comment {
access read
type IEC958
count 1
}
}
control.73 {
iface MIXER
name 'IEC958 Playback Pro Mask'
index 2
value '0f00000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000'
comment {
access read
type IEC958
count 1
}
}
control.74 {
iface MIXER
name 'IEC958 Playback Default'
index 2
value '0400000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000'
comment {
access 'read write'
type IEC958
count 1
}
}
control.75 {
iface MIXER
name 'IEC958 Playback Switch'
index 2
value true
comment {
access 'read write'
type BOOLEAN
count 1
}
}
control.76 {
iface PCM
device 8
name ELD
value ''
comment {
access 'read volatile'
type BYTES
count 0
}
}
control.77 {
iface PCM
device 3
name 'Playback Channel Map'
value.0 0
value.1 0
value.2 0
value.3 0
value.4 0
value.5 0
value.6 0
value.7 0
comment {
access 'read write'
type INTEGER
count 8
range '0 - 36'
}
}
control.78 {
iface PCM
device 7
name 'Playback Channel Map'
value.0 0
value.1 0
value.2 0
value.3 0
value.4 0
value.5 0
value.6 0
value.7 0
comment {
access 'read write'
type INTEGER
count 8
range '0 - 36'
}
}
control.79 {
iface PCM
device 8
name 'Playback Channel Map'
value.0 0
value.1 0
value.2 0
value.3 0
value.4 0
value.5 0
value.6 0
value.7 0
comment {
access 'read write'
type INTEGER
count 8
range '0 - 36'
}
}
control.80 {
iface MIXER
name 'PCM Playback Volume'
value.0 254
value.1 254
comment {
access 'read write user'
type INTEGER
count 2
range '0 - 255'
tlv '0000000100000008ffffec1400000014'
dbmin -5100
dbmax 0
dbvalue.0 -20
dbvalue.1 -20
}
}
}
--endcollapse--
!!All Loaded Modules
!!------------------
aesni_intel
at24
blake2b_generic
btrfs
cdc_ether
coretemp
crc32_pclmul
crc32c_generic
crc32c_intel
crct10dif_pclmul
cryptd
crypto_simd
crypto_user
fat
fuse
ghash_clmulni_intel
i2c_i801
i2c_smbus
i915
iTCO_vendor_support
iTCO_wdt
intel_cstate
intel_gtt
intel_pmc_bxt
intel_powerclamp
intel_rapl_common
intel_rapl_msr
intel_uncore
ip_tables
joydev
ledtrig_audio
libcrc32c
libphy
lpc_ich
mac_hid
mdio_devres
mei
mei_hdcp
mei_me
mii
mousedev
ns
pcspkr
qrtr
r8169
raid6_pq
rapl
realtek
rfkill
rndis_host
sg
snd
snd_hda_codec
snd_hda_codec_generic
snd_hda_codec_hdmi
snd_hda_codec_realtek
snd_hda_core
snd_hda_intel
snd_hwdep
snd_intel_dspcfg
snd_intel_sdw_acpi
snd_pcm
snd_timer
soundcore
ttm
uinput
usbhid
usbnet
vfat
video
x86_pkg_temp_thermal
x_tables
xor
!!Sysfs Files
!!-----------
/sys/class/sound/hwC0D0/init_pin_configs:
0x14 0x01014030
0x15 0x01011031
0x16 0x01016032
0x17 0x01012033
0x18 0x01a19850
0x19 0x02a19c80
0x1a 0x01813050
0x1b 0x02214c40
0x1c 0x99331150
0x1d 0x00000100
0x1e 0x01441170
0x1f 0x01c46160
/sys/class/sound/hwC0D0/driver_pin_configs:
/sys/class/sound/hwC0D0/user_pin_configs:
/sys/class/sound/hwC0D0/init_verbs:
/sys/class/sound/hwC0D0/hints:
/sys/class/sound/hwC0D3/init_pin_configs:
0x05 0x18560010
0x06 0x18560010
0x07 0x18560010
/sys/class/sound/hwC0D3/driver_pin_configs:
/sys/class/sound/hwC0D3/user_pin_configs:
/sys/class/sound/hwC0D3/init_verbs:
/sys/class/sound/hwC0D3/hints:
!!ALSA/HDA dmesg
!!--------------
[ 0.155992] ACPI: Added _OSI(Linux-Dell-Video)
[ 0.155992] ACPI: Added _OSI(Linux-Lenovo-NV-HDMI-Audio)
[ 0.155992] ACPI: Added _OSI(Linux-HPI-Hybrid-Graphics)
--
[ 3.167949] AES CTR mode by8 optimization enabled
[ 3.177865] snd_hda_intel 0000:00:1b.0: enabling device (0000 -> 0002)
[ 3.217267] i915 0000:00:02.0: vgaarb: deactivate vga console
--
[ 3.238682] input: Video Bus as /devices/LNXSYSTM:00/LNXSYBUS:00/PNP0A08:00/LNXVIDEO:00/input/input7
[ 3.238754] snd_hda_intel 0000:00:1b.0: bound 0000:00:02.0 (ops i915_audio_component_bind_ops [i915])
[ 3.355609] fbcon: i915drmfb (fb0) is primary device
--
[ 3.355615] i915 0000:00:02.0: [drm] fb0: i915drmfb frame buffer device
[ 3.408143] snd_hda_codec_realtek hdaudioC0D0: autoconfig for ALC883: line_outs=4 (0x14/0x16/0x15/0x17/0x0) type:line
[ 3.408149] snd_hda_codec_realtek hdaudioC0D0: speaker_outs=0 (0x0/0x0/0x0/0x0/0x0)
[ 3.408151] snd_hda_codec_realtek hdaudioC0D0: hp_outs=1 (0x1b/0x0/0x0/0x0/0x0)
[ 3.408153] snd_hda_codec_realtek hdaudioC0D0: mono: mono_out=0x0
[ 3.408154] snd_hda_codec_realtek hdaudioC0D0: dig-out=0x1e/0x0
[ 3.408155] snd_hda_codec_realtek hdaudioC0D0: inputs:
[ 3.408156] snd_hda_codec_realtek hdaudioC0D0: Rear Mic=0x18
[ 3.408158] snd_hda_codec_realtek hdaudioC0D0: Front Mic=0x19
[ 3.408159] snd_hda_codec_realtek hdaudioC0D0: Line=0x1a
[ 3.408160] snd_hda_codec_realtek hdaudioC0D0: CD=0x1c
[ 3.408161] snd_hda_codec_realtek hdaudioC0D0: dig-in=0x1f
[ 3.426616] BTRFS info (device sdb1): flagging fs with big metadata feature
--
[ 3.452313] random: crng init done
[ 3.462253] input: HDA Intel PCH Rear Mic as /devices/pci0000:00/0000:00:1b.0/sound/card0/input8
[ 3.465464] input: HDA Intel PCH Front Mic as /devices/pci0000:00/0000:00:1b.0/sound/card0/input9
[ 3.465525] input: HDA Intel PCH Line as /devices/pci0000:00/0000:00:1b.0/sound/card0/input10
[ 3.465580] input: HDA Intel PCH Line Out Front as /devices/pci0000:00/0000:00:1b.0/sound/card0/input11
[ 3.465629] input: HDA Intel PCH Line Out Surround as /devices/pci0000:00/0000:00:1b.0/sound/card0/input12
[ 3.469474] input: HDA Intel PCH Line Out CLFE as /devices/pci0000:00/0000:00:1b.0/sound/card0/input13
[ 3.472768] input: HDA Intel PCH Line Out Side as /devices/pci0000:00/0000:00:1b.0/sound/card0/input14
[ 3.472836] input: HDA Intel PCH Front Headphone as /devices/pci0000:00/0000:00:1b.0/sound/card0/input15
[ 3.472885] input: HDA Intel PCH HDMI/DP,pcm=3 as /devices/pci0000:00/0000:00:1b.0/sound/card0/input16
[ 3.472927] input: HDA Intel PCH HDMI/DP,pcm=7 as /devices/pci0000:00/0000:00:1b.0/sound/card0/input17
[ 3.472979] input: HDA Intel PCH HDMI/DP,pcm=8 as /devices/pci0000:00/0000:00:1b.0/sound/card0/input18
[ 3.504785] audit: type=1130 audit(1661738352.685:5): pid=1 uid=0 auid=4294967295 ses=4294967295 msg='unit=systemd-random-seed comm="systemd" exe="/usr/lib/systemd/systemd" hostname=? addr=? terminal=? res=success'
Sorry about any gramatical errors, English is not my native language.
