How to get cpu temperature with ryzen 4800h?

Support
, ,
1

Hi my laptop is ryzen 4800h with lenovo.

I installed lm_sensors but cannot detect any cpu temperature sensor.

So how could I get my cpu temperature detected…

$ sudo sensors-detect
[sudo] shore 的密码：
# sensors-detect version 3.6.0
# System: LENOVO 82B6 [Lenovo Legion R7000 2020] (laptop)
# Board: LENOVO LNVNB161216
# Kernel: 5.8.6-1-MANJARO x86_64
# Processor: AMD Ryzen 7 4800H with Radeon Graphics (23/96/1)

This program will help you determine which kernel modules you need
to load to use lm_sensors most effectively. It is generally safe
and recommended to accept the default answers to all questions,
unless you know what you're doing.

Some south bridges, CPUs or memory controllers contain embedded sensors.
Do you want to scan for them? This is totally safe. (YES/no): yes
Silicon Integrated Systems SIS5595...                       No
VIA VT82C686 Integrated Sensors...                          No
VIA VT8231 Integrated Sensors...                            No
AMD K8 thermal sensors...                                   No
AMD Family 10h thermal sensors...                           No
AMD Family 11h thermal sensors...                           No
AMD Family 12h and 14h thermal sensors...                   No
AMD Family 15h thermal sensors...                           No
AMD Family 16h thermal sensors...                           No
AMD Family 17h thermal sensors...                           No
AMD Family 15h power sensors...                             No
AMD Family 16h power sensors...                             No
Hygon Family 18h thermal sensors...                         No
Intel digital thermal sensor...                             No
Intel AMB FB-DIMM thermal sensor...                         No
Intel 5500/5520/X58 thermal sensor...                       No
VIA C7 thermal sensor...                                    No
VIA Nano thermal sensor...                                  No

Here is my system spec:

[shore@shore-82b6 ~]$ inxi -Fxxx
System:
  Host: shore-82b6 Kernel: 5.8.6-1-MANJARO x86_64 bits: 64 compiler: N/A
  Desktop: Xfce 4.14.2 tk: Gtk 3.24.20 info: xfce4-panel wm: xfwm4
  dm: LightDM 1.30.0 Distro: Manjaro Linux
Machine:
  Type: Laptop System: LENOVO product: 82B6 v: Lenovo Legion R7000 2020
  serial: <superuser/root required> Chassis: type: 10
  v: Lenovo Legion R7000 2020 serial: <superuser/root required>
  Mobo: LENOVO model: LNVNB161216 v: SDK0L77769 WIN
  serial: <superuser/root required> UEFI: LENOVO v: EUCN18WW
  date: 04/27/2020
Battery:
  ID-1: BAT0 charge: 58.0 Wh condition: 59.2/60.0 Wh (99%) volts: 17.2/15.4
  model: Celxpert L19C4PC0 type: Li-poly serial: 4751 status: Unknown
  cycles: 9
  ID-2: hidpp_battery_0 charge: N/A condition: N/A volts: 4.1/N/A
  model: Logitech G903 LIGHTSPEED Wireless Gaming Mouse w/ HERO type: N/A
  serial: 4087-ad-46-38-99 status: Discharging
CPU:
  Topology: 8-Core model: AMD Ryzen 7 4800H with Radeon Graphics bits: 64
  type: MT MCP arch: Zen rev: 1 L2 cache: 4096 KiB
  flags: avx avx2 lm nx pae sse sse2 sse3 sse4_1 sse4_2 sse4a ssse3 svm
  bogomips: 92671
  Speed: 3162 MHz min/max: 1400/2900 MHz boost: enabled Core speeds (MHz):
  1: 1523 2: 1441 3: 1899 4: 4296 5: 1477 6: 1906 7: 1908 8: 1907 9: 1397
  10: 3554 11: 1907 12: 1909 13: 1597 14: 4290 15: 1906 16: 1907
Graphics:
  Device-1: NVIDIA TU117M vendor: Lenovo driver: nvidia v: 450.66
  bus ID: 01:00.0 chip ID: 10de:1f99
  Device-2: IMC Networks Integrated Camera type: USB driver: uvcvideo
  bus ID: 1-3:2 chip ID: 13d3:56ff
  Display: x11 server: X.Org 1.20.8 driver: nvidia resolution:
  1: 1920x1080~60Hz 2: 1920x1080~60Hz s-dpi: 143
  OpenGL: renderer: GeForce GTX 1650/PCIe/SSE2 v: 4.6.0 NVIDIA 450.66
  direct render: Yes
Audio:
  Device-1: NVIDIA driver: snd_hda_intel v: kernel bus ID: 01:00.1
  chip ID: 10de:10fa
  Device-2: AMD Raven/Raven2/FireFlight/Renoir Audio Processor
  vendor: Lenovo driver: snd_rn_pci_acp3x v: kernel bus ID: 06:00.5
  chip ID: 1022:15e2
  Device-3: AMD Family 17h HD Audio vendor: Lenovo driver: snd_hda_intel
  v: kernel bus ID: 06:00.6 chip ID: 1022:15e3
  Sound Server: ALSA v: k5.8.6-1-MANJARO
Network:
  Device-1: Realtek RTL8111/8168/8411 PCI Express Gigabit Ethernet
  vendor: Lenovo driver: r8169 v: kernel port: 1000 bus ID: 03:00.0
  chip ID: 10ec:8168
  IF: eno1 state: down mac: 00:2b:67:2c:2a:d1
  Device-2: Intel Wi-Fi 6 AX200 driver: iwlwifi v: kernel port: 1000
  bus ID: 04:00.0 chip ID: 8086:2723
  IF: wlp4s0 state: up mac: f8:e4:e3:d5:8d:a6
  IF-ID-1: tun0 state: unknown speed: 10 Mbps duplex: full mac: N/A
Drives:
  Local Storage: total: 465.76 GiB used: 38.60 GiB (8.3%)
  ID-1: /dev/nvme0n1 vendor: Samsung model: MZVLB512HBJQ-000L2
  size: 476.94 GiB speed: 31.6 Gb/s lanes: 4 serial: S4DYNF0N130294
  rev: 3L1QEXF7 scheme: GPT
  ID-2: /dev/nvme1n1 vendor: Western Digital model: WDS500G3X0C-00SJG0
  size: 465.76 GiB speed: 31.6 Gb/s lanes: 4 serial: 191729803490
  rev: 102000WD scheme: GPT
Partition:
  ID-1: / size: 457.16 GiB used: 38.60 GiB (8.4%) fs: ext4
  dev: /dev/nvme1n1p2
Swap:
  Alert: No Swap data was found.
Sensors:
  System Temperatures: cpu: 56.8 C mobo: N/A gpu: nvidia temp: 47 C
  Fan Speeds (RPM): N/A
Info:
  Processes: 374 Uptime: 12m Memory: 30.74 GiB used: 5.35 GiB (17.4%)
  Init: systemd v: 246 Compilers: gcc: 10.2.0 Packages: pacman: 1182
  Shell: Bash v: 5.0.18 running in: xfce4-terminal inxi: 3.1.05
2

There’s more sensors to test than you listed. Did you answer y for all of the prompts?

3

What’s this then?

Type in sensors. There should be a sensor k10temp showing Tdie, which is the cpu temp.

Kernel has built in support for renoir temp sensor since 5.8. sensors-detect not needed.

https://www.phoronix.com/scan.php?page=news_item&px=AMD-Renoir-k10temp-Linux-5.8

2 Likes
4

Yep of course, the following is the full output:

$ sudo sensors-detect
[sudo] shore 的密码：
对不起，请重试。
[sudo] shore 的密码：
# sensors-detect version 3.6.0
# System: LENOVO 82B6 [Lenovo Legion R7000 2020] (laptop)
# Board: LENOVO LNVNB161216
# Kernel: 5.8.6-1-MANJARO x86_64
# Processor: AMD Ryzen 7 4800H with Radeon Graphics (23/96/1)

This program will help you determine which kernel modules you need
to load to use lm_sensors most effectively. It is generally safe
and recommended to accept the default answers to all questions,
unless you know what you're doing.

Some south bridges, CPUs or memory controllers contain embedded sensors.
Do you want to scan for them? This is totally safe. (YES/no): YES
Module cpuid loaded successfully.
Silicon Integrated Systems SIS5595...                       No
VIA VT82C686 Integrated Sensors...                          No
VIA VT8231 Integrated Sensors...                            No
AMD K8 thermal sensors...                                   No
AMD Family 10h thermal sensors...                           No
AMD Family 11h thermal sensors...                           No
AMD Family 12h and 14h thermal sensors...                   No
AMD Family 15h thermal sensors...                           No
AMD Family 16h thermal sensors...                           No
AMD Family 17h thermal sensors...                           No
AMD Family 15h power sensors...                             No
AMD Family 16h power sensors...                             No
Hygon Family 18h thermal sensors...                         No
Intel digital thermal sensor...                             No
Intel AMB FB-DIMM thermal sensor...                         No
Intel 5500/5520/X58 thermal sensor...                       No
VIA C7 thermal sensor...                                    No
VIA Nano thermal sensor...                                  No

Some Super I/O chips contain embedded sensors. We have to write to
standard I/O ports to probe them. This is usually safe.
Do you want to scan for Super I/O sensors? (YES/no): YES
Probing for Super-I/O at 0x2e/0x2f
Trying family `National Semiconductor/ITE'...               No
Trying family `SMSC'...                                     No
Trying family `VIA/Winbond/Nuvoton/Fintek'...               No
Trying family `ITE'...                                      No
Probing for Super-I/O at 0x4e/0x4f
Trying family `National Semiconductor/ITE'...               Yes
Found unknown chip with ID 0x8227

Some hardware monitoring chips are accessible through the ISA I/O ports.
We have to write to arbitrary I/O ports to probe them. This is usually
safe though. Yes, you do have ISA I/O ports even if you do not have any
ISA slots! Do you want to scan the ISA I/O ports? (YES/no): YES
Probing for `National Semiconductor LM78' at 0x290...       No
Probing for `National Semiconductor LM79' at 0x290...       No
Probing for `Winbond W83781D' at 0x290...                   No
Probing for `Winbond W83782D' at 0x290...                   No

Lastly, we can probe the I2C/SMBus adapters for connected hardware
monitoring devices. This is the most risky part, and while it works
reasonably well on most systems, it has been reported to cause trouble
on some systems.
Do you want to probe the I2C/SMBus adapters now? (YES/no): YES
Using driver `i2c-piix4' for device 0000:00:14.0: AMD KERNCZ SMBus
Module i2c-dev loaded successfully.

Next adapter: Synopsys DesignWare I2C adapter (i2c-0)
Do you want to scan it? (YES/no/selectively): YES
Adapter doesn't support all probing functions.
Some addresses won't be probed.

Next adapter: SMBus PIIX4 adapter port 0 at 0b00 (i2c-1)
Do you want to scan it? (YES/no/selectively): YES
Client found at address 0x50
Probing for `Analog Devices ADM1033'...                     No
Probing for `Analog Devices ADM1034'...                     No
Probing for `SPD EEPROM'...                                 Yes
    (confidence 8, not a hardware monitoring chip)
Probing for `EDID EEPROM'...                                No
Client found at address 0x52
Probing for `Analog Devices ADM1033'...                     No
Probing for `Analog Devices ADM1034'...                     No
Probing for `SPD EEPROM'...                                 Yes
    (confidence 8, not a hardware monitoring chip)

Next adapter: SMBus PIIX4 adapter port 2 at 0b00 (i2c-2)
Do you want to scan it? (YES/no/selectively): YES

Next adapter: SMBus PIIX4 adapter port 1 at 0b20 (i2c-3)
Do you want to scan it? (YES/no/selectively): YES
Client found at address 0x18
Probing for `Analog Devices ADM1021'...                     No
Probing for `Analog Devices ADM1021A/ADM1023'...            No
Probing for `Maxim MAX1617'...                              No
Probing for `Maxim MAX1617A'...                             No
Probing for `Maxim MAX1668'...                              No
Probing for `Maxim MAX1805'...                              No
Probing for `Maxim MAX1989'...                              No
Probing for `Maxim MAX6655/MAX6656'...                      No
Probing for `TI THMC10'...                                  No
Probing for `National Semiconductor LM84'...                No
Probing for `Genesys Logic GL523SM'...                      No
Probing for `Onsemi MC1066'...                              No
Probing for `Maxim MAX1618'...                              No
Probing for `Maxim MAX1619'...                              No
Probing for `National Semiconductor LM82/LM83'...           No
Probing for `Maxim MAX6654'...                              No
Probing for `Maxim MAX6690'...                              No
Probing for `Maxim MAX6680/MAX6681'...                      No
Probing for `Maxim MAX6695/MAX6696'...                      No
Probing for `Texas Instruments TMP400'...                   No
Probing for `Texas Instruments AMC6821'...                  No
Probing for `National Semiconductor LM95233'...             No
Probing for `National Semiconductor LM95234'...             No
Probing for `National Semiconductor LM95235'...             No
Probing for `National Semiconductor LM95245'...             No
Probing for `National Semiconductor LM64'...                No
Probing for `SMSC EMC1047'...                               No
Probing for `SMSC EMC1402'...                               No
Probing for `SMSC EMC1403'...                               No
Probing for `SMSC EMC1404'...                               No
Probing for `ST STTS424'...                                 No
Probing for `ST STTS424E'...                                No
Probing for `ST STTS2002'...                                No
Probing for `ST STTS3000'...                                No
Probing for `NXP SE97/SE97B'...                             No
Probing for `NXP SE98'...                                   No
Probing for `Analog Devices ADT7408'...                     No
Probing for `IDT TS3000/TSE2002'...                         No
Probing for `IDT TSE2004'...                                No
Probing for `IDT TS3001'...                                 No
Probing for `Maxim MAX6604'...                              No
Probing for `Microchip MCP9804'...                          No
Probing for `Microchip MCP9808'...                          No
Probing for `Microchip MCP98242'...                         No
Probing for `Microchip MCP98243'...                         No
Probing for `Microchip MCP98244'...                         No
Probing for `Microchip MCP9843'...                          No
Probing for `ON CAT6095/CAT34TS02'...                       No
Probing for `ON CAT34TS02C'...                              No
Probing for `ON CAT34TS04'...                               No
Probing for `Atmel AT30TS00'...                             No
Probing for `Giantec GT30TS00'...                           No
Client found at address 0x19
Probing for `Analog Devices ADM1021'...                     No
Probing for `Analog Devices ADM1021A/ADM1023'...            No
Probing for `Maxim MAX1617'...                              No
Probing for `Maxim MAX1617A'...                             No
Probing for `Maxim MAX1668'...                              No
Probing for `Maxim MAX1805'...                              No
Probing for `Maxim MAX1989'...                              No
Probing for `Maxim MAX6655/MAX6656'...                      No
Probing for `TI THMC10'...                                  No
Probing for `National Semiconductor LM84'...                No
Probing for `Genesys Logic GL523SM'...                      No
Probing for `Onsemi MC1066'...                              No
Probing for `Maxim MAX1618'...                              No
Probing for `Maxim MAX1619'...                              No
Probing for `National Semiconductor LM82/LM83'...           No
Probing for `Maxim MAX6654'...                              No
Probing for `Maxim MAX6690'...                              No
Probing for `Maxim MAX6680/MAX6681'...                      No
Probing for `Maxim MAX6695/MAX6696'...                      No
Probing for `Texas Instruments TMP400'...                   No
Probing for `Texas Instruments AMC6821'...                  No
Probing for `National Semiconductor LM95231'...             No
Probing for `National Semiconductor LM95241'...             No
Probing for `National Semiconductor LM95245'...             No
Probing for `ST STTS424'...                                 No
Probing for `ST STTS424E'...                                No
Probing for `ST STTS2002'...                                No
Probing for `ST STTS3000'...                                No
Probing for `NXP SE97/SE97B'...                             No
Probing for `NXP SE98'...                                   No
Probing for `Analog Devices ADT7408'...                     No
Probing for `IDT TS3000/TSE2002'...                         No
Probing for `IDT TSE2004'...                                No
Probing for `IDT TS3001'...                                 No
Probing for `Maxim MAX6604'...                              No
Probing for `Microchip MCP9804'...                          No
Probing for `Microchip MCP9808'...                          No
Probing for `Microchip MCP98242'...                         No
Probing for `Microchip MCP98243'...                         No
Probing for `Microchip MCP98244'...                         No
Probing for `Microchip MCP9843'...                          No
Probing for `ON CAT6095/CAT34TS02'...                       No
Probing for `ON CAT34TS02C'...                              No
Probing for `ON CAT34TS04'...                               No
Probing for `Atmel AT30TS00'...                             No
Probing for `Giantec GT30TS00'...                           No
Client found at address 0x1a
Probing for `Analog Devices ADM1021'...                     No
Probing for `Analog Devices ADM1021A/ADM1023'...            No
Probing for `Maxim MAX1617'...                              No
Probing for `Maxim MAX1617A'...                             No
Probing for `Maxim MAX1668'...                              No
Probing for `Maxim MAX1805'...                              No
Probing for `Maxim MAX1989'...                              No
Probing for `Maxim MAX6655/MAX6656'...                      No
Probing for `TI THMC10'...                                  No
Probing for `National Semiconductor LM84'...                No
Probing for `Genesys Logic GL523SM'...                      No
Probing for `Onsemi MC1066'...                              No
Probing for `Maxim MAX1618'...                              No
Probing for `Maxim MAX1619'...                              No
Probing for `National Semiconductor LM82/LM83'...           No
Probing for `Maxim MAX6654'...                              No
Probing for `Maxim MAX6690'...                              No
Probing for `Maxim MAX6680/MAX6681'...                      No
Probing for `Maxim MAX6695/MAX6696'...                      No
Probing for `Texas Instruments TMP400'...                   No
Probing for `Texas Instruments AMC6821'...                  No
Probing for `ST STTS424'...                                 No
Probing for `ST STTS424E'...                                No
Probing for `ST STTS2002'...                                No
Probing for `ST STTS3000'...                                No
Probing for `NXP SE97/SE97B'...                             No
Probing for `NXP SE98'...                                   No
Probing for `Analog Devices ADT7408'...                     No
Probing for `IDT TS3000/TSE2002'...                         No
Probing for `IDT TSE2004'...                                No
Probing for `IDT TS3001'...                                 No
Probing for `Maxim MAX6604'...                              No
Probing for `Microchip MCP9804'...                          No
Probing for `Microchip MCP9808'...                          No
Probing for `Microchip MCP98242'...                         No
Probing for `Microchip MCP98243'...                         No
Probing for `Microchip MCP98244'...                         No
Probing for `Microchip MCP9843'...                          No
Probing for `ON CAT6095/CAT34TS02'...                       No
Probing for `ON CAT34TS02C'...                              No
Probing for `ON CAT34TS04'...                               No
Probing for `Atmel AT30TS00'...                             No
Probing for `Giantec GT30TS00'...                           No
Client found at address 0x1b
Probing for `ST STTS424'...                                 No
Probing for `ST STTS424E'...                                No
Probing for `ST STTS2002'...                                No
Probing for `ST STTS3000'...                                No
Probing for `NXP SE97/SE97B'...                             No
Probing for `NXP SE98'...                                   No
Probing for `Analog Devices ADT7408'...                     No
Probing for `IDT TS3000/TSE2002'...                         No
Probing for `IDT TSE2004'...                                No
Probing for `IDT TS3001'...                                 No
Probing for `Maxim MAX6604'...                              No
Probing for `Microchip MCP9804'...                          No
Probing for `Microchip MCP9808'...                          No
Probing for `Microchip MCP98242'...                         No
Probing for `Microchip MCP98243'...                         No
Probing for `Microchip MCP98244'...                         No
Probing for `Microchip MCP9843'...                          No
Probing for `ON CAT6095/CAT34TS02'...                       No
Probing for `ON CAT34TS02C'...                              No
Probing for `ON CAT34TS04'...                               No
Probing for `Atmel AT30TS00'...                             No
Probing for `Giantec GT30TS00'...                           No
Client found at address 0x1c
Probing for `Texas Instruments TMP421'...                   No
Probing for `Texas Instruments TMP441'...                   No
Probing for `SMSC EMC1072'...                               No
Probing for `SMSC EMC1073'...                               No
Probing for `SMSC EMC1074'...                               No
Probing for `ST STTS424'...                                 No
Probing for `ST STTS424E'...                                No
Probing for `ST STTS2002'...                                No
Probing for `ST STTS3000'...                                No
Probing for `NXP SE97/SE97B'...                             No
Probing for `NXP SE98'...                                   No
Probing for `Analog Devices ADT7408'...                     No
Probing for `IDT TS3000/TSE2002'...                         No
Probing for `IDT TSE2004'...                                No
Probing for `IDT TS3001'...                                 No
Probing for `Maxim MAX6604'...                              No
Probing for `Microchip MCP9804'...                          No
Probing for `Microchip MCP9808'...                          No
Probing for `Microchip MCP98242'...                         No
Probing for `Microchip MCP98243'...                         No
Probing for `Microchip MCP98244'...                         No
Probing for `Microchip MCP9843'...                          No
Probing for `ON CAT6095/CAT34TS02'...                       No
Probing for `ON CAT34TS02C'...                              No
Probing for `ON CAT34TS04'...                               No
Probing for `Atmel AT30TS00'...                             No
Probing for `Giantec GT30TS00'...                           No
Client found at address 0x1d
Probing for `TI / National Semiconductor ADC128D818'...     No
Probing for `Texas Instruments TMP421'...                   No
Probing for `Texas Instruments TMP441'...                   No
Probing for `ST STTS424'...                                 No
Probing for `ST STTS424E'...                                No
Probing for `ST STTS2002'...                                No
Probing for `ST STTS3000'...                                No
Probing for `NXP SE97/SE97B'...                             No
Probing for `NXP SE98'...                                   No
Probing for `Analog Devices ADT7408'...                     No
Probing for `IDT TS3000/TSE2002'...                         No
Probing for `IDT TSE2004'...                                No
Probing for `IDT TS3001'...                                 No
Probing for `Maxim MAX6604'...                              No
Probing for `Microchip MCP9804'...                          No
Probing for `Microchip MCP9808'...                          No
Probing for `Microchip MCP98242'...                         No
Probing for `Microchip MCP98243'...                         No
Probing for `Microchip MCP98244'...                         No
Probing for `Microchip MCP9843'...                          No
Probing for `ON CAT6095/CAT34TS02'...                       No
Probing for `ON CAT34TS02C'...                              No
Probing for `ON CAT34TS04'...                               No
Probing for `Atmel AT30TS00'...                             No
Probing for `Giantec GT30TS00'...                           No
Client found at address 0x1e
Probing for `TI / National Semiconductor ADC128D818'...     No
Probing for `Texas Instruments TMP421'...                   No
Probing for `Texas Instruments TMP441'...                   No
Probing for `ST STTS424'...                                 No
Probing for `ST STTS424E'...                                No
Probing for `ST STTS2002'...                                No
Probing for `ST STTS3000'...                                No
Probing for `NXP SE97/SE97B'...                             No
Probing for `NXP SE98'...                                   No
Probing for `Analog Devices ADT7408'...                     No
Probing for `IDT TS3000/TSE2002'...                         No
Probing for `IDT TSE2004'...                                No
Probing for `IDT TS3001'...                                 No
Probing for `Maxim MAX6604'...                              No
Probing for `Microchip MCP9804'...                          No
Probing for `Microchip MCP9808'...                          No
Probing for `Microchip MCP98242'...                         No
Probing for `Microchip MCP98243'...                         No
Probing for `Microchip MCP98244'...                         No
Probing for `Microchip MCP9843'...                          No
Probing for `ON CAT6095/CAT34TS02'...                       No
Probing for `ON CAT34TS02C'...                              No
Probing for `ON CAT34TS04'...                               No
Probing for `Atmel AT30TS00'...                             No
Probing for `Giantec GT30TS00'...                           No
Client found at address 0x1f
Probing for `TI / National Semiconductor ADC128D818'...     No
Probing for `Texas Instruments TMP421'...                   No
Probing for `Texas Instruments TMP441'...                   No
Probing for `ST STTS424'...                                 No
Probing for `ST STTS424E'...                                No
Probing for `ST STTS2002'...                                No
Probing for `ST STTS3000'...                                No
Probing for `NXP SE97/SE97B'...                             No
Probing for `NXP SE98'...                                   No
Probing for `Analog Devices ADT7408'...                     No
Probing for `IDT TS3000/TSE2002'...                         No
Probing for `IDT TSE2004'...                                No
Probing for `IDT TS3001'...                                 No
Probing for `Maxim MAX6604'...                              No
Probing for `Microchip MCP9804'...                          No
Probing for `Microchip MCP9808'...                          No
Probing for `Microchip MCP98242'...                         No
Probing for `Microchip MCP98243'...                         No
Probing for `Microchip MCP98244'...                         No
Probing for `Microchip MCP9843'...                          No
Probing for `ON CAT6095/CAT34TS02'...                       No
Probing for `ON CAT34TS02C'...                              No
Probing for `ON CAT34TS04'...                               No
Probing for `Atmel AT30TS00'...                             No
Probing for `Giantec GT30TS00'...                           No
Client found at address 0x28
Probing for `National Semiconductor LM78'...                No
Probing for `National Semiconductor LM79'...                No
Probing for `National Semiconductor LM80'...                No
Probing for `National Semiconductor LM96080'...             No
Probing for `Winbond W83781D'...                            No
Probing for `Winbond W83782D'...                            No
Probing for `Nuvoton NCT7802Y'...                           No
Probing for `Winbond W83627HF'...                           No
Probing for `Winbond W83627EHF'...                          No
Probing for `Winbond W83627DHG/W83667HG/W83677HG'...        No
Probing for `Asus AS99127F (rev.1)'...                      No
Probing for `Asus AS99127F (rev.2)'...                      No
Probing for `Asus ASB100 Bach'...                           No
Probing for `Analog Devices ADM1029'...                     No
Probing for `ITE IT8712F'...                                No
Client found at address 0x29
Probing for `National Semiconductor LM78'...                No
Probing for `National Semiconductor LM79'...                No
Probing for `National Semiconductor LM80'...                No
Probing for `National Semiconductor LM96080'...             No
Probing for `Winbond W83781D'...                            No
Probing for `Winbond W83782D'...                            No
Probing for `Nuvoton NCT7802Y'...                           No
Probing for `Winbond W83627HF'...                           No
Probing for `Winbond W83627EHF'...                          No
Probing for `Winbond W83627DHG/W83667HG/W83677HG'...        No
Probing for `Asus AS99127F (rev.1)'...                      No
Probing for `Asus AS99127F (rev.2)'...                      No
Probing for `Asus ASB100 Bach'...                           No
Probing for `Analog Devices ADM1021'...                     No
Probing for `Analog Devices ADM1021A/ADM1023'...            No
Probing for `Maxim MAX1617'...                              No
Probing for `Maxim MAX1617A'...                             No
Probing for `Maxim MAX1668'...                              No
Probing for `Maxim MAX1805'...                              No
Probing for `Maxim MAX1989'...                              No
Probing for `Maxim MAX6655/MAX6656'...                      No
Probing for `TI THMC10'...                                  No
Probing for `National Semiconductor LM84'...                No
Probing for `Genesys Logic GL523SM'...                      No
Probing for `Onsemi MC1066'...                              No
Probing for `Maxim MAX1618'...                              No
Probing for `Maxim MAX1619'...                              No
Probing for `National Semiconductor LM82/LM83'...           No
Probing for `Maxim MAX6654'...                              No
Probing for `Maxim MAX6690'...                              No
Probing for `Maxim MAX6680/MAX6681'...                      No
Probing for `Maxim MAX6695/MAX6696'...                      No
Probing for `Texas Instruments TMP400'...                   No
Probing for `National Semiconductor LM95235'...             No
Probing for `National Semiconductor LM95245'...             No
Probing for `Analog Devices ADM1029'...                     No
Probing for `ITE IT8712F'...                                No
Probing for `SMSC EMC1402'...                               No
Probing for `SMSC EMC1403'...                               No
Probing for `SMSC EMC1404'...                               No
Client found at address 0x2a
Probing for `National Semiconductor LM78'...                No
Probing for `National Semiconductor LM79'...                No
Probing for `National Semiconductor LM80'...                No
Probing for `National Semiconductor LM96080'...             No
Probing for `Winbond W83781D'...                            No
Probing for `Winbond W83782D'...                            No
Probing for `Nuvoton NCT7802Y'...                           No
Probing for `Winbond W83627HF'...                           No
Probing for `Winbond W83627EHF'...                          No
Probing for `Winbond W83627DHG/W83667HG/W83677HG'...        No
Probing for `Asus AS99127F (rev.1)'...                      No
Probing for `Asus AS99127F (rev.2)'...                      No
Probing for `Asus ASB100 Bach'...                           No
Probing for `Analog Devices ADM1021'...                     No
Probing for `Analog Devices ADM1021A/ADM1023'...            No
Probing for `Maxim MAX1617'...                              No
Probing for `Maxim MAX1617A'...                             No
Probing for `Maxim MAX1668'...                              No
Probing for `Maxim MAX1805'...                              No
Probing for `Maxim MAX1989'...                              No
Probing for `Maxim MAX6655/MAX6656'...                      No
Probing for `TI THMC10'...                                  No
Probing for `National Semiconductor LM84'...                No
Probing for `Genesys Logic GL523SM'...                      No
Probing for `Onsemi MC1066'...                              No
Probing for `Maxim MAX1618'...                              No
Probing for `Maxim MAX1619'...                              No
Probing for `National Semiconductor LM82/LM83'...           No
Probing for `Maxim MAX6654'...                              No
Probing for `Maxim MAX6690'...                              No
Probing for `Maxim MAX6680/MAX6681'...                      No
Probing for `Maxim MAX6695/MAX6696'...                      No
Probing for `Texas Instruments TMP400'...                   No
Probing for `Texas Instruments TMP421'...                   No
Probing for `Texas Instruments TMP441'...                   No
Probing for `National Semiconductor LM95231'...             No
Probing for `National Semiconductor LM95233'...             No
Probing for `National Semiconductor LM95241'...             No
Probing for `Analog Devices ADM1029'...                     No
Probing for `ITE IT8712F'...                                No
Client found at address 0x2b
Probing for `National Semiconductor LM78'...                No
Probing for `National Semiconductor LM79'...                No
Probing for `National Semiconductor LM80'...                No
Probing for `National Semiconductor LM96080'...             No
Probing for `Winbond W83781D'...                            No
Probing for `Winbond W83782D'...                            No
Probing for `Nuvoton NCT7802Y'...                           No
Probing for `Winbond W83627HF'...                           No
Probing for `Winbond W83627EHF'...                          No
Probing for `Winbond W83627DHG/W83667HG/W83677HG'...        No
Probing for `Asus AS99127F (rev.1)'...                      No
Probing for `Asus AS99127F (rev.2)'...                      No
Probing for `Asus ASB100 Bach'...                           No
Probing for `Analog Devices ADM1021'...                     No
Probing for `Analog Devices ADM1021A/ADM1023'...            No
Probing for `Maxim MAX1617'...                              No
Probing for `Maxim MAX1617A'...                             No
Probing for `Maxim MAX1668'...                              No
Probing for `Maxim MAX1805'...                              No
Probing for `Maxim MAX1989'...                              No
Probing for `Maxim MAX6655/MAX6656'...                      No
Probing for `TI THMC10'...                                  No
Probing for `National Semiconductor LM84'...                No
Probing for `Genesys Logic GL523SM'...                      No
Probing for `Onsemi MC1066'...                              No
Probing for `Maxim MAX1618'...                              No
Probing for `Maxim MAX1619'...                              No
Probing for `National Semiconductor LM82/LM83'...           No
Probing for `Maxim MAX6654'...                              No
Probing for `Maxim MAX6690'...                              No
Probing for `Maxim MAX6680/MAX6681'...                      No
Probing for `Maxim MAX6695/MAX6696'...                      No
Probing for `Texas Instruments TMP400'...                   No
Probing for `National Semiconductor LM95231'...             No
Probing for `National Semiconductor LM95233'...             No
Probing for `National Semiconductor LM95241'...             No
Probing for `Analog Devices ADM1029'...                     No
Probing for `ITE IT8712F'...                                No
Client found at address 0x2c
Probing for `Myson MTP008'...                               No
Probing for `National Semiconductor LM78'...                No
Probing for `National Semiconductor LM79'...                No
Probing for `National Semiconductor LM80'...                No
Probing for `National Semiconductor LM96080'...             No
Probing for `National Semiconductor LM85'...                No
Probing for `National Semiconductor LM96000 or PC8374L'...  No
Probing for `Analog Devices ADM1027'...                     No
Probing for `Analog Devices ADT7460 or ADT7463'...          No
Probing for `SMSC EMC6D100 or EMC6D101'...                  No
Probing for `SMSC EMC6D102'...                              No
Probing for `SMSC EMC6D103'...                              No
Probing for `SMSC EMC6D103S or EMC2300'...                  No
Probing for `SMSC EMC6W201'...                              No
Probing for `Winbond WPCD377I'...                           No
Probing for `Analog Devices ADT7470'...                     No
Probing for `Analog Devices ADT7473'...                     No
Probing for `Analog Devices ADT7476'...                     No
Probing for `Analog Devices ADT7490'...                     No
Probing for `Andigilog aSC7611'...                          No
Probing for `Andigilog aSC7621'...                          No
Probing for `National Semiconductor LM87'...                No
Probing for `Analog Devices ADM1024'...                     No
Probing for `National Semiconductor LM93'...                No
Probing for `National Semiconductor LM94 or LM96194'...     No
Probing for `Winbond W83781D'...                            No
Probing for `Winbond W83782D'...                            No
Probing for `Winbond W83791D'...                            No
Probing for `Winbond W83792D'...                            No
Probing for `Winbond W83793R/G'...                          No
Probing for `Nuvoton W83795G/ADG'...                        No
Probing for `Nuvoton NCT7802Y'...                           No
Probing for `Winbond W83627HF'...                           No
Probing for `Winbond W83627EHF'...                          No
Probing for `Winbond W83627DHG/W83667HG/W83677HG'...        No
Probing for `Asus AS99127F (rev.1)'...                      No
Probing for `Asus AS99127F (rev.2)'...                      No
Probing for `Asus ASB100 Bach'...                           No
Probing for `Genesys Logic GL518SM'...                      No
Probing for `Genesys Logic GL520SM'...                      No
Probing for `Analog Devices ADM9240'...                     No
Probing for `Dallas Semiconductor DS1780'...                No
Probing for `National Semiconductor LM81'...                No
Probing for `Analog Devices ADM1026'...                     No
Probing for `Analog Devices ADM1025'...                     No
Probing for `Philips NE1619'...                             No
Probing for `Maxim MAX6639'...                              No
Probing for `Texas Instruments AMC6821'...                  No
Probing for `Analog Devices ADM1029'...                     No
Probing for `Analog Devices ADM1030'...                     No
Probing for `Analog Devices ADM1031'...                     No
Probing for `Analog Devices ADM1022'...                     No
Probing for `Texas Instruments THMC50'...                   No
Probing for `ITE IT8712F'...                                No
Probing for `ALi M5879'...                                  No
Probing for `SMSC LPC47M15x/192/292/997'...                 No
Probing for `SMSC DME1737'...                               No
Probing for `SMSC SCH5027D-NW'...                           No
Probing for `SMSC EMC1072'...                               No
Probing for `SMSC EMC1073'...                               No
Probing for `SMSC EMC1074'...                               No
Probing for `Winbond W83791SD'...                           No
Client found at address 0x2d
Probing for `Myson MTP008'...                               No
Probing for `National Semiconductor LM78'...                No
Probing for `National Semiconductor LM79'...                No
Probing for `National Semiconductor LM80'...                No
Probing for `National Semiconductor LM96080'...             No
Probing for `TI / National Semiconductor ADC128D818'...     No
Probing for `National Semiconductor LM85'...                No
Probing for `National Semiconductor LM96000 or PC8374L'...  No
Probing for `Analog Devices ADM1027'...                     No
Probing for `Analog Devices ADT7460 or ADT7463'...          No
Probing for `SMSC EMC6D100 or EMC6D101'...                  No
Probing for `SMSC EMC6D102'...                              No
Probing for `SMSC EMC6D103'...                              No
Probing for `SMSC EMC6D103S or EMC2300'...                  No
Probing for `SMSC EMC6W201'...                              No
Probing for `Winbond WPCD377I'...                           No
Probing for `Analog Devices ADT7473'...                     No
Probing for `Analog Devices ADT7476'...                     No
Probing for `Analog Devices ADT7490'...                     No
Probing for `Andigilog aSC7611'...                          No
Probing for `Andigilog aSC7621'...                          No
Probing for `National Semiconductor LM87'...                No
Probing for `Analog Devices ADM1024'...                     No
Probing for `National Semiconductor LM93'...                No
Probing for `National Semiconductor LM94 or LM96194'...     No
Probing for `Winbond W83781D'...                            No
Probing for `Winbond W83782D'...                            No
Probing for `Winbond W83783S'...                            No
Probing for `Winbond W83791D'...                            No
Probing for `Winbond W83792D'...                            No
Probing for `Winbond W83793R/G'...                          No
Probing for `Nuvoton W83795G/ADG'...                        No
Probing for `Nuvoton NCT7802Y'...                           No
Probing for `Nuvoton NCT7904D'...                           No
Probing for `Winbond W83627HF'...                           No
Probing for `Winbond W83627EHF'...                          No
Probing for `Winbond W83627DHG/W83667HG/W83677HG'...        No
Probing for `Asus AS99127F (rev.1)'...                      No
Probing for `Asus AS99127F (rev.2)'...                      No
Probing for `Asus ASB100 Bach'...                           No
Probing for `Winbond W83L784R/AR/G'...                      No
Probing for `Winbond W83L785R/G'...                         No
Probing for `Genesys Logic GL518SM'...                      No
Probing for `Genesys Logic GL520SM'...                      No
Probing for `Genesys Logic GL525SM'...                      No
Probing for `Analog Devices ADM9240'...                     No
Probing for `Dallas Semiconductor DS1780'...                No
Probing for `National Semiconductor LM81'...                No
Probing for `Analog Devices ADM1026'...                     No
Probing for `Analog Devices ADM1025'...                     No
Probing for `Philips NE1619'...                             No
Probing for `Texas Instruments AMC6821'...                  No
Probing for `Analog Devices ADM1029'...                     No
Probing for `Analog Devices ADM1030'...                     No
Probing for `Analog Devices ADM1031'...                     No
Probing for `Analog Devices ADM1022'...                     No
Probing for `Texas Instruments THMC50'...                   No
Probing for `VIA VT1211 (I2C)'...                           No
Probing for `ITE IT8712F'...                                No
Probing for `ALi M5879'...                                  No
Probing for `SMSC LPC47M15x/192/292/997'...                 No
Probing for `SMSC DME1737'...                               No
Probing for `SMSC SCH5027D-NW'...                           No
Probing for `Fintek F75373S/SG'...                          No
Probing for `Fintek F75375S/SP'...                          No
Probing for `Fintek F75387SG/RG'...                         No
Probing for `Winbond W83791SD'...                           No
Client found at address 0x2e
Probing for `Myson MTP008'...                               No
Probing for `National Semiconductor LM78'...                No
Probing for `National Semiconductor LM79'...                No
Probing for `National Semiconductor LM80'...                No
Probing for `National Semiconductor LM96080'...             No
Probing for `TI / National Semiconductor ADC128D818'...     No
Probing for `National Semiconductor LM85'...                No
Probing for `National Semiconductor LM96000 or PC8374L'...  No
Probing for `Analog Devices ADM1027'...                     No
Probing for `Analog Devices ADT7460 or ADT7463'...          No
Probing for `SMSC EMC6D100 or EMC6D101'...                  No
Probing for `SMSC EMC6D102'...                              No
Probing for `SMSC EMC6D103'...                              No
Probing for `SMSC EMC6D103S or EMC2300'...                  No
Probing for `SMSC EMC6W201'...                              No
Probing for `Winbond WPCD377I'...                           No
Probing for `Analog Devices ADT7467 or ADT7468'...          No
Probing for `Analog Devices ADT7470'...                     No
Probing for `Analog Devices ADT7473'...                     No
Probing for `Analog Devices ADT7475'...                     No
Probing for `Analog Devices ADT7476'...                     No
Probing for `Analog Devices ADT7490'...                     No
Probing for `Andigilog aSC7611'...                          No
Probing for `Andigilog aSC7621'...                          No
Probing for `National Semiconductor LM87'...                No
Probing for `Analog Devices ADM1024'...                     No
Probing for `National Semiconductor LM93'...                No
Probing for `National Semiconductor LM94 or LM96194'...     No
Probing for `Winbond W83781D'...                            No
Probing for `Winbond W83782D'...                            No
Probing for `Winbond W83791D'...                            No
Probing for `Winbond W83792D'...                            No
Probing for `Winbond W83793R/G'...                          No
Probing for `Nuvoton W83795G/ADG'...                        No
Probing for `Nuvoton NCT7802Y'...                           No
Probing for `Nuvoton NCT7904D'...                           No
Probing for `Winbond W83627HF'...                           No
Probing for `Winbond W83627EHF'...                          No
Probing for `Winbond W83627DHG/W83667HG/W83677HG'...        No
Probing for `Asus AS99127F (rev.1)'...                      No
Probing for `Asus AS99127F (rev.2)'...                      No
Probing for `Asus ASB100 Bach'...                           No
Probing for `Winbond W83L786NR/NG/R/G'...                   No
Probing for `Winbond W83L785TS-S'...                        No
Probing for `Analog Devices ADM9240'...                     No
Probing for `Dallas Semiconductor DS1780'...                No
Probing for `National Semiconductor LM81'...                No
Probing for `Analog Devices ADM1026'...                     No
Probing for `Analog Devices ADM1025'...                     No
Probing for `Maxim MAX6639'...                              No
Probing for `Texas Instruments AMC6821'...                  No
Probing for `Analog Devices ADM1029'...                     No
Probing for `Analog Devices ADM1030'...                     No
Probing for `Analog Devices ADM1031'...                     No
Probing for `Analog Devices ADM1022'...                     No
Probing for `Texas Instruments THMC50'...                   No
Probing for `Analog Devices ADM1028'...                     No
Probing for `Texas Instruments THMC51'...                   No
Probing for `ITE IT8712F'...                                No
Probing for `SMSC DME1737'...                               No
Probing for `SMSC SCH5027D-NW'...                           No
Probing for `SMSC EMC2103'...                               No
Probing for `Fintek F75373S/SG'...                          No
Probing for `Fintek F75375S/SP'...                          No
Probing for `Fintek F75387SG/RG'...                         No
Probing for `Winbond W83791SD'...                           No
Client found at address 0x2f
Probing for `National Semiconductor LM78'...                No
Probing for `National Semiconductor LM79'...                No
Probing for `National Semiconductor LM80'...                No
Probing for `National Semiconductor LM96080'...             No
Probing for `TI / National Semiconductor ADC128D818'...     No
Probing for `Analog Devices ADT7470'...                     No
Probing for `Winbond W83781D'...                            No
Probing for `Winbond W83782D'...                            No
Probing for `Winbond W83791D'...                            No
Probing for `Winbond W83792D'...                            No
Probing for `Winbond W83793R/G'...                          No
Probing for `Nuvoton W83795G/ADG'...                        No
Probing for `Nuvoton NCT7802Y'...                           No
Probing for `Winbond W83627HF'...                           No
Probing for `Winbond W83627EHF'...                          No
Probing for `Winbond W83627DHG/W83667HG/W83677HG'...        No
Probing for `Asus AS99127F (rev.1)'...                      No
Probing for `Asus AS99127F (rev.2)'...                      No
Probing for `Asus ASB100 Bach'...                           No
Probing for `Winbond W83L786NR/NG/R/G'...                   No
Probing for `Analog Devices ADM9240'...                     No
Probing for `Dallas Semiconductor DS1780'...                No
Probing for `National Semiconductor LM81'...                No
Probing for `Maxim MAX6639'...                              No
Probing for `Analog Devices ADM1029'...                     No
Probing for `ITE IT8712F'...                                No
Probing for `SMSC EMC2104'...                               No
Probing for `Fintek custom power control IC'...             No
Probing for `Winbond W83791SD'...                           No
Client found at address 0x48
Probing for `National Semiconductor LM75'...                No
Probing for `National Semiconductor LM75A'...               No
Probing for `Dallas Semiconductor DS75'...                  No
Probing for `National Semiconductor LM77'...                No
Probing for `Analog Devices ADT7410/ADT7420'...             No
Probing for `Analog Devices ADT7411'...                     No
Probing for `Maxim MAX6642'...                              No
Probing for `Texas Instruments TMP435'...                   No
Probing for `National Semiconductor LM73'...                No
Probing for `National Semiconductor LM92'...                No
Probing for `National Semiconductor LM76'...                No
Probing for `Maxim MAX6633/MAX6634/MAX6635'...              No
Probing for `NXP/Philips SA56004'...                        No
Probing for `SMSC EMC1023'...                               No
Probing for `SMSC EMC1043'...                               No
Probing for `SMSC EMC1053'...                               No
Probing for `SMSC EMC1063'...                               No
Client found at address 0x49
Probing for `National Semiconductor LM75'...                No
Probing for `National Semiconductor LM75A'...               No
Probing for `Dallas Semiconductor DS75'...                  No
Probing for `National Semiconductor LM77'...                No
Probing for `Analog Devices ADT7410/ADT7420'...             No
Probing for `Maxim MAX6642'...                              No
Probing for `Texas Instruments TMP435'...                   No
Probing for `National Semiconductor LM73'...                No
Probing for `National Semiconductor LM92'...                No
Probing for `National Semiconductor LM76'...                No
Probing for `Maxim MAX6633/MAX6634/MAX6635'...              No
Probing for `NXP/Philips SA56004'...                        No
Probing for `SMSC EMC1023'...                               No
Probing for `SMSC EMC1043'...                               No
Probing for `SMSC EMC1053'...                               No
Probing for `SMSC EMC1063'...                               No
Client found at address 0x4a
Probing for `National Semiconductor LM75'...                No
Probing for `National Semiconductor LM75A'...               No
Probing for `Dallas Semiconductor DS75'...                  No
Probing for `National Semiconductor LM77'...                No
Probing for `Analog Devices ADT7410/ADT7420'...             No
Probing for `Analog Devices ADT7411'...                     No
Probing for `Maxim MAX6642'...                              No
Probing for `Texas Instruments TMP435'...                   No
Probing for `National Semiconductor LM73'...                No
Probing for `National Semiconductor LM92'...                No
Probing for `National Semiconductor LM76'...                No
Probing for `Maxim MAX6633/MAX6634/MAX6635'...              No
Probing for `NXP/Philips SA56004'...                        No
Client found at address 0x4b
Probing for `National Semiconductor LM75'...                No
Probing for `National Semiconductor LM75A'...               No
Probing for `Dallas Semiconductor DS75'...                  No
Probing for `National Semiconductor LM77'...                No
Probing for `Analog Devices ADT7410/ADT7420'...             No
Probing for `Analog Devices ADT7411'...                     No
Probing for `Maxim MAX6642'...                              No
Probing for `Texas Instruments TMP435'...                   No
Probing for `National Semiconductor LM92'...                No
Probing for `National Semiconductor LM76'...                No
Probing for `Maxim MAX6633/MAX6634/MAX6635'...              No
Probing for `NXP/Philips SA56004'...                        No
Probing for `Analog Devices ADT7481'...                     No
Client found at address 0x4c
Probing for `National Semiconductor LM75'...                No
Probing for `National Semiconductor LM75A'...               No
Probing for `Dallas Semiconductor DS75'...                  No
Probing for `Analog Devices ADT7466'...                     No
Probing for `Andigilog aSC7511'...                          No
Probing for `Analog Devices ADM1021'...                     No
Probing for `Analog Devices ADM1021A/ADM1023'...            No
Probing for `Global Mixed-mode Technology G781'...          No
Probing for `Maxim MAX1617'...                              No
Probing for `Maxim MAX1617A'...                             No
Probing for `Maxim MAX1668'...                              No
Probing for `Maxim MAX1805'...                              No
Probing for `Maxim MAX1989'...                              No
Probing for `Maxim MAX6642'...                              No
Probing for `Maxim MAX6655/MAX6656'...                      No
Probing for `TI THMC10'...                                  No
Probing for `National Semiconductor LM84'...                No
Probing for `Genesys Logic GL523SM'...                      No
Probing for `Onsemi MC1066'...                              No
Probing for `Maxim MAX1618'...                              No
Probing for `Maxim MAX1619'...                              No
Probing for `National Semiconductor LM82/LM83'...           No
Probing for `National Semiconductor LM90'...                No
Probing for `National Semiconductor LM89/LM99'...           No
Probing for `National Semiconductor LM86'...                No
Probing for `Analog Devices ADM1032'...                     No
Probing for `Maxim MAX6654'...                              No
Probing for `Maxim MAX6690'...                              No
Probing for `Maxim MAX6657/MAX6658/MAX6659'...              No
Probing for `Maxim MAX6648/MAX6649/MAX6692'...              No
Probing for `Maxim MAX6680/MAX6681'...                      No
Probing for `Maxim MAX6695/MAX6696'...                      No
Probing for `Winbond W83L771W/G'...                         No
Probing for `Winbond W83L771AWG/ASG'...                     No
Probing for `Texas Instruments TMP400'...                   No
Probing for `Texas Instruments TMP401'...                   No
Probing for `Texas Instruments TMP411A'...                  No
Probing for `Texas Instruments TMP421'...                   No
Probing for `Texas Instruments TMP422'...                   No
Probing for `Texas Instruments TMP423'...                   No
Probing for `Texas Instruments TMP431'...                   No
Probing for `Texas Instruments TMP432'...                   No
Probing for `Texas Instruments TMP435'...                   No
Probing for `Texas Instruments TMP441'...                   No
Probing for `Texas Instruments TMP442'...                   No
Probing for `Texas Instruments TMP451'...                   No
Probing for `Texas Instruments AMC6821'...                  No
Probing for `National Semiconductor LM95235'...             No
Probing for `National Semiconductor LM95245'...             No
Probing for `National Semiconductor LM63'...                No
Probing for `National Semiconductor LM96163'...             No
Probing for `Fintek F75363SG'...                            No
Probing for `National Semiconductor LM73'...                No
Probing for `Maxim MAX6633/MAX6634/MAX6635'...              No
Probing for `Analog Devices ADT7461'...                     No
Probing for `Analog Devices ADT7461A, ON Semiconductor NCT1008'... No
Probing for `NXP/Philips SA56004'...                        No
Probing for `Analog Devices ADT7481'...                     No
Probing for `Fintek F75383S/M'...                           No
Probing for `SMSC EMC1002'...                               No
Probing for `SMSC EMC1023'...                               No
Probing for `SMSC EMC1033'...                               No
Probing for `SMSC EMC1043'...                               No
Probing for `SMSC EMC1046'...                               No
Probing for `SMSC EMC1053'...                               No
Probing for `SMSC EMC1063'...                               No
Probing for `SMSC EMC1072'...                               No
Probing for `SMSC EMC1073'...                               No
Probing for `SMSC EMC1074'...                               No
Probing for `SMSC EMC1402'...                               No
Probing for `SMSC EMC1403'...                               No
Probing for `SMSC EMC1404'...                               No
Probing for `SMSC EMC1422'...                               No
Probing for `SMSC EMC1423'...                               No
Probing for `SMSC EMC1424'...                               No
Client found at address 0x4d
Probing for `National Semiconductor LM75'...                No
Probing for `National Semiconductor LM75A'...               No
Probing for `Dallas Semiconductor DS75'...                  No
Probing for `Analog Devices ADM1021'...                     No
Probing for `Analog Devices ADM1021A/ADM1023'...            No
Probing for `Global Mixed-mode Technology G781'...          No
Probing for `Maxim MAX1617'...                              No
Probing for `Maxim MAX1617A'...                             No
Probing for `Maxim MAX1668'...                              No
Probing for `Maxim MAX1805'...                              No
Probing for `Maxim MAX1989'...                              No
Probing for `Maxim MAX6642'...                              No
Probing for `Maxim MAX6655/MAX6656'...                      No
Probing for `TI THMC10'...                                  No
Probing for `National Semiconductor LM84'...                No
Probing for `Genesys Logic GL523SM'...                      No
Probing for `Onsemi MC1066'...                              No
Probing for `Maxim MAX1618'...                              No
Probing for `Maxim MAX1619'...                              No
Probing for `National Semiconductor LM82/LM83'...           No
Probing for `National Semiconductor LM89/LM99'...           No
Probing for `Analog Devices ADM1032'...                     No
Probing for `Maxim MAX6654'...                              No
Probing for `Maxim MAX6690'...                              No
Probing for `Maxim MAX6659'...                              No
Probing for `Maxim MAX6646'...                              No
Probing for `Maxim MAX6680/MAX6681'...                      No
Probing for `Maxim MAX6695/MAX6696'...                      No
Probing for `Texas Instruments TMP400'...                   No
Probing for `Texas Instruments TMP411B'...                  No
Probing for `Texas Instruments TMP421'...                   No
Probing for `Texas Instruments TMP422'...                   No
Probing for `Texas Instruments TMP423'...                   No
Probing for `Texas Instruments TMP431'...                   No
Probing for `Texas Instruments TMP432'...                   No
Probing for `Texas Instruments TMP435'...                   No
Probing for `Texas Instruments TMP441'...                   No
Probing for `Texas Instruments TMP442'...                   No
Probing for `Texas Instruments AMC6821'...                  No
Probing for `National Semiconductor LM95234'...             No
Probing for `National Semiconductor LM95245'...             No
Probing for `National Semiconductor LM73'...                No
Probing for `Maxim MAX6633/MAX6634/MAX6635'...              No
Probing for `Analog Devices ADT7461'...                     No
Probing for `Analog Devices ADT7461A, ON Semiconductor NCT1008'... No
Probing for `NXP/Philips SA56004'...                        No
Probing for `Fintek F75384S/M'...                           No
Probing for `SMSC EMC1002'...                               No
Probing for `SMSC EMC1023'...                               No
Probing for `SMSC EMC1033'...                               No
Probing for `SMSC EMC1043'...                               No
Probing for `SMSC EMC1046'...                               No
Probing for `SMSC EMC1053'...                               No
Probing for `SMSC EMC1063'...                               No
Probing for `SMSC EMC1402'...                               No
Probing for `SMSC EMC1403'...                               No
Probing for `SMSC EMC1404'...                               No
Client found at address 0x4e
Probing for `National Semiconductor LM75'...                No
Probing for `National Semiconductor LM75A'...               No
Probing for `Dallas Semiconductor DS75'...                  No
Probing for `Analog Devices ADM1021'...                     No
Probing for `Analog Devices ADM1021A/ADM1023'...            No
Probing for `Maxim MAX1617'...                              No
Probing for `Maxim MAX1617A'...                             No
Probing for `Maxim MAX1668'...                              No
Probing for `Maxim MAX1805'...                              No
Probing for `Maxim MAX1989'...                              No
Probing for `Maxim MAX6642'...                              No
Probing for `Maxim MAX6655/MAX6656'...                      No
Probing for `TI THMC10'...                                  No
Probing for `National Semiconductor LM84'...                No
Probing for `Genesys Logic GL523SM'...                      No
Probing for `Onsemi MC1066'...                              No
Probing for `Maxim MAX1618'...                              No
Probing for `Maxim MAX1619'...                              No
Probing for `National Semiconductor LM82/LM83'...           No
Probing for `Maxim MAX6654'...                              No
Probing for `Maxim MAX6690'...                              No
Probing for `Maxim MAX6659'...                              No
Probing for `Maxim MAX6647'...                              No
Probing for `Maxim MAX6680/MAX6681'...                      No
Probing for `Maxim MAX6695/MAX6696'...                      No
Probing for `Texas Instruments TMP400'...                   No
Probing for `Texas Instruments TMP411C'...                  No
Probing for `Texas Instruments TMP421'...                   No
Probing for `Texas Instruments TMP422'...                   No
Probing for `Texas Instruments TMP435'...                   No
Probing for `Texas Instruments TMP441'...                   No
Probing for `Texas Instruments AMC6821'...                  No
Probing for `National Semiconductor LM95234'...             No
Probing for `National Semiconductor LM64'...                No
Probing for `National Semiconductor LM73'...                No
Probing for `Maxim MAX6633/MAX6634/MAX6635'...              No
Probing for `NXP/Philips SA56004'...                        No
Probing for `Fintek F75121R/F75122R/RG (VID+GPIO)'...       No
Probing for `Fintek F75111R/RG/N (GPIO)'...                 No
Probing for `ITE IT8201R/IT8203R/IT8206R/IT8266R'...        No
Client found at address 0x4f
Probing for `National Semiconductor LM75'...                No
Probing for `National Semiconductor LM75A'...               No
Probing for `Dallas Semiconductor DS75'...                  No
Probing for `Maxim MAX6642'...                              No
Probing for `Texas Instruments TMP421'...                   No
Probing for `Texas Instruments TMP422'...                   No
Probing for `Texas Instruments TMP435'...                   No
Probing for `Texas Instruments TMP441'...                   No
Probing for `Maxim MAX6633/MAX6634/MAX6635'...              No
Probing for `NXP/Philips SA56004'...                        No
Client found at address 0x50
Probing for `Analog Devices ADM1033'...                     No
Probing for `Analog Devices ADM1034'...                     No
Probing for `SPD EEPROM'...                                 No
Probing for `EDID EEPROM'...                                No
Client found at address 0x51
Probing for `Analog Devices ADM1033'...                     No
Probing for `Analog Devices ADM1034'...                     No
Probing for `SPD EEPROM'...                                 No
Client found at address 0x52
Probing for `Analog Devices ADM1033'...                     No
Probing for `Analog Devices ADM1034'...                     No
Probing for `SPD EEPROM'...                                 No
Client found at address 0x53
Probing for `Analog Devices ADM1033'...                     No
Probing for `Analog Devices ADM1034'...                     No
Probing for `SPD EEPROM'...                                 No
Client found at address 0x58
Probing for `Analog Devices ADT7462'...                     No
Probing for `Andigilog aSC7512'...                          No
Client found at address 0x5c
Probing for `Analog Devices ADT7462'...                     No
Probing for `SMSC EMC1072'...                               No
Probing for `SMSC EMC1073'...                               No
Probing for `SMSC EMC1074'...                               No
Client found at address 0x73
Probing for `FSC Poseidon I'...                             No
Probing for `FSC Poseidon II'...                            No
Probing for `FSC Scylla'...                                 No
Probing for `FSC Hermes'...                                 No
Probing for `FSC Heimdal'...                                No
Probing for `FSC Heracles'...                               No
Probing for `FSC Hades'...                                  No
Probing for `FSC Syleus'...                                 No
Client found at address 0x77
Probing for `Asus Mozart-2'...                              No

Next adapter: NVIDIA i2c adapter 1 at 1:00.0 (i2c-4)
Do you want to scan it? (yes/NO/selectively): yes

Next adapter: NVIDIA i2c adapter 3 at 1:00.0 (i2c-5)
Do you want to scan it? (yes/NO/selectively): yes

Next adapter: NVIDIA i2c adapter 5 at 1:00.0 (i2c-6)
Do you want to scan it? (yes/NO/selectively): yes
Client found at address 0x49
Probing for `National Semiconductor LM75'...                No
Probing for `National Semiconductor LM75A'...               No
Probing for `Dallas Semiconductor DS75'...                  No
Probing for `National Semiconductor LM77'...                No
Probing for `Analog Devices ADT7410/ADT7420'...             No
Probing for `Maxim MAX6642'...                              No
Probing for `Texas Instruments TMP435'...                   No
Probing for `National Semiconductor LM73'...                No
Probing for `National Semiconductor LM92'...                No
Probing for `National Semiconductor LM76'...                No
Probing for `Maxim MAX6633/MAX6634/MAX6635'...              No
Probing for `NXP/Philips SA56004'...                        No
Probing for `SMSC EMC1023'...                               No
Probing for `SMSC EMC1043'...                               No
Probing for `SMSC EMC1053'...                               No
Probing for `SMSC EMC1063'...                               No

Next adapter: NVIDIA i2c adapter 6 at 1:00.0 (i2c-7)
Do you want to scan it? (yes/NO/selectively): yes
Client found at address 0x58
Probing for `Analog Devices ADT7462'...                     No
Probing for `Andigilog aSC7512'...                          No
Client found at address 0x5c
Probing for `Analog Devices ADT7462'...                     No
Probing for `SMSC EMC1072'...                               No
Probing for `SMSC EMC1073'...                               No
Probing for `SMSC EMC1074'...                               No

Sorry, no sensors were detected.
This is relatively common on laptops, where thermal management is
handled by ACPI rather than the OS.

And after detection:

$ sensors
hidpp_battery_0-hid-3-6
Adapter: HID adapter
in0:           4.13 V

BAT0-acpi-0
Adapter: ACPI interface
in0:          17.16 V

nvme-pci-0500
Adapter: PCI adapter
Composite:    +49.9°C  (low  =  -5.2°C, high = +79.8°C)
                       (crit = +84.8°C)

iwlwifi_1-virtual-0
Adapter: Virtual device
temp1:        +53.0°C

k10temp-pci-00c3
Adapter: PCI adapter
Tctl:         +53.6°C
Tdie:         +53.6°C

nvme-pci-0200
Adapter: PCI adapter
Composite:    +38.9°C  (low  = -273.1°C, high = +83.8°C)
                       (crit = +84.8°C)
Sensor 1:     +38.9°C  (low  = -273.1°C, high = +65261.8°C)
Sensor 2:     +39.9°C  (low  = -273.1°C, high = +65261.8°C)
5

There you go. What @moson said. :point_up:

6

Great, thank you very much!!

7

Thanks a lot!!!

8

This topic was automatically closed 3 days after the last reply. New replies are no longer allowed.
