This last update reminded me how boring Digital Clock can be when it has no colours.
Fortunately I had the piece of mind to copy/rename the file to create a backup, because I knew the day would come that an update would kill it off…
So here, in full glory, is the modified file…
First, the folder:
/usr/share/plasma/plasmoids/org.kde.plasma.digitalclock/contents/ui/
DigitalClock.qml.colours
Contents of the qml
/*
SPDX-FileCopyrightText: 2013 Heena Mahour <heena393@gmail.com>
SPDX-FileCopyrightText: 2013 Sebastian Kügler <sebas@kde.org>
SPDX-FileCopyrightText: 2013 Martin Klapetek <mklapetek@kde.org>
SPDX-FileCopyrightText: 2014 David Edmundson <davidedmundson@kde.org>
SPDX-License-Identifier: GPL-2.0-or-later
*/
pragma ComponentBehavior: Bound
import QtQuick
import QtQuick.Layouts
import org.kde.plasma.plasmoid
import org.kde.plasma.core as PlasmaCore
import org.kde.plasma.components as PlasmaComponents
import org.kde.plasma.private.digitalclock
import org.kde.kirigami as Kirigami
MouseArea {
id: main
objectName: "digital-clock-compactrepresentation"
property string timeFormat
property string timeFormatWithSeconds
// This is quite convoluted in Qt 6:
// Qt.formatDate with locale only accepts Locale.FormatType as format type,
// no Qt.DateFormat (ISODate) and no format string.
// Locale.toString on the other hand only formats a date *with* time...
readonly property var dateFormatter: {
if (Plasmoid.configuration.dateFormat === "custom") {
Plasmoid.configuration.customDateFormat; // create a binding dependency on this property.
return (d) => {
return Qt.locale().toString(d, Plasmoid.configuration.customDateFormat);
};
} else if (Plasmoid.configuration.dateFormat === "isoDate") {
return (d) => {
return Qt.formatDate(d, Qt.ISODate);
};
} else if (Plasmoid.configuration.dateFormat === "longDate") {
return (d) => {
return Qt.formatDate(d, Qt.locale(), Locale.LongFormat);
};
} else {
return (d) => {
return Qt.formatDate(d, Qt.locale(), Locale.ShortFormat);
};
}
}
property string lastDate: ""
property int tzOffset
// This is the index in the list of user selected time zones
property int tzIndex: 0
// if showing the date and the time in one line or
// if the date/time zone cannot be fit with the smallest font to its designated space
readonly property bool oneLineMode: {
if (Plasmoid.configuration.dateDisplayFormat === 1) {
// BesideTime
return true;
} else if (Plasmoid.configuration.dateDisplayFormat === 2) {
// BelowTime
return false;
} else {
// Adaptive
return Plasmoid.formFactor === PlasmaCore.Types.Horizontal &&
height <= 2 * Kirigami.Theme.smallFont.pixelSize &&
(Plasmoid.configuration.showDate || timeZoneLabel.visible);
}
}
property bool wasExpanded
property int wheelDelta: 0
Accessible.role: Accessible.Button
Accessible.onPressAction: clicked(null)
Connections {
target: Plasmoid
function onContextualActionsAboutToShow() {
ClipboardMenu.secondsIncluded = (Plasmoid.configuration.showSeconds === 2);
ClipboardMenu.currentDate = main.getCurrentTime();
}
}
Connections {
target: Plasmoid.configuration
function onSelectedTimeZonesChanged() {
// If the currently selected time zone was removed,
// default to the first one in the list
if (Plasmoid.configuration.selectedTimeZones.indexOf(Plasmoid.configuration.lastSelectedTimezone) === -1) {
Plasmoid.configuration.lastSelectedTimezone = Plasmoid.configuration.selectedTimeZones[0];
}
main.setupLabels();
main.setTimeZoneIndex();
}
function onDisplayTimezoneFormatChanged() {
main.setupLabels();
}
function onLastSelectedTimezoneChanged() {
main.timeFormatCorrection();
}
function onShowLocalTimezoneChanged() {
main.timeFormatCorrection();
}
function onShowDateChanged() {
main.timeFormatCorrection();
}
function onUse24hFormatChanged() {
main.timeFormatCorrection();
}
}
function getCurrentTime(): date {
const data = dataSource.data[Plasmoid.configuration.lastSelectedTimezone];
// The order of signal propagation is unspecified, so we might get
// here before the dataSource has updated. Alternatively, a buggy
// configuration view might set lastSelectedTimezone to a new time
// zone before applying the new list, or it may just be set to
// something invalid in the config file.
if (data === undefined) {
return new Date();
}
// get the time for the given time zone from the dataengine
const now = data["DateTime"];
// get current UTC time
const msUTC = now.getTime() + (now.getTimezoneOffset() * 60000);
// add the dataengine TZ offset to it
const currentTime = new Date(msUTC + (data["Offset"] * 1000));
return currentTime;
}
function pointToPixel(pointSize: int): int {
const pixelsPerInch = Screen.pixelDensity * 25.4
return Math.round(pointSize / 72 * pixelsPerInch)
}
states: [
State {
name: "horizontalPanel"
when: Plasmoid.formFactor === PlasmaCore.Types.Horizontal && !main.oneLineMode
PropertyChanges {
target: main
Layout.fillHeight: true
Layout.fillWidth: false
Layout.minimumWidth: contentItem.width
Layout.maximumWidth: Layout.minimumWidth
}
PropertyChanges {
target: contentItem
height: timeLabel.height + (Plasmoid.configuration.showDate || timeZoneLabel.visible ? 0.8 * timeLabel.height : 0)
width: Math.max(timeLabel.width + (Plasmoid.configuration.showDate ? timeZoneLabel.paintedWidth : 0),
timeZoneLabel.paintedWidth, dateLabel.paintedWidth) + Kirigami.Units.largeSpacing
}
PropertyChanges {
target: labelsGrid
rows: Plasmoid.configuration.showDate ? 1 : 2
}
AnchorChanges {
target: labelsGrid
anchors.horizontalCenter: contentItem.horizontalCenter
}
PropertyChanges {
target: timeLabel
height: sizehelper.height
width: timeLabel.paintedWidth
font.pixelSize: timeLabel.height
}
PropertyChanges {
target: timeZoneLabel
height: Plasmoid.configuration.showDate ? 0.7 * timeLabel.height : 0.8 * timeLabel.height
width: Plasmoid.configuration.showDate ? timeZoneLabel.paintedWidth : timeLabel.width
font.pixelSize: timeZoneLabel.height
}
PropertyChanges {
target: dateLabel
height: 0.8 * timeLabel.height
width: dateLabel.paintedWidth
verticalAlignment: Text.AlignVCenter
font.pixelSize: dateLabel.height
}
AnchorChanges {
target: dateLabel
anchors.top: labelsGrid.bottom
anchors.horizontalCenter: labelsGrid.horizontalCenter
}
PropertyChanges {
target: sizehelper
/*
* The value 0.71 was picked by testing to give the clock the right
* size (aligned with tray icons).
* Value 0.56 seems to be chosen rather arbitrary as well such that
* the time label is slightly larger than the date or time zone label
* and still fits well into the panel with all the applied margins.
*/
height: Math.min(Plasmoid.configuration.showDate || timeZoneLabel.visible ? main.height * 0.56 : main.height * 0.71,
fontHelper.font.pixelSize)
font.pixelSize: sizehelper.height
}
},
State {
name: "oneLineDate"
// the one-line mode has no effect on a vertical panel because it would never fit
when: Plasmoid.formFactor !== PlasmaCore.Types.Vertical && main.oneLineMode
PropertyChanges {
target: main
Layout.fillHeight: true
Layout.fillWidth: false
Layout.minimumWidth: contentItem.width
Layout.maximumWidth: Layout.minimumWidth
}
PropertyChanges {
target: contentItem
height: sizehelper.height
width: dateLabel.width + dateLabel.anchors.rightMargin + labelsGrid.width
}
AnchorChanges {
target: labelsGrid
anchors.right: contentItem.right
}
PropertyChanges {
target: dateLabel
height: timeLabel.height
width: dateLabel.paintedWidth
font.pixelSize: 1024
verticalAlignment: Text.AlignVCenter
// between date and time; they are styled the same, so
// a space is more appropriate than smallSpacing
anchors.rightMargin: timeMetrics.advanceWidth(" ")
fontSizeMode: Text.VerticalFit
}
AnchorChanges {
target: dateLabel
anchors.right: labelsGrid.left
anchors.verticalCenter: labelsGrid.verticalCenter
}
PropertyChanges {
target: timeLabel
height: sizehelper.height
width: timeLabel.paintedWidth
fontSizeMode: Text.VerticalFit
}
PropertyChanges {
target: timeZoneLabel
height: 0.7 * timeLabel.height
width: timeZoneLabel.paintedWidth
fontSizeMode: Text.VerticalFit
horizontalAlignment: Text.AlignHCenter
}
PropertyChanges {
target: sizehelper
height: Math.min(main.height, fontHelper.contentHeight)
fontSizeMode: Text.VerticalFit
font.pixelSize: fontHelper.font.pixelSize
}
},
State {
name: "verticalPanel"
when: Plasmoid.formFactor === PlasmaCore.Types.Vertical
PropertyChanges {
target: main
Layout.fillHeight: false
Layout.fillWidth: true
Layout.maximumHeight: contentItem.height
Layout.minimumHeight: Layout.maximumHeight
}
PropertyChanges {
target: contentItem
height: Plasmoid.configuration.showDate ? labelsGrid.height + dateLabel.contentHeight : labelsGrid.height
width: main.width
}
PropertyChanges {
target: labelsGrid
rows: 2
}
PropertyChanges {
target: timeLabel
height: sizehelper.contentHeight
width: main.width
font.pixelSize: Math.min(timeLabel.height, fontHelper.font.pixelSize)
fontSizeMode: Text.Fit
}
PropertyChanges {
target: timeZoneLabel
height: Math.max(0.7 * timeLabel.height, minimumPixelSize)
width: main.width
fontSizeMode: Text.Fit
minimumPixelSize: dateLabel.minimumPixelSize
elide: Text.ElideRight
}
PropertyChanges {
target: dateLabel
width: main.width
//NOTE: in order for Text.Fit to work as intended, the actual height needs to be quite big, in order for the font to enlarge as much it needs for the available width, and then request a sensible height, for which contentHeight will need to be considered as opposed to height
height: Kirigami.Units.gridUnit * 10
fontSizeMode: Text.Fit
verticalAlignment: Text.AlignTop
// Those magic numbers are purely what looks nice as maximum size, here we have it the smallest
// between slightly bigger than the default font (1.4 times) and a bit smaller than the time font
font.pixelSize: Math.min(0.7 * timeLabel.height, Kirigami.Theme.defaultFont.pixelSize * 1.4)
elide: Text.ElideRight
wrapMode: Text.WordWrap
}
AnchorChanges {
target: dateLabel
anchors.top: labelsGrid.bottom
anchors.horizontalCenter: labelsGrid.horizontalCenter
}
PropertyChanges {
target: sizehelper
width: main.width
fontSizeMode: Text.HorizontalFit
font.pixelSize: fontHelper.font.pixelSize
}
},
State {
name: "other"
when: Plasmoid.formFactor !== PlasmaCore.Types.Vertical && Plasmoid.formFactor !== PlasmaCore.Types.Horizontal
PropertyChanges {
target: main
Layout.fillHeight: false
Layout.fillWidth: false
Layout.minimumWidth: Kirigami.Units.gridUnit * 3
Layout.minimumHeight: Kirigami.Units.gridUnit * 3
}
PropertyChanges {
target: contentItem
height: main.height
width: main.width
}
PropertyChanges {
target: labelsGrid
rows: 2
}
PropertyChanges {
target: timeLabel
height: sizehelper.height
width: main.width
fontSizeMode: Text.Fit
}
PropertyChanges {
target: timeZoneLabel
height: 0.7 * timeLabel.height
width: main.width
fontSizeMode: Text.Fit
minimumPixelSize: 1
}
PropertyChanges {
target: dateLabel
height: 0.7 * timeLabel.height
font.pixelSize: 1024
width: Math.max(timeLabel.contentWidth, Kirigami.Units.gridUnit * 3)
verticalAlignment: Text.AlignVCenter
fontSizeMode: Text.Fit
minimumPixelSize: 1
wrapMode: Text.WordWrap
}
AnchorChanges {
target: dateLabel
anchors.top: labelsGrid.bottom
anchors.horizontalCenter: labelsGrid.horizontalCenter
}
PropertyChanges {
target: sizehelper
height: {
if (Plasmoid.configuration.showDate) {
if (timeZoneLabel.visible) {
return 0.4 * main.height
}
return 0.56 * main.height
} else if (timeZoneLabel.visible) {
return 0.59 * main.height
}
return main.height
}
width: main.width
fontSizeMode: Text.Fit
font.pixelSize: 1024
}
}
]
onPressed: wasExpanded = root.expanded
onClicked: root.expanded = !wasExpanded
onWheel: wheel => {
if (!Plasmoid.configuration.wheelChangesTimezone) {
return;
}
var delta = (wheel.inverted ? -1 : 1) * (wheel.angleDelta.y ? wheel.angleDelta.y : wheel.angleDelta.x);
var newIndex = tzIndex;
wheelDelta += delta;
// magic number 120 for common "one click"
// See: https://doc.qt.io/qt-5/qml-qtquick-wheelevent.html#angleDelta-prop
while (wheelDelta >= 120) {
wheelDelta -= 120;
newIndex--;
}
while (wheelDelta <= -120) {
wheelDelta += 120;
newIndex++;
}
if (newIndex >= Plasmoid.configuration.selectedTimeZones.length) {
newIndex = 0;
} else if (newIndex < 0) {
newIndex = Plasmoid.configuration.selectedTimeZones.length - 1;
}
if (newIndex !== tzIndex) {
Plasmoid.configuration.lastSelectedTimezone = Plasmoid.configuration.selectedTimeZones[newIndex];
tzIndex = newIndex;
dataSource.dataChanged();
setupLabels();
}
}
/*
* Visible elements
*
*/
Item {
id: contentItem
anchors.verticalCenter: main.verticalCenter
Grid {
id: labelsGrid
rows: 1
horizontalItemAlignment: Grid.AlignHCenter
verticalItemAlignment: Grid.AlignVCenter
flow: Grid.TopToBottom
// between time and timezone; timezone is styled differently, so
// smallSpacing is more appropriate than a space
columnSpacing: Kirigami.Units.smallSpacing
PlasmaComponents.Label {
id: timeLabel
color: "#ffe387"
font {
family: fontHelper.font.family
weight: fontHelper.font.weight
italic: fontHelper.font.italic
features: { "tnum": 1 }
pixelSize: 1024
}
minimumPixelSize: 1
text: Qt.formatTime(main.getCurrentTime(), Plasmoid.configuration.showSeconds === 2 ? main.timeFormatWithSeconds : main.timeFormat)
textFormat: Text.PlainText
verticalAlignment: Text.AlignVCenter
horizontalAlignment: Text.AlignHCenter
}
PlasmaComponents.Label {
id: timeZoneLabel
color: "#ffff7f"
font.weight: timeLabel.font.weight
font.italic: timeLabel.font.italic
font.pixelSize: 1024
minimumPixelSize: 1
visible: text.length > 0
horizontalAlignment: Text.AlignHCenter
verticalAlignment: Text.AlignVCenter
textFormat: Text.PlainText
}
}
PlasmaComponents.Label {
id: dateLabel
color: "#77be9a"
visible: Plasmoid.configuration.showDate
font.family: timeLabel.font.family
font.weight: timeLabel.font.weight
font.italic: timeLabel.font.italic
font.pixelSize: 1024
minimumPixelSize: 1
horizontalAlignment: Text.AlignHCenter
verticalAlignment: Text.AlignVCenter
textFormat: Text.PlainText
}
}
/*
* end: Visible Elements
*
*/
PlasmaComponents.Label {
id: sizehelper
font.family: timeLabel.font.family
font.weight: timeLabel.font.weight
font.italic: timeLabel.font.italic
minimumPixelSize: 1
visible: false
textFormat: Text.PlainText
}
// To measure Label.height for maximum-sized font in VerticalFit mode
PlasmaComponents.Label {
id: fontHelper
height: 1024
font.family: (Plasmoid.configuration.autoFontAndSize || Plasmoid.configuration.fontFamily.length === 0) ? Kirigami.Theme.defaultFont.family : Plasmoid.configuration.fontFamily
font.weight: Plasmoid.configuration.autoFontAndSize ? Kirigami.Theme.defaultFont.weight : Plasmoid.configuration.fontWeight
font.italic: Plasmoid.configuration.autoFontAndSize ? Kirigami.Theme.defaultFont.italic : Plasmoid.configuration.italicText
font.pixelSize: Plasmoid.configuration.autoFontAndSize ? 3 * Kirigami.Theme.defaultFont.pixelSize : pointToPixel(Plasmoid.configuration.fontSize)
fontSizeMode: Text.VerticalFit
visible: false
textFormat: Text.PlainText
}
FontMetrics {
id: timeMetrics
font.family: timeLabel.font.family
font.weight: timeLabel.font.weight
font.italic: timeLabel.font.italic
}
// Qt's QLocale does not offer any modular time creating like Klocale did
// eg. no "gimme time with seconds" or "gimme time without seconds and with time zone".
// QLocale supports only two formats - Long and Short. Long is unusable in many situations
// and Short does not provide seconds. So if seconds are enabled, we need to add it here.
//
// What happens here is that it looks for the delimiter between "h" and "m", takes it
// and appends it after "mm" and then appends "ss" for the seconds.
function timeFormatCorrection(timeFormatString = Qt.locale().timeFormat(Locale.ShortFormat)) {
const regexp = /(hh*)(.+)(mm)/i
const match = regexp.exec(timeFormatString);
const hours = match[1];
const delimiter = match[2];
const minutes = match[3]
const seconds = "ss";
const amPm = "AP";
const uses24hFormatByDefault = timeFormatString.toLowerCase().indexOf("ap") === -1;
// because QLocale is incredibly stupid and does not convert 12h/24h clock format
// when uppercase H is used for hours, needs to be h or hh, so toLowerCase()
let result = hours.toLowerCase() + delimiter + minutes;
let result_sec = result + delimiter + seconds;
// add "AM/PM" either if the setting is the default and locale uses it OR if the user unchecked "use 24h format"
if ((Plasmoid.configuration.use24hFormat === Qt.PartiallyChecked && !uses24hFormatByDefault) || Plasmoid.configuration.use24hFormat === Qt.Unchecked) {
result += " " + amPm;
result_sec += " " + amPm;
}
timeFormat = result;
timeFormatWithSeconds = result_sec;
setupLabels();
}
function setupLabels() {
const lastSelectedData = dataSource.data[Plasmoid.configuration.lastSelectedTimezone];
const localData = dataSource.data["Local"];
// The order of signal propagation is unspecified, so we might get
// here before the dataSource has updated. Alternatively, a buggy
// configuration view might set lastSelectedTimezone to a new time
// zone before applying the new list, or it may just be set to
// something invalid in the config file.
if (lastSelectedData === undefined || localData === undefined) {
return;
}
const showTimezone = Plasmoid.configuration.showLocalTimezone
|| (Plasmoid.configuration.lastSelectedTimezone !== "Local"
&& lastSelectedData["Timezone City"] !== localData["Timezone City"]);
let timezoneString = "";
if (showTimezone) {
// format time zone as tz code, city or UTC offset
switch (Plasmoid.configuration.displayTimezoneFormat) {
case 0: // Code
timezoneString = lastSelectedData["Timezone Abbreviation"]
break;
case 1: // City
timezoneString = TimeZonesI18n.i18nCity(lastSelectedData["Timezone"]);
break;
case 2: // Offset from UTC time
const lastOffset = lastSelectedData["Offset"];
const symbol = lastOffset > 0 ? '+' : '';
const hours = Math.floor(lastOffset / 3600);
const minutes = Math.floor(lastOffset % 3600 / 60);
timezoneString = "UTC" + symbol + hours.toString().padStart(2, '0') + ":" + minutes.toString().padStart(2, '0');
break;
}
if ((Plasmoid.configuration.showDate || oneLineMode) && Plasmoid.formFactor === PlasmaCore.Types.Horizontal) {
timezoneString = `(${timezoneString})`;
}
}
// an empty string clears the label and that makes it hidden
timeZoneLabel.text = timezoneString;
if (Plasmoid.configuration.showDate) {
dateLabel.text = dateFormatter(getCurrentTime());
} else {
// clear it so it doesn't take space in the layout
dateLabel.text = "";
}
// find widest character between 0 and 9
let maximumWidthNumber = 0;
let maximumAdvanceWidth = 0;
for (let i = 0; i <= 9; i++) {
const advanceWidth = timeMetrics.advanceWidth(i);
if (advanceWidth > maximumAdvanceWidth) {
maximumAdvanceWidth = advanceWidth;
maximumWidthNumber = i;
}
}
// replace all placeholders with the widest number (two digits)
const format = timeFormat.replace(/(h+|m+|s+)/g, "" + maximumWidthNumber + maximumWidthNumber); // make sure maximumWidthNumber is formatted as string
// build the time string twice, once with an AM time and once with a PM time
const date = new Date(2000, 0, 1, 1, 0, 0);
const timeAm = Qt.formatTime(date, format);
const advanceWidthAm = timeMetrics.advanceWidth(timeAm);
date.setHours(13);
const timePm = Qt.formatTime(date, format);
const advanceWidthPm = timeMetrics.advanceWidth(timePm);
// set the sizehelper's text to the widest time string
if (advanceWidthAm > advanceWidthPm) {
sizehelper.text = timeAm;
} else {
sizehelper.text = timePm;
}
fontHelper.text = sizehelper.text
}
function dateTimeChanged() {
let doCorrections = false;
if (Plasmoid.configuration.showDate) {
// If the date has changed, force size recalculation, because the day name
// or the month name can now be longer/shorter, so we need to adjust applet size
const currentDate = Qt.formatDateTime(getCurrentTime(), "yyyy-MM-dd");
if (lastDate !== currentDate) {
doCorrections = true;
lastDate = currentDate
}
}
const currentTimeZoneOffset = dataSource.data["Local"]["Offset"] / 60;
if (currentTimeZoneOffset !== tzOffset) {
doCorrections = true;
tzOffset = currentTimeZoneOffset;
Date.timeZoneUpdated(); // inform the QML JS engine about TZ change
}
if (doCorrections) {
timeFormatCorrection();
}
}
function setTimeZoneIndex() {
tzIndex = Plasmoid.configuration.selectedTimeZones.indexOf(Plasmoid.configuration.lastSelectedTimezone);
}
Component.onCompleted: {
// Sort the time zones according to their offset
// Calling sort() directly on Plasmoid.configuration.selectedTimeZones
// has no effect, so sort a copy and then assign the copy to it
const byOffset = (a, b) => a.offset - b.offset;
const sortedTimeZones = Plasmoid.configuration.selectedTimeZones
.map(timeZone => ({
timeZone,
// If not found, move it to the bottom by giving it the highest offset as a fallback
offset: dataSource.data[timeZone]?.["Offset"] ?? 86400,
}));
sortedTimeZones.sort(byOffset);
Plasmoid.configuration.selectedTimeZones = sortedTimeZones
.map(({ timeZone }) => timeZone);
setTimeZoneIndex();
tzOffset = -(new Date().getTimezoneOffset());
dateTimeChanged();
timeFormatCorrection();
dataSource.dataChanged
.connect(dateTimeChanged);
dateFormatterChanged
.connect(setupLabels);
stateChanged
.connect(setupLabels);
}
}
You can rename DigitalClock.qml DigitalClock.qml.default and then rename *.qml.colours *.qml and restart plasma.
Yellow color is 554:
PlasmaComponents.Label {
id: timeZoneLabel
color: "#ffff7f"
Green color is line 569
PlasmaComponents.Label {
id: dateLabel
color: "#77be9a"
As usual, Kate is the tool for the job
