PineTab2 started with kernel 6.15.0-rc6 - without Screen coming on
OS: Manjaro ARM Linux aarch64
Host: Pine64 PineTab2 v2.0
Kernel: Linux 6.15.0-rc6-1-MANJARO-ARM
Uptime: 31 seconds
Packages: 875 (pacman)[arm-unstable]
Shell: bash 5.2.37
Theme: Breeze-Dark [GTK2], Breeze [GTK3/4]
Icons: breeze [GTK2/3/4]
Font: Noto Sans (10pt) [GTK2/3/4]
Cursor: breeze (24px)
Terminal: vt220
CPU: pinetab2 (4) @ 1.80 GHz
GPU: Rockchip rk3568-mali [Integrated]
Memory: 307.96 MiB / 7.51 GiB (4%)
Swap: 0 B / 11.26 GiB (0%)
Disk (/): 26.40 GiB / 114.11 GiB (23%) - ext4
Battery: 86% [Discharging]
UART - Start linux-rc 6.15.0-rc6
DDR V1.16 6f71c736ce typ 23/03/02-20:01:48
ln
LP4/4x derate en, other dram:1x trefi
ddrconfig:7
LPDDR4X, 324MHz
BW=32 Col=10 Bk=8 CS0 Row=17 CS1 Row=17 CS=2 Die BW=16 Size=8192MB
tdqss: cs0 dqs0: 24ps, dqs1: -96ps, dqs2: -72ps, dqs3: -192ps,
tdqss: cs1 dqs0: 24ps, dqs1: -72ps, dqs2: -48ps, dqs3: -192ps,
change to: 324MHz
PHY drv:clk:36,ca:36,DQ:29,odt:0
vrefinner:24%, vrefout:41%
dram drv:40,odt:0
clk skew:0x63
change to: 528MHz
PHY drv:clk:36,ca:36,DQ:29,odt:0
vrefinner:24%, vrefout:41%
dram drv:40,odt:0
clk skew:0x58
change to: 780MHz
PHY drv:clk:36,ca:36,DQ:29,odt:0
vrefinner:24%, vrefout:41%
dram drv:40,odt:0
clk skew:0x58
change to: 1056MHz(final freq)
PHY drv:clk:36,ca:36,DQ:29,odt:60
vrefinner:16%, vrefout:22%
dram drv:40,odt:80
vref_ca:00000071
clk skew:0x3c
cs 0:
the read training result:
DQS0:0x3c, DQS1:0x42, DQS2:0x42, DQS3:0x34,
min : 0xa 0xb 0xb 0xb 0x1 0x3 0x8 0x4 , 0xa 0xa 0x6 0x0 0x10 0xb 0xf 0xc ,
0x12 0x12 0x10 0xd 0x8 0x1 0x6 0xa , 0x8 0x6 0x5 0x1 0xd 0xa 0x8 0xb ,
mid :0x29 0x2a 0x2b 0x28 0x1e 0x21 0x24 0x21 ,0x29 0x29 0x23 0x21 0x2e 0x2b 0x2d 0x2b ,
0x30 0x30 0x2d 0x2b 0x25 0x20 0x24 0x27 ,0x25 0x24 0x22 0x1e 0x29 0x2a 0x25 0x29 ,
max :0x48 0x4a 0x4c 0x46 0x3c 0x40 0x41 0x3f ,0x48 0x49 0x41 0x42 0x4c 0x4c 0x4b 0x4a ,
0x4f 0x4f 0x4b 0x4a 0x43 0x40 0x42 0x45 ,0x43 0x42 0x3f 0x3b 0x46 0x4a 0x43 0x48 ,
range:0x3e 0x3f 0x41 0x3b 0x3b 0x3d 0x39 0x3b ,0x3e 0x3f 0x3b 0x42 0x3c 0x41 0x3c 0x3e ,
0x3d 0x3d 0x3b 0x3d 0x3b 0x3f 0x3c 0x3b ,0x3b 0x3c 0x3a 0x3a 0x39 0x40 0x3b 0x3d ,
the write training result:
DQS0:0x3f, DQS1:0x30, DQS2:0x33, DQS3:0x23,
min :0x66 0x69 0x6a 0x68 0x5d 0x60 0x64 0x64 0x63 ,0x53 0x55 0x4e 0x4c 0x58 0x56 0x57 0x56 0x53 ,
0x5a 0x5b 0x57 0x56 0x52 0x4e 0x50 0x56 0x56 ,0x4f 0x4d 0x4b 0x48 0x53 0x52 0x4f 0x55 0x4c ,
mid :0x84 0x87 0x88 0x85 0x7a 0x7d 0x81 0x80 0x7f ,0x71 0x71 0x6a 0x69 0x74 0x71 0x72 0x72 0x6f ,
0x77 0x78 0x74 0x74 0x6e 0x67 0x6b 0x71 0x73 ,0x6c 0x69 0x67 0x65 0x6f 0x6f 0x6b 0x71 0x69 ,
max :0xa3 0xa5 0xa6 0xa3 0x97 0x9a 0x9e 0x9c 0x9c ,0x8f 0x8d 0x87 0x87 0x90 0x8c 0x8e 0x8e 0x8c ,
0x95 0x96 0x91 0x92 0x8b 0x81 0x87 0x8c 0x90 ,0x8a 0x86 0x84 0x83 0x8c 0x8d 0x87 0x8e 0x86 ,
range:0x3d 0x3c 0x3c 0x3b 0x3a 0x3a 0x3a 0x38 0x39 ,0x3c 0x38 0x39 0x3b 0x38 0x36 0x37 0x38 0x39 ,
0x3b 0x3b 0x3a 0x3c 0x39 0x33 0x37 0x36 0x3a ,0x3b 0x39 0x39 0x3b 0x39 0x3b 0x38 0x39 0x3a ,
cs 1:
the read training result:
DQS0:0x3f, DQS1:0x42, DQS2:0x40, DQS3:0x38,
min : 0xb 0xd 0xf 0xb 0x1 0x4 0x7 0x3 , 0x9 0x9 0x2 0x1 0xd 0xd 0xd 0x9 ,
0x10 0x10 0xd 0xb 0x5 0x1 0x2 0x6 , 0xb 0x9 0x7 0x1 0xf 0x10 0xa 0x10 ,
mid :0x2c 0x2d 0x2f 0x2c 0x22 0x24 0x28 0x24 ,0x2a 0x2b 0x23 0x22 0x2e 0x2d 0x2d 0x2a ,
0x30 0x30 0x2c 0x2b 0x25 0x20 0x23 0x26 ,0x2b 0x28 0x26 0x21 0x2e 0x2e 0x2a 0x2f ,
max :0x4d 0x4e 0x4f 0x4d 0x44 0x45 0x49 0x45 ,0x4c 0x4d 0x45 0x43 0x4f 0x4d 0x4e 0x4c ,
0x50 0x50 0x4c 0x4b 0x46 0x40 0x44 0x46 ,0x4b 0x47 0x46 0x41 0x4e 0x4d 0x4a 0x4e ,
range:0x42 0x41 0x40 0x42 0x43 0x41 0x42 0x42 ,0x43 0x44 0x43 0x42 0x42 0x40 0x41 0x43 ,
0x40 0x40 0x3f 0x40 0x41 0x3f 0x42 0x40 ,0x40 0x3e 0x3f 0x40 0x3f 0x3d 0x40 0x3e ,
the write training result:
DQS0:0x3f, DQS1:0x30, DQS2:0x33, DQS3:0x23,
min :0x66 0x69 0x6a 0x68 0x5d 0x5f 0x64 0x62 0x63 ,0x57 0x57 0x51 0x4f 0x5a 0x59 0x59 0x58 0x56 ,
0x5d 0x5e 0x5b 0x5b 0x55 0x51 0x54 0x58 0x59 ,0x4d 0x4b 0x4a 0x48 0x52 0x51 0x4e 0x52 0x4a ,
mid :0x83 0x85 0x87 0x85 0x79 0x7b 0x80 0x7d 0x7e ,0x72 0x72 0x6c 0x6b 0x76 0x74 0x73 0x73 0x71 ,
0x7a 0x7b 0x77 0x77 0x71 0x6c 0x6f 0x73 0x75 ,0x69 0x67 0x66 0x64 0x6e 0x6d 0x6a 0x6e 0x66 ,
max :0xa0 0xa2 0xa4 0xa2 0x96 0x98 0x9c 0x99 0x9a ,0x8e 0x8e 0x88 0x87 0x93 0x8f 0x8e 0x8e 0x8d ,
0x97 0x98 0x93 0x93 0x8e 0x88 0x8b 0x8f 0x92 ,0x86 0x83 0x82 0x80 0x8a 0x89 0x86 0x8b 0x83 ,
range:0x3a 0x39 0x3a 0x3a 0x39 0x39 0x38 0x37 0x37 ,0x37 0x37 0x37 0x38 0x39 0x36 0x35 0x36 0x37 ,
0x3a 0x3a 0x38 0x38 0x39 0x37 0x37 0x37 0x39 ,0x39 0x38 0x38 0x38 0x38 0x38 0x38 0x39 0x39 ,
CA Training result:
cs:0 min :0x40 0x3a 0x37 0x2f 0x37 0x2f 0x38 ,0x43 0x36 0x37 0x2e 0x37 0x2d 0x3b ,
cs:0 mid :0x7b 0x7d 0x72 0x72 0x72 0x73 0x67 ,0x7e 0x7b 0x72 0x71 0x72 0x71 0x6a ,
cs:0 max :0xb7 0xc1 0xad 0xb6 0xad 0xb7 0x97 ,0xb9 0xc0 0xad 0xb5 0xad 0xb5 0x99 ,
cs:0 range:0x77 0x87 0x76 0x87 0x76 0x88 0x5f ,0x76 0x8a 0x76 0x87 0x76 0x88 0x5e ,
cs:1 min :0x41 0x40 0x35 0x35 0x36 0x33 0x38 ,0x3f 0x3c 0x34 0x32 0x35 0x32 0x38 ,
cs:1 mid :0x7f 0x7f 0x75 0x74 0x75 0x74 0x6a ,0x7e 0x7b 0x73 0x70 0x74 0x71 0x69 ,
cs:1 max :0xbe 0xbf 0xb5 0xb4 0xb5 0xb5 0x9c ,0xbe 0xba 0xb2 0xaf 0xb3 0xb1 0x9b ,
cs:1 range:0x7d 0x7f 0x80 0x7f 0x7f 0x82 0x64 ,0x7f 0x7e 0x7e 0x7d 0x7e 0x7f 0x63 ,
out
U-Boot SPL 2023.07-2 (Jul 21 2023 - 11:24:46 +0000)
Trying to boot from MMC2
## Checking hash(es) for config config-2 ... OK
## Checking hash(es) for Image atf-1 ... sha256+ OK
## Checking hash(es) for Image u-boot ... sha256+ OK
## Checking hash(es) for Image fdt-2 ... sha256+ OK
## Checking hash(es) for Image atf-2 ... sha256+ OK
## Checking hash(es) for Image atf-3 ... sha256+ OK
## Checking hash(es) for Image atf-4 ... sha256+ OK
## Checking hash(es) for Image atf-5 ... sha256+ OK
## Checking hash(es) for Image atf-6 ... sha256+ OK
INFO: Preloader serial: 2
NOTICE: BL31: v2.3():v2.3-594-g7f859117f:cl
NOTICE: BL31: Built : 04:51:16, May 11 2023
INFO: GICv3 without legacy support detected.
INFO: ARM GICv3 driver initialized in EL3
INFO: pmu v1 is valid 220114
INFO: dfs DDR fsp_param[0].freq_mhz= 1056MHz
INFO: dfs DDR fsp_param[1].freq_mhz= 324MHz
INFO: dfs DDR fsp_param[2].freq_mhz= 528MHz
INFO: dfs DDR fsp_param[3].freq_mhz= 780MHz
INFO: BL31: Initialising Exception Handling Framework
INFO: BL31: Initializing runtime services
WARNING: No OPTEE provided by BL2 boot loader, Booting device without OPTEE initialization. SMC`s destined for OPTEE will return SMC_UNK
ERROR: Error initializing runtime service opteed_fast
INFO: BL31: Preparing for EL3 exit to normal world
INFO: Entry point address = 0xa00000
INFO: SPSR = 0x3c9
U-Boot 2023.07-2 (Jul 21 2023 - 11:24:46 +0000) Manjaro Linux ARM
Model: Pine64 PineTab2 v2.0
DRAM: 8 GiB (effective 7.7 GiB)
PMIC: RK8170 (on=0x80, off=0x80)
Core: 321 devices, 25 uclasses, devicetree: separate
MMC: mmc@fe2b0000: 1, mmc@fe2c0000: 2, mmc@fe310000: 0
Loading Environment from nowhere... OK
In: serial@fe660000
Out: serial@fe660000
Err: serial@fe660000
Model: Pine64 PineTab2 v2.0
Net: No ethernet found.
Hit any key to stop autoboot: 0
Card did not respond to voltage select! : -110
** Booting bootflow 'mmc@fe310000.bootdev.part_1' with extlinux
1: Manjaro ARM
Retrieving file: /Image
Retrieving file: /initramfs-linux.img
append: initrd=/initramfs-linux.img console=ttyS2,1500000 earlycon=uart8250,mmio32,0xfe660000 root=PARTUUID=cbc9819e-278b-44f3-a40c-1fe5f7ecf762 rw rootwait audit=0 splash plymouth.ignore-serial-consoles
Retrieving file: /dtbs/rockchip/rk3566-pinetab2-v2.0.dtb
Moving Image from 0x2080000 to 0x2200000, end=4210000
## Flattened Device Tree blob at 0a100000
Booting using the fdt blob at 0xa100000
Working FDT set to a100000
Loading Ramdisk to ec6ab000, end ecef2003 ... .OK
Loading Device Tree to 00000000ec68a000, end 00000000ec6aaef1 ... OK
Working FDT set to ec68a000
Starting kernel ...
:: running early hook [udev]
Starting systemd-udevd version 257.5-2-arch
:: running hook [udev]
:: Triggering uevents...
:: running hook [keymap]
:: Loading keymap...kbd_mode: KDSKBMODE: Inappropriate ioctl for device
done.
:: performing fsck on 'PARTUUID=cbc9819e-278b-44f3-a40c-1fe5f7ecf762'
ROOT_MNJRO: clean, 917970/7565776 files, 7418410/30410675 blocks
:: mounting 'PARTUUID=cbc9819e-278b-44f3-a40c-1fe5f7ecf762' on real root
:: running cleanup hook [udev]
Welcome to Manjaro ARM Linux!
[ OK ] Created slice Slice /system/dirmngr.
[ OK ] Created slice Slice /system/getty.
[ OK ] Created slice Slice /system/gpg-agent.
[ OK ] Created slice Slice /system/gpg-agent-browser.
[ OK ] Created slice Slice /system/gpg-agent-extra.
[ OK ] Created slice Slice /system/gpg-agent-ssh.
[ OK ] Created slice Slice /system/keyboxd.
[ OK ] Created slice Slice /system/modprobe.
[ OK ] Created slice Slice /system/serial-getty.
[ OK ] Created slice User and Session Slice.
[ OK ] Started Forward Password Requests to Wall Directory Watch.
[ OK ] Set up automount Arbitrary Executa…ormats File System Automount Point.
Expecting device /dev/disk/by-part…81c7-11c5-49f6-b299-7b499cef470c...
Expecting device /dev/ttyS2...
[ OK ] Reached target Local Integrity Protected Volumes.
[ OK ] Reached target Remote Encrypted Volumes.
[ OK ] Reached target Remote File Systems.
[ OK ] Reached target Slice Units.
[ OK ] Reached target Swaps.
[ OK ] Reached target Local Verity Protected Volumes.
[ OK ] Listening on Device-mapper event daemon FIFOs.
[ OK ] Listening on Process Core Dump Socket.
[ OK ] Listening on Credential Encryption/Decryption.
[ OK ] Listening on Journal Socket (/dev/log).
[ OK ] Listening on Journal Sockets.
[ OK ] Listening on DDI File System Mounter Socket.
[ OK ] Listening on Network Service Netlink Socket.
[ OK ] Listening on Namespace Resource Manager Socket.
[ OK ] Listening on Userspace Out-Of-Memory (OOM) Killer Socket.
[ OK ] Listening on udev Control Socket.
[ OK ] Listening on udev Kernel Socket.
[ OK ] Listening on User Database Manager Socket.
Mounting Huge Pages File System...
Mounting POSIX Message Queue File System...
Mounting Kernel Debug File System...
Mounting Temporary Directory /tmp...
Starting Create List of Static Device Nodes...
Starting Load Kernel Module configfs...
Starting Load Kernel Module dm_mod...
Starting Load Kernel Module drm...
Starting Load Kernel Module efi_pstore...
Starting Load Kernel Module fuse...
Starting Load Kernel Module loop...
Starting Journal Service...
Starting Load Kernel Modules...
Starting Generate network units from Kernel command line...
Starting Userspace Out-Of-Memory (OOM) Killer...
Starting Remount Root and Kernel File Systems...
Starting Load udev Rules from Credentials...
Starting Coldplug All udev Devices...
Starting Virtual Console Setup...
[ OK ] Mounted Huge Pages File System.
[ OK ] Mounted POSIX Message Queue File System.
[ OK ] Mounted Kernel Debug File System.
[ OK ] Mounted Temporary Directory /tmp.
[ OK ] Finished Create List of Static Device Nodes.
[ OK ] Finished Load Kernel Module configfs.
[ OK ] Finished Load Kernel Module dm_mod.
[ OK ] Finished Load Kernel Module drm.
[ OK ] Finished Load Kernel Module efi_pstore.
[ OK ] Finished Load Kernel Module fuse.
[ OK ] Finished Load Kernel Module loop.
[ OK ] Finished Load Kernel Modules.
[ OK ] Finished Generate network units from Kernel command line.
[ OK ] Finished Remount Root and Kernel File Systems.
[ OK ] Finished Load udev Rules from Credentials.
Mounting FUSE Control File System...
Mounting Kernel Configuration File System...
Starting Namespace Resource Manager...
Starting Load/Save OS Random Seed...
Starting Apply Kernel Variables...
Starting Create Static Device Nodes in /dev gracefully...
Starting User Database Manager...
[ OK ] Started Journal Service.
[ OK ] Finished Virtual Console Setup.
[ OK ] Mounted FUSE Control File System.
[ OK ] Mounted Kernel Configuration File System.
[ OK ] Started Namespace Resource Manager.
[ OK ] Finished Apply Kernel Variables.
Starting Flush Journal to Persistent Storage...
[ OK ] Started User Database Manager.
[ OK ] Started Userspace Out-Of-Memory (OOM) Killer.
[ OK ] Finished Create Static Device Nodes in /dev gracefully.
Starting Network Time Synchronization...
Starting Create Static Device Nodes in /dev...
[ OK ] Finished Coldplug All udev Devices.
[ OK ] Started Network Time Synchronization.
[ OK ] Reached target System Time Set.
[ OK ] Finished Create Static Device Nodes in /dev.
[ OK ] Reached target Preparation for Local File Systems.
[ OK ] Reached target Containers.
[ OK ] Listening on Disk Image Download Service Socket.
Starting Rule-based Manager for Device Events and Files...
[ OK ] Finished Flush Journal to Persistent Storage.
[ OK ] Started Rule-based Manager for Device Events and Files.
Starting Show Plymouth Boot Screen...
[ OK ] Finished Hold until boot process finishes up.
[ OK ] Finished Terminate Plymouth Boot Screen.
[ OK ] Started Simple Desktop Display Manager.
[ OK ] Started Serial Getty on ttyS2.
[ OK ] Reached target Login Prompts.
[ OK ] Reached target Multi-User System.
Starting Power Profiles daemon...
[ OK ] Started Power Profiles daemon.
Manjaro Linux 6.15.0-rc6-1-MANJARO-ARM (manjaropt2) (ttyS2)
journalctl -b 0 | grep error
kernel: platform regulatory.0: loading /lib/firmware/6.15.0-rc6-1-MANJARO-ARM/regulatory.db failed with error -20
kernel: usb 1-1: loading /lib/firmware/6.15.0-rc6-1-MANJARO-ARM/rtlwifi/rtl8192eu_nic.bin failed with error -20
kernel: Goodix-TS 1-005d: loading /lib/firmware/6.15.0-rc6-1-MANJARO-ARM/goodix_911_cfg.bin failed with error -20
kernel: Goodix-TS 1-005d: loading /lib/firmware/6.15.0-rc6-1-MANJARO-ARM/goodix_911_cfg.bin.zst failed with error -20
kernel: Goodix-TS 1-005d: loading /lib/firmware/6.15.0-rc6-1-MANJARO-ARM/goodix_911_cfg.bin.xz failed with error -20
kernel: Goodix-TS 1-005d: Direct firmware load for goodix_911_cfg.bin failed with error -2
polkitd[582]: Error opening rules directory: Error opening directory “/run/polkit-1/rules.d”: No such file or directory (g-file-error-quark, 4)
polkitd[582]: Error opening rules directory: Error opening directory “/usr/local/share/polkit-1/rules.d”: No such file or directory (g-file-error-quark, 4)
kernel: platform hdmi-sound: deferred probe pending: asoc-simple-card: parse error
sudo dmesg
[ 0.000000] Booting Linux on physical CPU 0x0000000000 [0x412fd050]
[ 0.000000] Linux version 6.15.0-rc6-1-MANJARO-ARM (builduser@gitlab-runner-ampere-cax41) (gcc (GCC) 14.2.1 20250207, GNU ld (GNU Binutils) 2.44) #1 SMP PREEMPT Sun May 11 23:46:32 UTC 2025
[ 0.000000] Machine model: Pine64 PineTab2 v2.0
[ 0.000000] earlycon: uart8250 at MMIO32 0x00000000fe660000 (options '')
[ 0.000000] printk: legacy bootconsole [uart8250] enabled
[ 0.000000] efi: UEFI not found.
[ 0.000000] OF: reserved mem: 0x000000000010f000..0x000000000010f0ff (0 KiB) nomap non-reusable shmem@10f000
[ 0.000000] Zone ranges:
[ 0.000000] DMA [mem 0x0000000000200000-0x00000000ffffffff]
[ 0.000000] DMA32 empty
[ 0.000000] Normal [mem 0x0000000100000000-0x00000001ffffffff]
[ 0.000000] Movable zone start for each node
[ 0.000000] Early memory node ranges
[ 0.000000] node 0: [mem 0x0000000000200000-0x00000000efffffff]
[ 0.000000] node 0: [mem 0x0000000100000000-0x00000001ffffffff]
[ 0.000000] Initmem setup node 0 [mem 0x0000000000200000-0x00000001ffffffff]
[ 0.000000] On node 0, zone DMA: 512 pages in unavailable ranges
[ 0.000000] cma: Reserved 256 MiB at 0x00000000dc600000
[ 0.000000] psci: probing for conduit method from DT.
[ 0.000000] psci: PSCIv1.1 detected in firmware.
[ 0.000000] psci: Using standard PSCI v0.2 function IDs
[ 0.000000] psci: MIGRATE_INFO_TYPE not supported.
[ 0.000000] psci: SMC Calling Convention v1.2
[ 0.000000] No bootconfig data provided, so skipping bootconfig
[ 0.000000] percpu: Embedded 24 pages/cpu s59864 r8192 d30248 u98304
[ 0.000000] pcpu-alloc: s59864 r8192 d30248 u98304 alloc=24*4096
[ 0.000000] pcpu-alloc: [0] 0 [0] 1 [0] 2 [0] 3
[ 0.000000] Detected VIPT I-cache on CPU0
[ 0.000000] CPU features: detected: GIC system register CPU interface
[ 0.000000] CPU features: detected: Virtualization Host Extensions
[ 0.000000] CPU features: detected: Qualcomm erratum 1009, or ARM erratum 1286807, 2441009
[ 0.000000] CPU features: detected: ARM errata 1165522, 1319367, or 1530923
[ 0.000000] alternatives: applying boot alternatives
[ 0.000000] Kernel command line: initrd=/initramfs-linux.img console=ttyS2,1500000 earlycon=uart8250,mmio32,0xfe660000 root=PARTUUID=cbc9819e-278b-44f3-a40c-1fe5f7ecf762 rw rootwait audit=0 splash plymouth.ignore-serial-consoles
[ 0.000000] audit: disabled (until reboot)
[ 0.000000] Unknown kernel command line parameters "splash", will be passed to user space.
[ 0.000000] printk: log buffer data + meta data: 262144 + 917504 = 1179648 bytes
[ 0.000000] Dentry cache hash table entries: 1048576 (order: 11, 8388608 bytes, linear)
[ 0.000000] Inode-cache hash table entries: 524288 (order: 10, 4194304 bytes, linear)
[ 0.000000] software IO TLB: area num 4.
[ 0.000000] software IO TLB: mapped [mem 0x00000000d8600000-0x00000000dc600000] (64MB)
[ 0.000000] Built 1 zonelists, mobility grouping on. Total pages: 2031104
[ 0.000000] mem auto-init: stack:off, heap alloc:off, heap free:off
[ 0.000000] SLUB: HWalign=64, Order=0-1, MinObjects=0, CPUs=4, Nodes=1
[ 0.000000] rcu: Preemptible hierarchical RCU implementation.
[ 0.000000] rcu: RCU restricting CPUs from NR_CPUS=8 to nr_cpu_ids=4.
[ 0.000000] Trampoline variant of Tasks RCU enabled.
[ 0.000000] Tracing variant of Tasks RCU enabled.
[ 0.000000] rcu: RCU calculated value of scheduler-enlistment delay is 30 jiffies.
[ 0.000000] rcu: Adjusting geometry for rcu_fanout_leaf=16, nr_cpu_ids=4
[ 0.000000] RCU Tasks: Setting shift to 2 and lim to 1 rcu_task_cb_adjust=1 rcu_task_cpu_ids=4.
[ 0.000000] RCU Tasks Trace: Setting shift to 2 and lim to 1 rcu_task_cb_adjust=1 rcu_task_cpu_ids=4.
[ 0.000000] NR_IRQS: 64, nr_irqs: 64, preallocated irqs: 0
[ 0.000000] GIC: enabling workaround for GICv3: non-coherent attribute
[ 0.000000] GICv3: GIC: Using split EOI/Deactivate mode
[ 0.000000] GICv3: 320 SPIs implemented
[ 0.000000] GICv3: 0 Extended SPIs implemented
[ 0.000000] GICv3: MBI range [296:319]
[ 0.000000] GICv3: Using MBI frame 0x00000000fd410000
[ 0.000000] Root IRQ handler: gic_handle_irq
[ 0.000000] GICv3: GICv3 features: 16 PPIs
[ 0.000000] GICv3: GICD_CTRL.DS=0, SCR_EL3.FIQ=1
[ 0.000000] GICv3: CPU0: found redistributor 0 region 0:0x00000000fd460000
[ 0.000000] ITS [mem 0xfd440000-0xfd45ffff]
[ 0.000000] GIC: enabling workaround for ITS: Rockchip erratum RK3568002
[ 0.000000] GIC: enabling workaround for ITS: non-coherent attribute
[ 0.000000] ITS@0x00000000fd440000: allocated 8192 Devices @410000 (indirect, esz 8, psz 64K, shr 0)
[ 0.000000] ITS@0x00000000fd440000: allocated 32768 Interrupt Collections @420000 (flat, esz 2, psz 64K, shr 0)
[ 0.000000] ITS: using cache flushing for cmd queue
[ 0.000000] GICv3: using LPI property table @0x0000000000430000
[ 0.000000] GIC: using cache flushing for LPI property table
[ 0.000000] GICv3: CPU0: using allocated LPI pending table @0x0000000000440000
[ 0.000000] rcu: srcu_init: Setting srcu_struct sizes based on contention.
[ 0.000000] arch_timer: cp15 timer(s) running at 24.00MHz (phys).
[ 0.000000] clocksource: arch_sys_counter: mask: 0xffffffffffffff max_cycles: 0x588fe9dc0, max_idle_ns: 440795202592 ns
[ 0.000001] sched_clock: 56 bits at 24MHz, resolution 41ns, wraps every 4398046511097ns
[ 0.002664] Console: colour dummy device 80x25
[ 0.002814] Calibrating delay loop (skipped), value calculated using timer frequency.. 48.00 BogoMIPS (lpj=80000)
[ 0.002839] pid_max: default: 32768 minimum: 301
[ 0.003005] LSM: initializing lsm=capability,landlock,yama,apparmor
[ 0.003235] landlock: Up and running.
[ 0.003245] Yama: becoming mindful.
[ 0.003620] AppArmor: AppArmor initialized
[ 0.003806] Mount-cache hash table entries: 16384 (order: 5, 131072 bytes, linear)
[ 0.003867] Mountpoint-cache hash table entries: 16384 (order: 5, 131072 bytes, linear)
[ 0.019668] rcu: Hierarchical SRCU implementation.
[ 0.019691] rcu: Max phase no-delay instances is 1000.
[ 0.020295] Timer migration: 1 hierarchy levels; 8 children per group; 1 crossnode level
[ 0.030353] EFI services will not be available.
[ 0.031089] smp: Bringing up secondary CPUs ...
[ 0.037720] Detected VIPT I-cache on CPU1
[ 0.037830] GICv3: CPU1: found redistributor 100 region 0:0x00000000fd480000
[ 0.037858] GICv3: CPU1: using allocated LPI pending table @0x0000000000450000
[ 0.037923] CPU1: Booted secondary processor 0x0000000100 [0x412fd050]
[ 0.040785] Detected VIPT I-cache on CPU2
[ 0.040882] GICv3: CPU2: found redistributor 200 region 0:0x00000000fd4a0000
[ 0.040905] GICv3: CPU2: using allocated LPI pending table @0x0000000000460000
[ 0.040959] CPU2: Booted secondary processor 0x0000000200 [0x412fd050]
[ 0.047298] Detected VIPT I-cache on CPU3
[ 0.047392] GICv3: CPU3: found redistributor 300 region 0:0x00000000fd4c0000
[ 0.047416] GICv3: CPU3: using allocated LPI pending table @0x0000000000470000
[ 0.047468] CPU3: Booted secondary processor 0x0000000300 [0x412fd050]
[ 0.047659] smp: Brought up 1 node, 4 CPUs
[ 0.047695] SMP: Total of 4 processors activated.
[ 0.047703] CPU: All CPU(s) started at EL2
[ 0.047712] CPU features: detected: 32-bit EL0 Support
[ 0.047719] CPU features: detected: 32-bit EL1 Support
[ 0.047728] CPU features: detected: Data cache clean to the PoU not required for I/D coherence
[ 0.047738] CPU features: detected: Common not Private translations
[ 0.047745] CPU features: detected: CRC32 instructions
[ 0.047761] CPU features: detected: RCpc load-acquire (LDAPR)
[ 0.047770] CPU features: detected: LSE atomic instructions
[ 0.047778] CPU features: detected: Privileged Access Never
[ 0.047786] CPU features: detected: PMUv3
[ 0.047793] CPU features: detected: RAS Extension Support
[ 0.047805] CPU features: detected: Speculative Store Bypassing Safe (SSBS)
[ 0.047895] alternatives: applying system-wide alternatives
[ 0.053532] Memory: 7595268K/8124416K available (18176K kernel code, 2850K rwdata, 8436K rodata, 2432K init, 740K bss, 263996K reserved, 262144K cma-reserved)
[ 0.056667] devtmpfs: initialized
[ 0.084334] clocksource: jiffies: mask: 0xffffffff max_cycles: 0xffffffff, max_idle_ns: 6370867519511994 ns
[ 0.084387] posixtimers hash table entries: 2048 (order: 3, 32768 bytes, linear)
[ 0.084440] futex hash table entries: 1024 (order: 4, 65536 bytes, linear)
[ 0.089143] 24560 pages in range for non-PLT usage
[ 0.089173] 516080 pages in range for PLT usage
[ 0.089590] pinctrl core: initialized pinctrl subsystem
[ 0.090794] DMI not present or invalid.
[ 0.094875] NET: Registered PF_NETLINK/PF_ROUTE protocol family
[ 0.096646] DMA: preallocated 1024 KiB GFP_KERNEL pool for atomic allocations
[ 0.097116] DMA: preallocated 1024 KiB GFP_KERNEL|GFP_DMA pool for atomic allocations
[ 0.097668] DMA: preallocated 1024 KiB GFP_KERNEL|GFP_DMA32 pool for atomic allocations
[ 0.099103] thermal_sys: Registered thermal governor 'fair_share'
[ 0.099117] thermal_sys: Registered thermal governor 'bang_bang'
[ 0.099127] thermal_sys: Registered thermal governor 'step_wise'
[ 0.099136] thermal_sys: Registered thermal governor 'user_space'
[ 0.099273] cpuidle: using governor ladder
[ 0.099344] cpuidle: using governor menu
[ 0.099771] hw-breakpoint: found 6 breakpoint and 4 watchpoint registers.
[ 0.100021] ASID allocator initialised with 65536 entries
[ 0.102347] Serial: AMBA PL011 UART driver
[ 0.118163] /vop@fe040000: Fixed dependency cycle(s) with /dsi@fe060000
[ 0.118299] /dsi@fe060000: Fixed dependency cycle(s) with /dsi@fe060000/panel@0
[ 0.118325] /dsi@fe060000: Fixed dependency cycle(s) with /vop@fe040000
[ 0.118534] /dsi@fe060000/panel@0: Fixed dependency cycle(s) with /dsi@fe060000
[ 0.119164] /vop@fe040000: Fixed dependency cycle(s) with /hdmi@fe0a0000
[ 0.119295] /hdmi@fe0a0000: Fixed dependency cycle(s) with /vop@fe040000
[ 0.125790] /pcie@fe260000: Fixed dependency cycle(s) with /pcie@fe260000/legacy-interrupt-controller
[ 0.150721] gpio gpiochip0: Static allocation of GPIO base is deprecated, use dynamic allocation.
[ 0.151682] rockchip-gpio fdd60000.gpio: probed /pinctrl/gpio@fdd60000
[ 0.152353] gpio gpiochip1: Static allocation of GPIO base is deprecated, use dynamic allocation.
[ 0.152793] rockchip-gpio fe740000.gpio: probed /pinctrl/gpio@fe740000
[ 0.153272] gpio gpiochip2: Static allocation of GPIO base is deprecated, use dynamic allocation.
[ 0.153714] rockchip-gpio fe750000.gpio: probed /pinctrl/gpio@fe750000
[ 0.154304] gpio gpiochip3: Static allocation of GPIO base is deprecated, use dynamic allocation.
[ 0.154780] rockchip-gpio fe760000.gpio: probed /pinctrl/gpio@fe760000
[ 0.155340] gpio gpiochip4: Static allocation of GPIO base is deprecated, use dynamic allocation.
[ 0.155762] rockchip-gpio fe770000.gpio: probed /pinctrl/gpio@fe770000
[ 0.159889] /hdmi@fe0a0000: Fixed dependency cycle(s) with /hdmi-connector
[ 0.160045] /hdmi-connector: Fixed dependency cycle(s) with /hdmi@fe0a0000
[ 0.168225] HugeTLB: allocation took 0ms with hugepage_allocation_threads=1
[ 0.168256] HugeTLB: allocation took 0ms with hugepage_allocation_threads=1
[ 0.168274] HugeTLB: registered 1.00 GiB page size, pre-allocated 0 pages
[ 0.168284] HugeTLB: 0 KiB vmemmap can be freed for a 1.00 GiB page
[ 0.168296] HugeTLB: registered 32.0 MiB page size, pre-allocated 0 pages
[ 0.168304] HugeTLB: 0 KiB vmemmap can be freed for a 32.0 MiB page
[ 0.168314] HugeTLB: registered 2.00 MiB page size, pre-allocated 0 pages
[ 0.168322] HugeTLB: 0 KiB vmemmap can be freed for a 2.00 MiB page
[ 0.168332] HugeTLB: registered 64.0 KiB page size, pre-allocated 0 pages
[ 0.168339] HugeTLB: 0 KiB vmemmap can be freed for a 64.0 KiB page
[ 0.169263] cryptd: max_cpu_qlen set to 1000
[ 0.171407] ACPI: Interpreter disabled.
[ 0.172076] iommu: Default domain type: Translated
[ 0.172093] iommu: DMA domain TLB invalidation policy: strict mode
[ 0.173534] SCSI subsystem initialized
[ 0.173855] libata version 3.00 loaded.
[ 0.174250] usbcore: registered new interface driver usbfs
[ 0.174322] usbcore: registered new interface driver hub
[ 0.174381] usbcore: registered new device driver usb
[ 0.175367] pps_core: LinuxPPS API ver. 1 registered
[ 0.175382] pps_core: Software ver. 5.3.6 - Copyright 2005-2007 Rodolfo Giometti <giometti@linux.it>
[ 0.175418] PTP clock support registered
[ 0.175800] scmi_core: SCMI protocol bus registered
[ 0.176502] Advanced Linux Sound Architecture Driver Initialized.
[ 0.177916] NetLabel: Initializing
[ 0.177929] NetLabel: domain hash size = 128
[ 0.177983] NetLabel: protocols = UNLABELED CIPSOv4 CALIPSO
[ 0.178134] NetLabel: unlabeled traffic allowed by default
[ 0.178464] vgaarb: loaded
[ 0.179269] clocksource: Switched to clocksource arch_sys_counter
[ 0.179804] VFS: Disk quotas dquot_6.6.0
[ 0.179854] VFS: Dquot-cache hash table entries: 512 (order 0, 4096 bytes)
[ 0.180912] AppArmor: AppArmor Filesystem Enabled
[ 0.181050] pnp: PnP ACPI: disabled
[ 0.197870] NET: Registered PF_INET protocol family
[ 0.198431] IP idents hash table entries: 131072 (order: 8, 1048576 bytes, linear)
[ 0.206544] tcp_listen_portaddr_hash hash table entries: 4096 (order: 4, 65536 bytes, linear)
[ 0.206648] Table-perturb hash table entries: 65536 (order: 6, 262144 bytes, linear)
[ 0.206701] TCP established hash table entries: 65536 (order: 7, 524288 bytes, linear)
[ 0.207240] TCP bind hash table entries: 65536 (order: 9, 2097152 bytes, linear)
[ 0.209607] TCP: Hash tables configured (established 65536 bind 65536)
[ 0.209864] UDP hash table entries: 4096 (order: 6, 262144 bytes, linear)
[ 0.210199] UDP-Lite hash table entries: 4096 (order: 6, 262144 bytes, linear)
[ 0.210868] NET: Registered PF_UNIX/PF_LOCAL protocol family
[ 0.211908] RPC: Registered named UNIX socket transport module.
[ 0.211926] RPC: Registered udp transport module.
[ 0.211935] RPC: Registered tcp transport module.
[ 0.211943] RPC: Registered tcp-with-tls transport module.
[ 0.211950] RPC: Registered tcp NFSv4.1 backchannel transport module.
[ 0.211965] NET: Registered PF_XDP protocol family
[ 0.211993] PCI: CLS 0 bytes, default 64
[ 0.212406] Trying to unpack rootfs image as initramfs...
[ 0.218303] kvm [1]: nv: 566 coarse grained trap handlers
[ 0.219040] kvm [1]: IPA Size Limit: 40 bits
[ 0.219093] kvm [1]: GICv3: no GICV resource entry
[ 0.219105] kvm [1]: disabling GICv2 emulation
[ 0.219154] kvm [1]: GIC system register CPU interface enabled
[ 0.219203] kvm [1]: vgic interrupt IRQ9
[ 0.219362] kvm [1]: VHE mode initialized successfully
[ 0.222823] Initialise system trusted keyrings
[ 0.223290] workingset: timestamp_bits=46 max_order=21 bucket_order=0
[ 0.224367] squashfs: version 4.0 (2009/01/31) Phillip Lougher
[ 0.225132] NFS: Registering the id_resolver key type
[ 0.225212] Key type id_resolver registered
[ 0.225224] Key type id_legacy registered
[ 0.225271] nfs4filelayout_init: NFSv4 File Layout Driver Registering...
[ 0.225295] nfs4flexfilelayout_init: NFSv4 Flexfile Layout Driver Registering...
[ 0.670816] Freeing initrd memory: 8476K
[ 0.847567] NET: Registered PF_ALG protocol family
[ 0.847616] Key type asymmetric registered
[ 0.847627] Asymmetric key parser 'x509' registered
[ 0.847637] Asymmetric key parser 'pkcs8' registered
[ 0.847847] Block layer SCSI generic (bsg) driver version 0.4 loaded (major 246)
[ 0.848175] io scheduler mq-deadline registered
[ 0.848192] io scheduler kyber registered
[ 0.848284] io scheduler bfq registered
[ 0.874387] ledtrig-cpu: registered to indicate activity on CPUs
[ 0.893014] dma-pl330 fe530000.dma-controller: Loaded driver for PL330 DMAC-241330
[ 0.893049] dma-pl330 fe530000.dma-controller: DBUFF-128x8bytes Num_Chans-8 Num_Peri-32 Num_Events-16
[ 0.896214] dma-pl330 fe550000.dma-controller: Loaded driver for PL330 DMAC-241330
[ 0.896240] dma-pl330 fe550000.dma-controller: DBUFF-128x8bytes Num_Chans-8 Num_Peri-32 Num_Events-16
[ 0.907139] Serial: 8250/16550 driver, 4 ports, IRQ sharing enabled
[ 0.911959] printk: legacy console [ttyS2] disabled
[ 0.912532] fe660000.serial: ttyS2 at MMIO 0xfe660000 (irq = 25, base_baud = 1500000) is a 16550A
[ 0.912900] printk: legacy console [ttyS2] enabled
[ 0.912918] printk: legacy bootconsole [uart8250] disabled
[ 0.918006] Serial: AMBA driver
[ 0.921899] platform fdea0000.video-codec: Adding to iommu group 0
[ 0.923737] platform fdf80100.video-decoder: Adding to iommu group 1
[ 0.925302] platform fe040000.vop: Adding to iommu group 2
[ 0.950944] spi-nor spi4.0: supply vcc not found, using dummy regulator
[ 0.967449] usbcore: registered new interface driver uas
[ 0.967559] usbcore: registered new interface driver usb-storage
[ 0.967753] usbcore: registered new interface driver usbserial_generic
[ 0.967809] usbserial: USB Serial support registered for generic
[ 0.971546] mousedev: PS/2 mouse device common for all mice
[ 0.972899] i2c_dev: i2c /dev entries driver
[ 0.975745] /i2c@fdd40000/pmic@20: Fixed dependency cycle(s) with /i2c@fdd40000/pmic@20/regulators/BOOST
[ 0.986591] usbcore: registered new interface driver pcwd_usb
[ 0.986686] device-mapper: uevent: version 1.0.3
[ 0.987174] device-mapper: ioctl: 4.49.0-ioctl (2025-01-17) initialised: dm-devel@lists.linux.dev
[ 0.990642] sdhci: Secure Digital Host Controller Interface driver
[ 0.990669] sdhci: Copyright(c) Pierre Ossman
[ 0.991442] Synopsys Designware Multimedia Card Interface Driver
[ 0.994328] sdhci-pltfm: SDHCI platform and OF driver helper
[ 0.997272] No iBFT detected.
[ 0.999128] arm-scmi arm-scmi.0.auto: Using scmi_smc_transport
[ 0.999156] arm-scmi arm-scmi.0.auto: SCMI max-rx-timeout: 30ms / max-msg-size: 104bytes / max-msg: 20
[ 0.999469] scmi_protocol scmi_dev.1: Enabled polling mode TX channel - prot_id:16
[ 1.000182] arm-scmi arm-scmi.0.auto: SCMI RAW Mode initialized for instance 0
[ 1.000201] arm-scmi arm-scmi.0.auto: SCMI RAW Mode COEX enabled !
[ 1.000336] arm-scmi arm-scmi.0.auto: SCMI Notifications - Core Enabled.
[ 1.000422] arm-scmi arm-scmi.0.auto: SCMI Protocol v2.0 'rockchip:' Firmware version 0x0
[ 1.003537] SMCCC: SOC_ID: ARCH_SOC_ID not implemented, skipping ....
[ 1.004109] hid: raw HID events driver (C) Jiri Kosina
[ 1.004419] usbcore: registered new interface driver usbhid
[ 1.004433] usbhid: USB HID core driver
[ 1.010598] hw perfevents: enabled with armv8_cortex_a55 PMU driver, 7 (0,8000003f) counters available
[ 1.011827] watchdog: NMI not fully supported
[ 1.011841] watchdog: Hard watchdog permanently disabled
[ 1.020129] NET: Registered PF_INET6 protocol family
[ 1.052051] Segment Routing with IPv6
[ 1.052202] In-situ OAM (IOAM) with IPv6
[ 1.052320] mip6: Mobile IPv6
[ 1.052356] NET: Registered PF_PACKET protocol family
[ 1.052681] Key type dns_resolver registered
[ 1.072705] registered taskstats version 1
[ 1.072942] Loading compiled-in X.509 certificates
[ 1.073027] debug_vm_pgtable: [debug_vm_pgtable ]: Validating architecture page table helpers
[ 1.073372] Key type .fscrypt registered
[ 1.073386] Key type fscrypt-provisioning registered
[ 1.074629] Key type encrypted registered
[ 1.165885] fan53555-regulator 0-001c: FAN53555 Option[12] Rev[15] Detected!
[ 1.205174] boost: Bringing 4700000uV into 5000000-5000000uV
[ 1.211120] input: rk805 pwrkey as /devices/platform/fdd40000.i2c/i2c-0/0-0020/rk805-pwrkey.3.auto/input/input0
[ 1.232613] dwmmc_rockchip fe2c0000.mmc: IDMAC supports 32-bit address mode.
[ 1.232692] dwmmc_rockchip fe2c0000.mmc: Using internal DMA controller.
[ 1.232702] dwmmc_rockchip fe2c0000.mmc: Version ID is 270a
[ 1.232755] dwmmc_rockchip fe2c0000.mmc: DW MMC controller at irq 63,32 bit host data width,256 deep fifo
[ 1.233264] dwmmc_rockchip fe2c0000.mmc: Failed getting OCR mask: -22
[ 1.233339] mmc_host mmc2: card is non-removable.
[ 1.233448] dwmmc_rockchip fe2c0000.mmc: could not set regulator OCR (-22)
[ 1.233456] dwmmc_rockchip fe2c0000.mmc: failed to enable vmmc regulator
[ 1.235372] regulator-vcc3v3-sd enforce active low on GPIO handle
[ 1.242247] rockchip-dw-pcie 3c0000000.pcie: host bridge /pcie@fe260000 ranges:
[ 1.242292] rockchip-dw-pcie 3c0000000.pcie: IO 0x00f4100000..0x00f41fffff -> 0x00f4100000
[ 1.242309] rockchip-dw-pcie 3c0000000.pcie: MEM 0x00f4200000..0x00f5ffffff -> 0x00f4200000
[ 1.242319] rockchip-dw-pcie 3c0000000.pcie: MEM 0x0300000000..0x033fffffff -> 0x0040000000
[ 1.242488] rockchip-dw-pcie 3c0000000.pcie: iATU: unroll T, 8 ob, 8 ib, align 64K, limit 8G
[ 1.249308] mmc_host mmc2: Bus speed (slot 0) = 375000Hz (slot req 400000Hz, actual 375000HZ div = 0)
[ 1.277700] dwmmc_rockchip fe2c0000.mmc: could not set regulator OCR (-22)
[ 1.277709] dwmmc_rockchip fe2c0000.mmc: failed to enable vmmc regulator
[ 1.290785] mmc_host mmc2: Bus speed (slot 0) = 375000Hz (slot req 375000Hz, actual 375000HZ div = 0)
[ 1.319131] mmc2: Failed to initialize a non-removable card
[ 1.343073] rockchip-dw-pcie 3c0000000.pcie: PCI host bridge to bus 0000:00
[ 1.343099] pci_bus 0000:00: root bus resource [bus 00-0f]
[ 1.343110] pci_bus 0000:00: root bus resource [io 0x0000-0xfffff] (bus address [0xf4100000-0xf41fffff])
[ 1.343117] pci_bus 0000:00: root bus resource [mem 0xf4200000-0xf5ffffff]
[ 1.343124] pci_bus 0000:00: root bus resource [mem 0x300000000-0x33fffffff] (bus address [0x40000000-0x7fffffff])
[ 1.343166] pci 0000:00:00.0: [1d87:3566] type 01 class 0x060400 PCIe Root Port
[ 1.343189] pci 0000:00:00.0: ROM [mem 0x00000000-0x0000ffff pref]
[ 1.343197] pci 0000:00:00.0: PCI bridge to [bus 01-ff]
[ 1.343206] pci 0000:00:00.0: bridge window [io 0x0000-0x0fff]
[ 1.343213] pci 0000:00:00.0: bridge window [mem 0x00000000-0x000fffff]
[ 1.343223] pci 0000:00:00.0: bridge window [mem 0x00000000-0x000fffff 64bit pref]
[ 1.343283] pci 0000:00:00.0: supports D1 D2
[ 1.343289] pci 0000:00:00.0: PME# supported from D0 D1 D3hot
[ 1.347656] pci_bus 0000:01: busn_res: can not insert [bus 01-ff] under [bus 00-0f] (conflicts with (null) [bus 00-0f])
[ 1.347882] pci 0000:00:00.0: ROM [mem 0xf4200000-0xf420ffff pref]: assigned
[ 1.347900] pci 0000:00:00.0: PCI bridge to [bus 01-ff]
[ 1.347915] pci_bus 0000:00: resource 4 [io 0x0000-0xfffff]
[ 1.347922] pci_bus 0000:00: resource 5 [mem 0xf4200000-0xf5ffffff]
[ 1.347928] pci_bus 0000:00: resource 6 [mem 0x300000000-0x33fffffff]
[ 1.350236] pcieport 0000:00:00.0: PME: Signaling with IRQ 67
[ 1.350598] pcieport 0000:00:00.0: AER: enabled with IRQ 76
[ 1.363164] xhci-hcd xhci-hcd.7.auto: xHCI Host Controller
[ 1.363404] xhci-hcd xhci-hcd.7.auto: new USB bus registered, assigned bus number 1
[ 1.363529] xhci-hcd xhci-hcd.7.auto: hcc params 0x0220fe64 hci version 0x110 quirks 0x0000808002000010
[ 1.363577] xhci-hcd xhci-hcd.7.auto: irq 78, io mem 0xfd000000
[ 1.363694] xhci-hcd xhci-hcd.7.auto: xHCI Host Controller
[ 1.363815] xhci-hcd xhci-hcd.7.auto: new USB bus registered, assigned bus number 2
[ 1.363827] xhci-hcd xhci-hcd.7.auto: Host supports USB 3.0 SuperSpeed
[ 1.363994] usb usb1: New USB device found, idVendor=1d6b, idProduct=0002, bcdDevice= 6.15
[ 1.364004] usb usb1: New USB device strings: Mfr=3, Product=2, SerialNumber=1
[ 1.364010] usb usb1: Product: xHCI Host Controller
[ 1.364015] usb usb1: Manufacturer: Linux 6.15.0-rc6-1-MANJARO-ARM xhci-hcd
[ 1.364020] usb usb1: SerialNumber: xhci-hcd.7.auto
[ 1.364402] hub 1-0:1.0: USB hub found
[ 1.364433] hub 1-0:1.0: 1 port detected
[ 1.364713] usb usb2: We don't know the algorithms for LPM for this host, disabling LPM.
[ 1.364823] usb usb2: New USB device found, idVendor=1d6b, idProduct=0003, bcdDevice= 6.15
[ 1.364832] usb usb2: New USB device strings: Mfr=3, Product=2, SerialNumber=1
[ 1.364838] usb usb2: Product: xHCI Host Controller
[ 1.364843] usb usb2: Manufacturer: Linux 6.15.0-rc6-1-MANJARO-ARM xhci-hcd
[ 1.364848] usb usb2: SerialNumber: xhci-hcd.7.auto
[ 1.365166] hub 2-0:1.0: USB hub found
[ 1.365194] hub 2-0:1.0: 1 port detected
[ 1.369328] ehci-platform fd800000.usb: EHCI Host Controller
[ 1.369517] ohci-platform fd840000.usb: Generic Platform OHCI controller
[ 1.369597] dwmmc_rockchip fe2b0000.mmc: IDMAC supports 32-bit address mode.
[ 1.369666] dwmmc_rockchip fe2b0000.mmc: Using internal DMA controller.
[ 1.369676] dwmmc_rockchip fe2b0000.mmc: Version ID is 270a
[ 1.369729] dwmmc_rockchip fe2b0000.mmc: DW MMC controller at irq 81,32 bit host data width,256 deep fifo
[ 1.369805] ohci-platform fd840000.usb: new USB bus registered, assigned bus number 4
[ 1.369909] ohci-platform fd840000.usb: irq 80, io mem 0xfd840000
[ 1.369949] ehci-platform fd800000.usb: new USB bus registered, assigned bus number 3
[ 1.370040] ehci-platform fd800000.usb: irq 79, io mem 0xfd800000
[ 1.372093] dwmmc_rockchip fe2b0000.mmc: Got CD GPIO
[ 1.373792] of_cfs_init
[ 1.373837] of_cfs_init: OK
[ 1.373980] clk: Disabling unused clocks
[ 1.374886] PM: genpd: Disabling unused power domains
[ 1.374932] ALSA device list:
[ 1.374941] No soundcards found.
[ 1.375122] dw-apb-uart fe660000.serial: forbid DMA for kernel console
[ 1.379338] ehci-platform fd800000.usb: USB 2.0 started, EHCI 1.00
[ 1.379580] usb usb3: New USB device found, idVendor=1d6b, idProduct=0002, bcdDevice= 6.15
[ 1.379590] usb usb3: New USB device strings: Mfr=3, Product=2, SerialNumber=1
[ 1.379596] usb usb3: Product: EHCI Host Controller
[ 1.379601] usb usb3: Manufacturer: Linux 6.15.0-rc6-1-MANJARO-ARM ehci_hcd
[ 1.379606] usb usb3: SerialNumber: fd800000.usb
[ 1.380072] hub 3-0:1.0: USB hub found
[ 1.380105] hub 3-0:1.0: 1 port detected
[ 1.382685] mmc_host mmc1: Bus speed (slot 0) = 375000Hz (slot req 400000Hz, actual 375000HZ div = 0)
[ 1.402333] mmc0: SDHCI controller on fe310000.mmc [fe310000.mmc] using ADMA
[ 1.426991] usb usb4: New USB device found, idVendor=1d6b, idProduct=0001, bcdDevice= 6.15
[ 1.427027] usb usb4: New USB device strings: Mfr=3, Product=2, SerialNumber=1
[ 1.427042] usb usb4: Product: Generic Platform OHCI controller
[ 1.427134] usb usb4: Manufacturer: Linux 6.15.0-rc6-1-MANJARO-ARM ohci_hcd
[ 1.427149] usb usb4: SerialNumber: fd840000.usb
[ 1.428081] hub 4-0:1.0: USB hub found
[ 1.428157] hub 4-0:1.0: 1 port detected
[ 1.431409] Freeing unused kernel memory: 2432K
[ 1.431698] Run /init as init process
[ 1.431711] with arguments:
[ 1.431722] /init
[ 1.431732] splash
[ 1.431740] with environment:
[ 1.431748] HOME=/
[ 1.431756] TERM=linux
[ 1.479980] mmc0: new HS200 MMC card at address 0001
[ 1.485009] mmcblk0: mmc0:0001 SPeMMC 116 GiB
[ 1.491801] mmcblk0: p1 p2
[ 1.495463] mmcblk0boot0: mmc0:0001 SPeMMC 4.00 MiB
[ 1.499750] mmcblk0boot1: mmc0:0001 SPeMMC 4.00 MiB
[ 1.503850] mmcblk0rpmb: mmc0:0001 SPeMMC 4.00 MiB, chardev (240:0)
[ 1.606224] usb 1-1: new high-speed USB device number 2 using xhci-hcd
[ 1.727296] rk808-rtc rk808-rtc.4.auto: registered as rtc0
[ 1.728240] rk808-rtc rk808-rtc.4.auto: setting system clock to 2025-05-12T14:55:30 UTC (1747061730)
[ 1.743283] usb 1-1: New USB device found, idVendor=2357, idProduct=0109, bcdDevice= 2.00
[ 1.743305] usb 1-1: New USB device strings: Mfr=1, Product=2, SerialNumber=3
[ 1.743312] usb 1-1: Product: 802.11n NIC
[ 1.743317] usb 1-1: Manufacturer: Realtek
[ 1.743322] usb 1-1: SerialNumber: 00e04c000001
[ 1.915971] usb 4-1: new full-speed USB device number 2 using ohci-platform
[ 2.120045] usb 4-1: New USB device found, idVendor=1018, idProduct=1006, bcdDevice= 1.06
[ 2.120068] usb 4-1: New USB device strings: Mfr=0, Product=0, SerialNumber=0
[ 2.127898] input: HID 1018:1006 as /devices/platform/fd840000.usb/usb4/4-1/4-1:1.0/0003:1018:1006.0001/input/input1
[ 2.240305] hid-generic 0003:1018:1006.0001: input,hidraw0: USB HID v1.11 Keyboard [HID 1018:1006] on usb-fd840000.usb-1/input0
[ 2.278492] input: HID 1018:1006 Mouse as /devices/platform/fd840000.usb/usb4/4-1/4-1:1.1/0003:1018:1006.0002/input/input2
[ 2.278914] input: HID 1018:1006 Touchpad as /devices/platform/fd840000.usb/usb4/4-1/4-1:1.1/0003:1018:1006.0002/input/input3
[ 2.279907] input: HID 1018:1006 System Control as /devices/platform/fd840000.usb/usb4/4-1/4-1:1.1/0003:1018:1006.0002/input/input4
[ 2.333157] input: HID 1018:1006 Consumer Control as /devices/platform/fd840000.usb/usb4/4-1/4-1:1.1/0003:1018:1006.0002/input/input5
[ 2.333543] hid-multitouch 0003:1018:1006.0002: input,hiddev96,hidraw1: USB HID v1.11 Mouse [HID 1018:1006] on usb-fd840000.usb-1/input1
[ 2.931700] panfrost fde60000.gpu: clock rate = 594000000
[ 2.931750] panfrost fde60000.gpu: bus_clock rate = 500000000
[ 2.939080] panfrost fde60000.gpu: mali-g52 id 0x7402 major 0x1 minor 0x0 status 0x0
[ 2.939105] panfrost fde60000.gpu: features: 00000000,00000cf7, issues: 00000000,00000400
[ 2.939112] panfrost fde60000.gpu: Features: L2:0x07110206 Shader:0x00000002 Tiler:0x00000209 Mem:0x1 MMU:0x00002823 AS:0xff JS:0x7
[ 2.939120] panfrost fde60000.gpu: shader_present=0x1 l2_present=0x1
[ 2.947697] [drm] Initialized panfrost 1.3.0 for fde60000.gpu on minor 0
[ 2.990917] input: gpio-keys as /devices/platform/gpio-keys/input/input6
[ 3.557804] EXT4-fs (mmcblk0p2): mounted filesystem ad8a83af-2277-4917-ba84-6bee1313a2b1 r/w with ordered data mode. Quota mode: none.
[ 4.123079] systemd[1]: systemd 257.5-2-arch running in system mode (+PAM +AUDIT -SELINUX -APPARMOR -IMA +IPE +SMACK +SECCOMP +GCRYPT +GNUTLS +OPENSSL +ACL +BLKID +CURL +ELFUTILS +FIDO2 +IDN2 -IDN +IPTC +KMOD +LIBCRYPTSETUP +LIBCRYPTSETUP_PLUGINS +LIBFDISK +PCRE2 +PWQUALITY +P11KIT +QRENCODE +TPM2 +BZIP2 +LZ4 +XZ +ZLIB +ZSTD +BPF_FRAMEWORK -BTF +XKBCOMMON +UTMP -SYSVINIT +LIBARCHIVE)
[ 4.123232] systemd[1]: Detected architecture arm64.
[ 4.153901] systemd[1]: Hostname set to <manjaropt2>.
[ 4.521645] systemd[1]: bpf-restrict-fs: BPF LSM hook not enabled in the kernel, BPF LSM not supported.
[ 5.278122] systemd[1]: Queued start job for default target Graphical Interface.
[ 5.348416] systemd[1]: Created slice Slice /system/dirmngr.
[ 5.362314] systemd[1]: Created slice Slice /system/getty.
[ 5.366506] systemd[1]: Created slice Slice /system/gpg-agent.
[ 5.379462] systemd[1]: Created slice Slice /system/gpg-agent-browser.
[ 5.393058] systemd[1]: Created slice Slice /system/gpg-agent-extra.
[ 5.407408] systemd[1]: Created slice Slice /system/gpg-agent-ssh.
[ 5.420729] systemd[1]: Created slice Slice /system/keyboxd.
[ 5.434316] systemd[1]: Created slice Slice /system/modprobe.
[ 5.440036] systemd[1]: Created slice Slice /system/serial-getty.
[ 5.454199] systemd[1]: Created slice User and Session Slice.
[ 5.456655] systemd[1]: Started Forward Password Requests to Wall Directory Watch.
[ 5.468906] systemd[1]: Set up automount Arbitrary Executable File Formats File System Automount Point.
[ 5.479803] systemd[1]: Expecting device /dev/disk/by-partuuid/2c1c81c7-11c5-49f6-b299-7b499cef470c...
[ 5.489648] systemd[1]: Expecting device /dev/ttyS2...
[ 5.490984] systemd[1]: Reached target Local Integrity Protected Volumes.
[ 5.500112] systemd[1]: Reached target Remote Encrypted Volumes.
[ 5.509841] systemd[1]: Reached target Remote File Systems.
[ 5.511331] systemd[1]: Reached target Slice Units.
[ 5.512953] systemd[1]: Reached target Swaps.
[ 5.514508] systemd[1]: Reached target Local Verity Protected Volumes.
[ 5.525062] systemd[1]: Listening on Device-mapper event daemon FIFOs.
[ 5.582702] systemd[1]: Listening on Process Core Dump Socket.
[ 5.601977] systemd[1]: Listening on Credential Encryption/Decryption.
[ 5.625766] systemd[1]: Journal Audit Socket was skipped because of an unmet condition check (ConditionSecurity=audit).
[ 5.628641] systemd[1]: Listening on Journal Socket (/dev/log).
[ 5.632725] systemd[1]: Listening on Journal Sockets.
[ 5.635825] systemd[1]: Listening on DDI File System Mounter Socket.
[ 5.649057] systemd[1]: Listening on Network Service Netlink Socket.
[ 5.661398] systemd[1]: Listening on Namespace Resource Manager Socket.
[ 5.672756] systemd[1]: Listening on Userspace Out-Of-Memory (OOM) Killer Socket.
[ 5.683226] systemd[1]: TPM PCR Measurements was skipped because of an unmet condition check (ConditionSecurity=measured-uki).
[ 5.683565] systemd[1]: Make TPM PCR Policy was skipped because of an unmet condition check (ConditionSecurity=measured-uki).
[ 5.685581] systemd[1]: Listening on udev Control Socket.
[ 5.688386] systemd[1]: Listening on udev Kernel Socket.
[ 5.691769] systemd[1]: Listening on User Database Manager Socket.
[ 5.720781] systemd[1]: Mounting Huge Pages File System...
[ 5.735333] systemd[1]: Mounting POSIX Message Queue File System...
[ 5.814634] systemd[1]: Mounting Kernel Debug File System...
[ 5.823727] systemd[1]: Kernel Trace File System was skipped because of an unmet condition check (ConditionPathExists=/sys/kernel/tracing).
[ 5.830892] systemd[1]: Mounting Temporary Directory /tmp...
[ 5.839350] systemd[1]: Starting Create List of Static Device Nodes...
[ 5.847155] systemd[1]: Starting Load Kernel Module configfs...
[ 5.854122] systemd[1]: Starting Load Kernel Module dm_mod...
[ 5.864930] systemd[1]: Starting Load Kernel Module drm...
[ 5.880097] systemd[1]: Starting Load Kernel Module efi_pstore...
[ 5.893528] systemd[1]: Starting Load Kernel Module fuse...
[ 5.909448] systemd[1]: Starting Load Kernel Module loop...
[ 5.920256] systemd[1]: File System Check on Root Device was skipped because of an unmet condition check (ConditionPathIsReadWrite=!/).
[ 5.920610] systemd[1]: Clear Stale Hibernate Storage Info was skipped because of an unmet condition check (ConditionPathExists=/sys/firmware/efi/efivars/HibernateLocation-8cf2644b-4b0b-428f-9387-6d876050dc67).
[ 5.928999] systemd[1]: Starting Journal Service...
[ 5.941660] fuse: init (API version 7.43)
[ 5.946889] systemd[1]: Starting Load Kernel Modules...
[ 5.954709] loop: module loaded
[ 5.960709] systemd[1]: Starting Generate network units from Kernel command line...
[ 5.985826] systemd[1]: Starting Userspace Out-Of-Memory (OOM) Killer...
[ 5.987718] systemd[1]: TPM PCR Machine ID Measurement was skipped because of an unmet condition check (ConditionSecurity=measured-uki).
[ 5.996071] systemd[1]: Starting Remount Root and Kernel File Systems...
[ 5.997403] systemd[1]: Early TPM SRK Setup was skipped because of an unmet condition check (ConditionSecurity=measured-uki).
[ 6.007283] systemd[1]: Starting Load udev Rules from Credentials...
[ 6.026741] systemd[1]: Starting Coldplug All udev Devices...
[ 6.046270] systemd[1]: Starting Virtual Console Setup...
[ 6.051976] systemd-journald[362]: Collecting audit messages is disabled.
[ 6.078865] systemd[1]: Mounted Huge Pages File System.
[ 6.083758] systemd[1]: Mounted POSIX Message Queue File System.
[ 6.087700] systemd[1]: Mounted Kernel Debug File System.
[ 6.091810] systemd[1]: Mounted Temporary Directory /tmp.
[ 6.094615] systemd[1]: Finished Create List of Static Device Nodes.
[ 6.109928] systemd[1]: modprobe@configfs.service: Deactivated successfully.
[ 6.114142] systemd[1]: Finished Load Kernel Module configfs.
[ 6.115653] systemd[1]: modprobe@dm_mod.service: Deactivated successfully.
[ 6.116689] systemd[1]: Finished Load Kernel Module dm_mod.
[ 6.118139] systemd[1]: modprobe@drm.service: Deactivated successfully.
[ 6.119000] systemd[1]: Finished Load Kernel Module drm.
[ 6.119964] EXT4-fs (mmcblk0p2): re-mounted ad8a83af-2277-4917-ba84-6bee1313a2b1.
[ 6.124663] systemd[1]: modprobe@efi_pstore.service: Deactivated successfully.
[ 6.125730] systemd[1]: Finished Load Kernel Module efi_pstore.
[ 6.127439] systemd[1]: modprobe@fuse.service: Deactivated successfully.
[ 6.129445] systemd[1]: Finished Load Kernel Module fuse.
[ 6.131007] systemd[1]: modprobe@loop.service: Deactivated successfully.
[ 6.132152] systemd[1]: Finished Load Kernel Module loop.
[ 6.133917] systemd[1]: Finished Load Kernel Modules.
[ 6.135884] systemd[1]: Finished Generate network units from Kernel command line.
[ 6.139376] systemd[1]: Finished Remount Root and Kernel File Systems.
[ 6.141310] systemd[1]: Finished Load udev Rules from Credentials.
[ 6.154130] systemd[1]: Mounting FUSE Control File System...
[ 6.163764] systemd[1]: Mounting Kernel Configuration File System...
[ 6.166433] systemd[1]: Rebuild Hardware Database was skipped because of an unmet condition check (ConditionNeedsUpdate=/etc).
[ 6.187934] systemd[1]: Starting Namespace Resource Manager...
[ 6.188237] systemd[1]: Platform Persistent Storage Archival was skipped because of an unmet condition check (ConditionDirectoryNotEmpty=/sys/fs/pstore).
[ 6.231920] systemd[1]: Starting Load/Save OS Random Seed...
[ 6.232339] systemd[1]: Repartition Root Disk was skipped because no trigger condition checks were met.
[ 6.239697] systemd[1]: Starting Apply Kernel Variables...
[ 6.276028] systemd[1]: Starting Create Static Device Nodes in /dev gracefully...
[ 6.286336] systemd[1]: TPM SRK Setup was skipped because of an unmet condition check (ConditionSecurity=measured-uki).
[ 6.302836] systemd[1]: Starting User Database Manager...
[ 6.305818] systemd[1]: Started Journal Service.
[ 6.529432] systemd-journald[362]: Received client request to flush runtime journal.
[ 8.532662] random: crng init done
[ 8.848226] mc: Linux media interface: v0.10
[ 8.894030] videodev: Linux video capture interface: v2.00
[ 8.906479] platform regulatory.0: loading /lib/firmware/6.15.0-rc6-1-MANJARO-ARM/regulatory.db failed with error -20
[ 8.994761] input: rk817_ext Headphones as /devices/platform/rk817-sound/sound/card0/input7
[ 9.021834] input: adc-keys as /devices/platform/adc-keys/input/input8
[ 9.126830] hantro-vpu fdea0000.video-codec: registered rockchip,rk3568-vpu-dec as /dev/video0
[ 9.134699] usb 1-1: RTL8192EU rev B (SMIC) romver 0, 2T2R, TX queues 3, WiFi=1, BT=0, GPS=0, HI PA=0
[ 9.134730] usb 1-1: RTL8192EU MAC: 50:3e:aa:b6:8b:a2
[ 9.134738] usb 1-1: rtl8xxxu: Loading firmware rtlwifi/rtl8192eu_nic.bin
[ 9.134808] usb 1-1: loading /lib/firmware/6.15.0-rc6-1-MANJARO-ARM/rtlwifi/rtl8192eu_nic.bin failed with error -20
[ 9.139676] usb 1-1: Firmware revision 35.7 (signature 0x92e1)
[ 9.259342] rcu: INFO: rcu_preempt detected expedited stalls on CPUs/tasks: { P448 } 7 jiffies s: 349 root: 0x0/T
[ 9.259379] rcu: blocking rcu_node structures (internal RCU debug):
[ 9.293152] iio iio:device1: interrupts on the falling edge or active low level
[ 9.391146] Goodix-TS 1-005d: ID 911, version: 1060
[ 9.391306] Goodix-TS 1-005d: loading /lib/firmware/6.15.0-rc6-1-MANJARO-ARM/goodix_911_cfg.bin failed with error -20
[ 9.396909] Goodix-TS 1-005d: loading /lib/firmware/6.15.0-rc6-1-MANJARO-ARM/goodix_911_cfg.bin.zst failed with error -20
[ 9.397023] Goodix-TS 1-005d: loading /lib/firmware/6.15.0-rc6-1-MANJARO-ARM/goodix_911_cfg.bin.xz failed with error -20
[ 9.397055] Goodix-TS 1-005d: Direct firmware load for goodix_911_cfg.bin failed with error -2
[ 9.397064] Goodix-TS 1-005d: Falling back to sysfs fallback for: goodix_911_cfg.bin
[ 9.508370] zram: Added device: zram0
[ 9.537534] zram0: detected capacity change from 0 to 23613984
[ 9.606750] Adding 11806988k swap on /dev/zram0. Priority:100 extents:1 across:11806988k SS
[ 10.401547] usbcore: registered new interface driver rtl8xxxu
[ 10.450653] rtl8xxxu 1-1:1.0 wlu1: renamed from wlan0
[ 20.536660] dw-mipi-dsi-rockchip fe060000.dsi: [drm:dw_mipi_dsi_rockchip_probe] *ERROR* failed to get mipi dphy: -517
[ 20.537950] platform fe060000.dsi: deferred probe pending: (reason unknown)
[ 20.537967] platform hdmi-sound: deferred probe pending: asoc-simple-card: parse error
[ 27.396110] systemd-journald[362]: Failed to set ACL on /var/log/journal/ed2d96fea5054c68b2d2ae15cbfd0e40/user-1001.journal, ignoring: Operation not supported
[ 69.608755] input: Goodix Capacitive TouchScreen as /devices/platform/fe5a0000.i2c/i2c-1/1-005d/input/input9
